- Page 1 INSTALLATION & OPERATION MANUAL BCD305 SERIES DC Battery Charger An ISO9001 and AS9100 Registered Company Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA)
- Page 2 Copyright (2005-2016) Analytic Systems Ware (1993) Ltd. Revised - May 19, 2016...
-
Page 3: Important & Safety Instructions
IMPORTANT & SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS — This manual contains important safety and operating instructions for the battery charger. ALL BATTERY CHARGERS 1. CAUTION — To reduce risk of injury, charge only lead acid or sealed gel cell type rechargeable batteries. -
Page 4: Battery Charger Location
Connect and disconnect all DC connections only after setting battery charger switch to off position. Analytic Systems does not recommend the use of the BCD305 Series Battery Chargers in life support applications where failure or malfunction of this product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effectiveness. - Page 5 Introduction This all new single board design incorporates state of the art switchmode technology for unmatched efficiency and ultra-quite operation. Multiple stages of filtering reduce radiated or conducted noise to very low levels. Extra features include adjustable output voltage, audible and visual indicators for low input voltage, low output voltage and over temperature.
-
Page 6: Specifications
Charging Current = Input Volts/Output Volts x 26 For example, at 10.5VDC in and 13.6VDC out, the charging current = 10.5/13.6 x 26 = 20.1 amps Designed and manufactured by: ANALYTIC SYSTEMS WARE (1993) LTD. 8128 River Way p. -
Page 7: Installation
Installation MOUNTING Mount the unit in a DRY location. Allow at least 1 inch of clearance for adequate cooling. POWER CONNECTION The unit is supplied with input power leads 1 meter long. This should normally be adequate to connect to a source of power. If you must extend the cable: •... -
Page 8: Operation
Operation Turn the power switch on the front of the unit on to energize the outputs. If you wish to adjust the output voltage, first attach a good digital voltmeter to the output terminals to monitor the voltage. Next, remove the cover plate (secured by 2 screws) to expose the output adjust potentiometer. - Page 9 Dry Contact Relay To use your dry contact output fail relay you must connect a 9-pin D connector to the unit. You must use pins one and six as is indicated on page 7 in the remote connector diagram. The relay is factory preset to fail in the closed position when the low output LED and buzzer come on.
-
Page 10: Remote Control Option
The remote control panel allows the unit to be operated remotely as well as duplicating all the diagnostic indicators and audible alarm. IMPORTANT: This remote is to be used only on Battery Chargers manufactured by Analytic Systems. REMOTE CONNECTOR This connector is located on the side of the unit. -
Page 11: Limited Warranty
2 Years from date of manufacture for non-standard or OEM products 1 Year from date of manufacture for encapsulated products. 3. Analytic Systems will determine eligibility for warranty from the date of purchase shown on the warranty card when returned within 30 days, or... - Page 12 An ISO9001 and AS9100 Registered Company Battery Chargers • Inverters • Power Supplies • Voltage Converters 8128 River Way, Delta B.C. V4G 1K5 Canada T. 604.946.9981 F. 604.946.9983 TF. 800.668.3884 (US/CANADA) www.analyticsystems.com...
