Focus 48 – LED Lighting Profile
Installation Guide
Notes
Install in a dry sheltered position
•
Profile is not sealed. Do not install where water or high humidity may be present
•
without further protection.
Installation should only be performed by a qualified professional
•
Install in accordance with all appropriate wiring standards
•
DALI is not SELV and needs to be wired accordingly
•
Never connect a LED fitting to a driver that is powered. Doing so may result in damage
•
to the LED.
Always make sure the output voltage range and output current of the LED driver match
•
the requirements of the LED fitting. Failure to do so may result in damage both the
driver and fitting.
The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified person.
•
Do not install under mechanical stress.
•
Allow for expansion due to changes in temperature.
•
Please be aware that while the system has a very long operational life, faults may still occur, and provision needs to be made for maintenance.
•
Always turn off power before working on fitting.
•
• Specifications
Dimensions
Length
Weight
Wiring Diagram
digilin.com.au
+617 3899 1267
U n i t s
48 x 32.5
mm
Custom
1400
g/m
Document Rev: 1.0 - 4 February 2022
Product specifications are subject to change without notice
©2022 Digilin Technologies
Page 1 of 3
Advertisement
Table of Contents
Related Manuals for Digilin Focus 48
Summary of Contents for Digilin Focus 48
- Page 1 Focus 48 – LED Lighting Profile Installation Guide Notes Install in a dry sheltered position • Profile is not sealed. Do not install where water or high humidity may be present • without further protection. Installation should only be performed by a qualified professional •...
- Page 2 Focus 48 - LED Lighting Profile Installation Guide Installation If necessary, assemble full length before Cut a hole in the ceiling to the cut-out size With mains circuit off, connect driver to install. For interconnections follow the mains. “Extrusion interconnects” guide before moving to next step.
- Page 3 Focus 48 - LED Lighting Profile Installation Guide Extrusion interconnects Remove all covers Remove gear trays Loosen keyways Align extrusions together Slide internal keys ways across 50/50 into each Re-tighten Keyways. extrusion. Re-install gear tray, making cable Re-install cover interconnects, as necessary.
