6. BASIC OPERATIONS

3) PANEL RELEASE BUTTON (REL)
Press this button to remove the control panel.
1) POWER ON/OFF BUTTON (
Press POWER button or any other button on the front of the radio to turn the unit on. Press
POWER button again to turn the unit off.
1) MUTE BUTTON (MUTE)
Press the mute button momentarily to mute the audio volume, and "Mute" will flash in the
display. Press the mute button again to restore volume to the previous setting.
8) SUBWOOFER (SUB)
Pressing the SUB button to activate the Subwoofer function On, and "Subwoofer" will appear
on the LCD display for 3 seconds. press the SUB button again to turn off the Subwoofer
function.
10) iX-BASS BUTTON (X-Bass )
Pressing the iX-Bass button to turn on the iX-Bass function, and "iX-Bass" will appear in the
LCD display for 3 seconds. Press the iX-Bass button again to turn off the iX-Bass function.
5) SOURCE BUTTON (SRC)
Press SRC button to select a different source of operation as indicated on the display panel.
Available modes include Tuner, USB Host, SD/MMC, iPod and Aux - In.
2) FRONT PANEL AUX-IN JACK
Connect the external signal to AUX in jack located at the front of the panel , then press SRC
button to select Aux mode. Press SRC Button again to cancel Aux Mode and return to
previous mode.
1
OPEN THE AUX-IN JACK DOOR/COVER
TO ACCESS TO THE AUX-IN JACK
6) ENCODER VOLUME BUTTON
To increase the volume, rotate the volume control clockwise. To decrease the volume, rotate
the volume control counter clockwise. When volume is adjusted, the volume level will be
shown on the display panel as a number ranging from 0 (lowest) to 46 (highest).
)
AUX IN
11
2
FRONT CABINET
LEFT TRACK
RIGHT TRACK
GROUND
AUX IN
