TOBIN SIDE TABLE
JD-1002-12
ASSEMBLY INSTRUCTIONS
Components:
(A) Top , 1x
Hardware & Tools:
(C) Allen bolt , 4x
20mm x 6 mm
Before beginning:
o Unpack all part and hardware to ensure you have all needed components for assembly
0 Read the guide cover to cover before beginning assembly.
0 Have 2 adults on hand for assembly.
0 Assembly on a padded, no - marring surface.
0 Save all packaging until finish.
Assembly steps
Step 1: Lay the table ( A) on a soft surface, with the inserted nuts facing up. Place the Legs(B)
making them match with the Bolt as shown in the images
Body x 1
(D) Allen bolt , 4x
E
C
(B) Leg , 2x
25mm x 6 mm
Leg, 2x
Leg, 1x
(E) Allen Key , 1x
E
D
