  • Page 2 This radio is equipped with the most advanced "TOUCH SENSE PANEL", so that it is easy and convenient to use while driving. Tips; Here are some tips to show you how easy it is to use this touch sense panel: Tips Using a very light touch on the radio panel will activate that feature.

  • Page 3: Installation

    1. INSTALLATION Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and system work properly. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.
  • Page 4 Removing the unit Trim Plate Installation: Push the trim plate against the chassis until it is fitted. You must do this before you install the front panel, otherwise it can't be attached. DIN REAR-MOUNT (METHOD B) Installation using the screw holes on the sides of the unit. Fastening the unit to the factory radio mounting bracket.

  • Page 5: Detachable Control Panel (D.c.p .)

    2. DETACHABLE CONTROL PANEL (D.C.P .) Removing The Detachable Control Panel (D.C.P .). PANEL RELEASE BUTTON Attaching the DCP CAUTION DO NOT insert the D.C.P from the left side. Doing so may damage it. The D.C.P can easily be damaged by shocks. After removing it, place it in a protective case and be careful not to drop it or subject it to strong shocks.
  • Page 6 3. WIRING DIAGRAM (20 PIN + ISO PLUG) FUSE Figure 2 ISO CONNECTOR 4PIN+8PIN FEMALE WITH MALE TERMINAL ISO CONNECTOR WIRING CHART WIRE COLOR FUNCTION/LABEL YELLOW CONSTANT 12 VOLTS BLUE POWER ANTENNA/REMOTE TURN ON IGNITION(ACC) BLACK GROUND VIOLET RIGHT REAR SPEAKER (+) VIOLET/BLACK RIGHT REAR SPEAKER (-) GREY...

  • Page 7: Control Panel Function

    4. CONTROL PANEL FUNCTION OPERATIONS: SYSTEM TUNER Long Short Short Press Press Press Mute Power Audio Me nu Mode En cod er Vol ume Ba nd Su b- W Co py ix-Ba ss PT Y Display Se ek Up Se ek Do wn System Menu...

  • Page 8: Ipod Operation

    5. iPod OPERATION INSTALLING iPod INTO THE BUILT-IN iPod DOCKING Always follow the below steps to install the iPod into the docking station. Incorrect or improper installation may cause permanent damage to the docking or the iPod unit. Step 1 Press down the button as indicated below to unlock the iPod docking.
  • Page 9 REMOVE iPod FROM THE BUILT-IN iPod DOCKING To take out the iPod from the docking station, user can first detach the front panel, and repeat step 1 to step 8 to take out the iPod & return the iPod docking inside the unit’s cabinent. Step 1 Press the button as indicated below to unlock the iPod docking.
  • Page 10 iPod FULL CONTROL / OPERATION This unit is equipped with iPod Ready function which allow end user to have direct control of the iPod on the front panel control button and display iPod song information on the unit's LCD display. Please read below for more details operation.
  • Page 11 Playlist Artist Album Song Genre Once selected the desire searching method, within 10 second press the AUDIO button as confirm & access into the searching mode, then turn the rotate encode volume knob to navigate thru the Album or Artist or Song contained in the iPod. Press the AUDIO button to confirm & play the selected song.

  • Page 12: Basic Operations

    6. BASIC OPERATIONS PANEL RELEASE BUTTON (REL) Press this button to remove the control panel. POWER ON/OFF BUTTON ( Press POWER button or any other button on the front of the radio to turn the unit on. Press POWER button again to turn the unit off. MUTE BUTTON (MUTE) Press the mute button momentarily to mute the audio volume, and "Mute"...

  • Page 13: Menu Operation

    7. MENU OPERATION 22) MENU FUNCTION LIST (SYS MENU) Press SYS MENU to access the menu. Navigate the menu by pressing SYS MENU momentarily to move forward to the next option. The menu can also be navigated by using the Tuning Up or Tuning Down Button to move to the next or previous option.

