Calibre – Linear Flood
Installation Guide
Notes
Installation should only be performed by a qualified professional
•
Install in accordance with all appropriate wiring standards
•
DALI is not SELV and needs to be wired accordingly
•
Never connect a LED fitting to a driver that is powered. Doing so may
•
result in damage to the LED.
The light source contained in this luminaire shall only be replaced by the
•
manufacturer or his service agent or a similar qualified person.
Do not install under mechanical stress.
•
Allow for expansion due to changes in temperature.
•
Please be aware that while the system has a very long operational life, faults may still occur, and provision needs to be made for maintenance.
•
Always turn off power before working on fitting.
•
All cabling connections should be sealed & protected.
•
Specifications
Dimensions
Length
Weight
Mounting Plate
digilin.com.au
+617 3899 1267
5 0 0
1 0 0 0
102 x 113
508
996
U n i t s
mm
mm
g
Product specifications are subject to change without notice
Document Rev: 1.0 - 24 June 2022
©2022 Digilin Technologies
Page 1 of 3
Advertisement
Table of Contents
Related Manuals for Digilin Calibre 500
Summary of Contents for Digilin Calibre 500
- Page 1 1 0 0 0 U n i t s Dimensions 102 x 113 Length Weight Mounting Plate Document Rev: 1.0 - 24 June 2022 Product specifications are subject to change without notice digilin.com.au ©2022 Digilin Technologies +617 3899 1267 Page 1 of 3...
- Page 2 Calibre - Linear Flood Installation Guide Wiring Diagrams Non-Dim DALI digilin.com.au +617 3899 1267 Page 2 of 3...
- Page 3 Note: Drivers should not be covered. Drivers rely on convection air flow for cooling and covering them may cause them to enter thermal regulation. For any technical information relating to the connection of these luminaires to dimming systems, refer to LED products at www.digilin.com.au digilin.com.au...
