Moe's SR-1042-03 Assembly Instructions

`
! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish.
! Proper assembly of this item requires 2 to 3 people.
CARE INSTRUCTIONS
Hardware may loosen overtime. Periodically check that all connections are tight. Wipe with a soft, dry cloth. To protect
finish, avoid the use of chemicals and household cleaners. All hot serving dishes should be placed on a pad. Any liquid
spilled onto the furniture should be cleaned up immediately with a damp cloth.
Hardware & Tools/Matériel
A
M8 x
Allen Bolt
25mm 24x

ASSEMBLY STEP:

STEP1: Place the HeadBoard onto the clean & smooth Surface, then Align the Leg with the Fastner
insterted into the HeadBoard. Insert Allen bolt (A) with Washer (C), Spring Washer (D) and Tighten
with Allen Key(E).
STEP 2: Repeat STEP 1 For the Foot Board.
STEP 3: After Assemble the Head Board & Foot Board,Align the Side Rail Hardware Fitting With Head
Board & Foot Board insterted Fasteners, As shown in the Fig.
Now Insert Allen Bolt (A) with Washer (C), Spring Washer (D) & Tighten with Allen Key (E).
STEP 4: Tighten the Mid Leg With the Mid Rail, Using Allen Bolt (B) and Allen Key (F).Now, Place the
Mid Rail With Attached Mid Leg,Gently into the Provided Slots of Head Board & Foot Board. Then Insert
the Allen Bolt (B) and tighten with Allen Key (F).
STEP 5: Once All Connections are tight , Product is Ready to Use.
B C
M8 x
Allen Bolt
Flat washer,
65mm 5x
20mm, 24x
D
24x
Spring washer,
BRONSON BED
SR-1042-03
SR-1043-03
Assembly Instructions
E F
Allen Key 5mm Allen Key 6mm,
1x 1x