  • Page 14: Audio Operation

    8. AUDIO OPERATION Audio Menu Pressing “AUDIO button to access the Audio Menu. User can navigate thru the Audio Menu items ” by pressing the “AUDIO” button repeatedly, or by pressing the Tuning Up or Tuning Down Button. Once the desired menu item appears on the display, adjust that option by using the Volume Up or Down button within 5 seconds.

  • Page 15: Tuner Operation

    9. TUNER OPERATION BAND BUTTON (BAND) Press BAND to change between FM bands and AM(MW)bands. 20-21) TUNING UP/DOWN BUTTON ( Manual Tuning Press the Up Tuning or Down Tuning button for more than 3 seconds to move the radio frequency number up or down one step. Auto Seek Tuning Press the Up Tuning or Down Tuning button for less than 3 seconds to move to next station automatically.

  • Page 16: Rds Operation

    10. RDS OPERATION RDS functions The unit is equipped with the following RDS function: - AF Alternative Frequencies - CT Clock Time - EON Enchanced other Network - PI Program identifications - PS Program service name - PTY Program Type - REG Regional Change - TA Traffic Announcement - TP Traffic program...

  • Page 17: Operation

    11. MP3/WMA MUSIC FILES OPERATION OPERATION PAUSE BUTTON Press the pause button to suspend file play. Press the pause button again to resume file play. 20-21) FILE SELECT Press the Up Tuning or Down Tuning button ( to the next file, The selected file number will appear on the display. Press and hold the Up Tuning or Down Tuning button ( reverse through the file.
  • Page 18 Entering File and Folder Names Names using the code list characters are the only file names and folder names that can be entered and displayed. Using any other character will cause the file and folder names to be displayed incorrectly. The unit recognizes and plays only files with the MP3/WMA extension. A file name entered with characters not on the code list may not play correctly.
  • Page 19 FILE/FOLDER PLAY There are three different play methods as following: File/Folder Intro play: Press M2 button more than 3 seconds during playing MP3/WMA file for “intro play” all files of the current folder. Intro play should restart from the first song of the current folder, after all files in the current files have been intro-played.

  • Page 20: Usb Operation

    12. USB OPERATION The unit can support USB Host Function. It can playback MP3 and WMA Audio format which are stored into USB Memory Stick or USB interface Music Player. Please read below before you start the operation of USB HOST Function. Inserting and Removing USB Drive Inserting the USB stick Mode change to USB HOST...

  • Page 21: Memory Card Operation

    13. MEMORY CARD OPERATION The unit can support playback MP3 and WMA Audio format which are stored into SD and MMC Memory Card . Please read below before you start the operation of Memory Card. Inserting and Removing a SD or MMC card on the main unit Detach the Front Panel Detach the...

  • Page 22: Music Files Transferring

    14. MUSIC FILES TRANSFERRING Thanks for the most useful and convenient files transferring function of this unit, user can easily transfer music files between USB Stick, SD or MMC Memory card. Please read below for the details operation of this function: TRANSFERABLE MEDIA Files are transferable within the following media: Removable USB Stick...
  • Page 23 TRANSFER MP3 OR WMA MUSIC FILES BETWEEN MEDIA DEVICES Select a device by mode button and playback the music file need to be transfer: 1. Long press the COPY button to activate the transfer mode. 2. The LCD will display thru >...

  • Page 24: Music Files Erasing

    15. MUSIC FILES ERASING You can erase files from the USB Stick or Memory Card. Please read below for the details operation of this function: ERASABLE MEDIA USB Stick and Memory Card. ERASING MUSIC FILES ON THE MEDIA There are THREE different methods for erasing files; 1.Erase while the Music File is playing.
  • Page 25 Short Press the AUDIO to enter into the ERASE mode Once enter into the erase mode. User can rotate the encoder to select “ erase or rotate the volume knob to select “ ” to cancel the ERASE mode. If no further button is press within a 5 second time out.

