TOBIN ENTERTAINMENT UNIT
JD-1004-12
ASSEMBLY INSTRUCTIONS
Components:
(A) Top , 1x
(C)Center Leg , 1x
Hardware & Tools:
(D) Allen bolt , 2x
16mm x 6 mm
Before beginning:
o Unpack all part and hardware to ensure you have all needed components for assembly
0 Read the guide cover to cover before beginning assembly.
0 Have 2 adults on hand for assembly.
0 Assembly on a padded, no - marring surface.
0 Save all packaging until finish.
Assembly steps
Step 1: Lay the table ( A) on a soft surface, with the inserted nuts facing up. Place the Legs(B)
making them match with the Bolt as shown in the images
Body x 1
(E) Allen bolt , 4x
20mm x 6 mm
G
E
(B) Leg , 2x
(F) Allen bolt , 4x
25mm x 6 mm
A
B
Leg, 2x
Leg, 1x
(G) Allen Key , 1x
C
Advertisement
Table of Contents
Related Manuals for Moe's JD-1004-12
Summary of Contents for Moe's JD-1004-12
- Page 1 TOBIN ENTERTAINMENT UNIT JD-1004-12 ASSEMBLY INSTRUCTIONS Components: (A) Top , 1x (B) Leg , 2x Body x 1 Leg, 2x Leg, 1x (C)Center Leg , 1x Hardware & Tools: (F) Allen bolt , 4x (D) Allen bolt , 2x (E) Allen bolt , 4x...
- Page 2 Step 2: Attach the leg using the Bolts D, E and F and Allen Key (G) provided Step 3: Turn the Table on its upright position Assembly complete Care Instruction: 0 Do not clean furniture with harsh clensers or polish. 0 Do not put hot items directly on furniture surface.
