Covert Smoke Digital Video Record Camera
Remote Control COLOR CCD Camera 3.7mm Pinhole Lens
SDRDVR35-HSL
* Non-Active Smoke Detector Camera
* Mpeg 4 Compression format
* Memory Full Overwrite Funtcion
* Motion Detection 32G SD Card capability
* Easy Access SD Card
* Records Video/Audio & Takes
* Remote Control
* Included 4GB SD Card
* DC 12V 300mA
Recording Time
SD Card Capacity
1GB
2GB
4GB
* Specifications are subject to change without notice
Recording Time
Photos
150Min(-/+ 10%)
23,200pcs (-/+ 10%)
300Min(-/+ 10%)
36,400pcs (-/+ 10%)
600Min(-/+ 10%)
92,800pcs (-/+ 10%)
VIDEO
DC 12V
ITEMS
TYPE
PICK-UP DEVICE
PICTURE ELEMENTS
HORIZONTAL RESOLUTION
MINI ILLUMINATION
HORIZ.SYNC FREQUENCY
VERTICAL FREQUENCY
CLOCK FREQUENCY
SCANNING SYSTEM
S/N RATIO
ELECTRONIC SHUTTER
LENS
VIDEO OUTPUT
AUDIO OUTPUT
GAMMA
ALARM
WEIGHT
POWER SUPPLY
POWER CONSUMPTION
STORAGE TEMPERATURE
OPERATING TEMPERATURE
100 Feet
Remote Control
Power DC 12V
SDRDVR35-HSL
COLOR
COLOR CCD IMAGE SENSOR
NTSC: 512Hx492V - PAL: 512Hx582V
540 TVL
0.001 LUX
EIA/NTSC: 15.734Khz - CCIR/PAL: 15.625Khz
EIA/NTSC: 60Hz - CCIR/PAL: 18.9375
EIA/NTSC: 19.0699 Mhz - CCIR: 18.9375
2:1 INTERLACE
46dB
1/1000.000s
PINHOLE LENS
1Vp-p, 75 Ohms
2Vp-p (Max)
0.45
100g
DC 12V
300mA
-30°C to +60°C
-10°C to +45\°C
MIC
Camera
VIDEO
MONITOR
** Designed in U.S.A.
IR