  • Page 26: Files Manager

    16. FILES MANAGER The advance “File Management.” System of this unit can help to well you organize all the music files just like a PC . Please read below for details: FOLDERS MANAGEMENT This unit will automatically self-create the below default folders onto any USB /SD / MMC media device, once these devices are inserted into the unit.

  • Page 27: Bluetooth Hand Free Operation

    17. BLUETOOTH HAND FREE OPERATION User Guide For Bluetooth Operation 1. When user use our Bluetooth HEAD UNIT, please make sure the mobile phone you use must / does support Bluetooth functions (Headset or Handsfree profiles or both) 2. Before you start to use our Bluetooth HEAD UNIT, please make sure complete pairing with your mobile phone first.
  • Page 28 Bluetooth Mobile Phone Compatibility List This unit can support Bluetooth specification v1.2 or higher, and compatible with Bluetooth profiles such as handsfree or headset profiles. however the functionality may be limited due to some phones' own dedicated interfacing specification. This list is only updated to the time this list is being printed. This list gives an example of Bluetooth mobile phone available on the market, if your Bluetooth mobile phone is not on the list, please try it out in practice or try your phone at the local dealer or consult with the local dealer in case it is not mentioned in the list.
  • Page 29 3. MOTOROLA Features Caller ID A2DP/AVRCP Paring Paring In-Band Ring T one Ringing T alk Reject Audio T ransfer T alking Volume up/down Hang up Audio T ransfer Dialing Volume up/down Stop/Pause/Play Stereo Volume control Control Forward/Backward Next/Previous MOTOROLA Features Caller ID A2DP/AVRCP Paring...
  • Page 30 4. NOKIA Features Caller ID A2DP/AVRCP Paring In-Band Ring T one T alk Ringing Reject Audio T ransfer Volume up/down T alking Hang up Audio T ransfer Dialing Volume up/down Stop/Pause/Play Stereo Volume control Control Forward/Backward Next/Previous NOKIA Features Caller ID A2DP/AVRCP Paring In-Band Ring T one...
  • Page 31 NOKIA Features Caller ID A2DP/AVRCP Paring In-Band Ring T one Ringing T alk Reject Audio T ransfer T alking Volume up/down Hang up Dialing Audio T ransfer Volume up/down Stop/Pause/Play Stereo Volume control Control Forward/Backward Next/Previous 5. SAMSUNG Features Caller ID A2DP/AVRCP Paring In-Band Ring T one...
  • Page 32 SAMSUNG Features Caller ID A2DP/AVRCP Paring In-Band Ring T one Ringing T alk Reject Audio T ransfer T alking Volume up/down Hang up Dialing Audio T ransfer Volume up/down Stop/Pause/Play Stereo Volume control Control Forward/Backward Next/Previous 6. SHARP & SIEMENS Features Caller ID A2DP/AVRCP...
  • Page 33 7. SONYERICSSON Features Caller ID A2DP/AVRCP Paring In-Band Ring T one Ringing T alk Reject Audio T ransfer T alking Volume up/down Hang up Audio T ransfer Dialing Volume up/down Stop/Pause/Play Volume control Stereo Control Forward/Backward Next/Previous SONYERICSSON Features Caller ID A2DP/AVRCP Paring In-Band Ring T one...
  • Page 34 SONYERICSSON Features Caller ID A2DP/AVRCP Paring In-Band Ring T one Ringing T alk Reject Audio T ransfer T alking Volume up/down Hang up Dialing Audio T ransfer Volume up/down Stop/Pause/Play Stereo Volume control Control Forward/Backward Next/Previous S700i W550i Z600 Not Supported Not Supported Not Supported this function...
  • Page 35 BLUETOOTH HAND FREE PANEL FUNCTION KEY MATRIX Panel Function Button Short Press AUDIO Long Press Encoder volume Knob BAND Short Press MODE Long Press MENU Tune Up / Down Bluetooth Hand Free Function Enter Phone number input mode Confirm Dialing the input Phone Number Use for numeric input 1.
  • Page 36 PAIRING Pairing The Bluetooth System Between User’s Mobile Phone & The Unit Access into MENU - PAIRING mode to activates the operation of Pairing . Please see MENU Operation for more details of how to access into MENU mode . Once the activate the Pairing mode.

  • Page 37: Answering An Incoming Call

    The unit will be Auto Re-Connection by following operation . Every time turn the ignition key from off to on ,the unit will Auto re-connect with the mobile phone one. Every time when user long press AUDIO button or short press MODE button confirm dialing a call, the Unit will Auto Re-connect with the Mobile Phone once ( Only if this Mobile Phone has been paired with the unit previously ).

  • Page 38: Outgoing Call

    OUTGOING CALL Making An Outgoing Call Press the “PHONE” (AUDIO)button to start making an outgoing call. The LCD Display will display phone number. Rotate the encoder knob to navigate thru the numeric 0-9 *, # & + . Press the” AUDIO” button as confirm input the selected numeric. Use the File up/down button to move the cursor back or forward to the wrong inpu numeric.

  • Page 39: Highlight Features

    DIALED LIST To Find the Last 10 Dialed Number The unit can memory up to 10 last dialed number. Press the “PHONE” (AUDIO) button, after the LCD appeared display “ then Long press “PHONE” (AUDIO) button. The last dialed number as the first number on the list will display on the LC D. Rotate the encoder knob to navigate through the 10 last dialed number.
  • Page 40 BLUETOOTH AUDIO STREAMING A2DP (ADVANCED AUDIO DISTRIBUTION PROFILE) User can listen to music files on an audio device on this unit if the audio device supports A2DP (Advanced Audio Distribution Profile) of Bluetooth Technology. Please read the below instruction before operating the Bluetooth Audio streaming function on this unit. Connecting A Bluetooth Audio Device With This Unit Before using audio device to play music on this unit, the audio device must be paired with this unit first.
  • Page 41 Operating an audio device with this unit AVRCP ( Audio Video Remote Control Profile ) This unit can perform the following operations with the connecting Audio device which supports AVRCP (Audio Video Remote Control Profile) & only if the Audio device does support AVRCP . (1) Start playing - Every time when user change mode into “BT AUDIO”...

  • Page 42: Download Mode

    BLUETOOTH WIRELESS MUSIC FILE DOWNLOAD (OPP) Thanks for the most advance and convenient Bluetooth Wireless Technology, now user can wirelessly transfer the music file and download onto this unit's USB stick or Memory Card. Please read the below instruction before operating the Bluetooth Wireless Music File Download on this unit.
  • Page 43 c. If there is no storage media available on this unit to accept the download, the display will show d. If this unit detected the selected media memory capacity is used up or the. file size being. file size being download is bigger than the media memory capacity left, (2) Once selected the storage media, Press the ENTER (MENU) button to confirm the selection and the file download will begin.
  • Page 44 18. REMOTE FUNCTION(RDS +iPod) OPERATIONS: SYSTEM Short Long Press Press Power Mute Display Menu Source Mute Vol ume Up Vol ume Do wn Au di o Men u Su b- W Co py ix-Ba ss TUNER CD/M P3/W MA Short Long Short Press...

  • Page 45: Specifications

    19. SPECIFICATIONS MEDIA SECTION USB Host Memory Card Support Type of Memory Card RADIO SECTION Frequency Range Intermediate Frequency Usable Sensitivity Stereo Separation S/N Ratio AM/MW Frequency Range Intermediate Frequency Usable Sensitivity S/N Ratio BLUE TOOTH Power Consumption Output Power Frequency Band Range Standard...

  • Page 46: Troubleshooting

    20. TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom Cause The car ignition is not on. No power The fuse is blown. Volume is in minimum.
  • Page 47 10 R - 02 0896...
