- Page 1 ENGLISH ComDry M190Y Dehumidifier User manual from serial no. 20001 T-M190Y-A1808...
- Page 2 Copyright © 2018 Munters Europe AB Original instructions Read these instructions before using the dehumidifier.
-
Page 3: Table Of Contents
8. Fault tracing ........................23 9. Technical specification ...................... 24 9.1. Dimensions and service space ................24 9.2. Capacity diagram ....................25 9.3. Fan curve ......................26 9.4. Technical data ....................... 27 10. Disposal ........................28 11. Contact Munters ......................29... -
Page 4: Important User Information
1. Important user information 1.1. Intended use Munters dehumidifiers are intended to be used for the dehumidification of air. Any other use of the unit, or use which is contrary to the instructions given in this manual, can cause personal injury and damage to the unit and other property. -
Page 5: Copyright
The contents of this manual can be changed without prior notice. NOTE This manual contains information which is protected by copyright laws. It is not allowed to reproduce or transmit any part of this manual without written consent from Munters. Munters Europe AB, P.O. Box 1150, SE-16426 KISTA Sweden... -
Page 6: Introduction
Read through the manual before the dehumidifier is installed and used. Contact your nearest Munters office if you have any questions about the installation or the use of your dehumidifier. -
Page 7: Marking
ComDry M190Y Dehumidifier WARNING • The unit must not be splashed with or immersed in water. • All electrical installations must be done by an authorized electrician in accordance with local regulations. An incorrect installation can cause electrical shock hazards and damage to the unit. -
Page 8: Function Overview
The rotor is divided in two zones. ComDry M190Y uses the same inlet airflow for process air and for reactivation of the rotor. The airflow to be dehumidified, process air, passes through the largest zone of the rotor and then leaves the rotor as dry air. -
Page 9: Transport, Delivery Inspection And Storage
• Any damage to the unit must be documented with photos. • Any visible damage must be reported in writing to Munters within 3 days and prior to installation of the unit. • Discard the packaging material according to local regulations. -
Page 10: Installation
ComDry M190Y Dehumidifier 5. Installation 5.1. Safety WARNING All electrical installations must be done by an authorized electrician in accordance with local regulations. An incorrect installation can cause electrical shock hazards and dam- age to the unit. The unit must never be connected to another voltage or frequency than what is speci- fied on the identification plate. -
Page 11: Open System
ComDry M190Y Dehumidifier 1. Process / Reactivation air 2. Dry air 3. Wet air 5.3. Open system The dehumidifier is placed outside the space to be dehumidified. The installation is used to solve the following problems: • When moisture damaged objects are to be dehumidified. -
Page 12: Site Requirements
The dehumidifier is only intended for indoor installation. Avoid installing the dehumidifier in a damp environment where there is a risk of water entering the unit or in a very dusty environment. If in doubt, contact Munters. NOTE It is important that the intended installation site meets the location and space require- ments for the equipment in order to achieve the best possible performance and trou- ble-free operation. -
Page 13: Connecting The Wet Air Hose
ComDry M190Y Dehumidifier NOTE Horizontal ducts must be installed with a slight decline away from the dehumidifier to drain possible condensation. The decline must be at least 2 cm/m of duct. Drainage holes (5 mm) should be made at low points of the duct to prevent water accumulation. -
Page 14: Electrical Connections
ComDry M190Y Dehumidifier 5.6. Electrical connections The dehumidifier is delivered with a 2.7 m long power cable, with a plug for connection to an earthed outlet. WARNING All electrical installations must be done by an authorized electrician in accordance with local regulations. -
Page 15: Accessories
ComDry M190Y Dehumidifier Remove the cover. CAN bus ports with empty termination plugs. 5.8. Accessories Wall bracket For mounting the unit on a wall. Stub pipe kit Used when there is a need to connect an inlet duct or hose to the dehumidifier. - Page 16 ComDry M190Y Dehumidifier Remote control Makes it possible to control the unit from a distance, delivered with a 10 m cable. External signal box Used when there is a need to connect to an external control system. Remote RH/T sensor For external measuring of humidity and temperature.
-
Page 17: Operation
ComDry M190Y Dehumidifier 6. Operation 6.1. Safety WARNING The unit must not be splashed with or immersed in water. The unit can restart automatically without warning following a power cut. Do not operate the unit if the power cable or plug is damaged, risk of electrical shock. -
Page 18: Humidity Control
ComDry M190Y Dehumidifier 6.3. Humidity control The ComDry dehumidifier is equipped with a sophisticated microprocessor based control system. This, in combination with the built-in humidity/temperature sensor in the process air inlet, makes it possible to set both the control and presentation of the humidity to either relative humidity (RH%), dew point (Dp °C) or absolute humidity (X gr/kg). -
Page 19: Control Panel Overview
ComDry M190Y Dehumidifier 6.5. Control panel overview RH1 55% Humidity menu Temperature menu Alarm indicator Time menu Functions menu Operation indicator Power menu Alarm menu On/Off button Menu button Function Up/Right button Enter/Confirmation button Down/Left button NOTE For more information about the control system and the operation of the dehumidifier, see the ComDry Control System Supplement or Quick Guide. -
Page 20: Stop The Dehumidifier
ComDry M190Y Dehumidifier Press the On/Off button (C) once to start the dehumidifier. If the measured humidity is lower than the Set Value, the green operating indicator (B) will start to flash in a long on/short off sequence. Depending on fan mode setting, the process fan will run or not. The unit is now in stand-by mode. -
Page 21: Maintenance
It is recommended to contact Munters for service or repair. Operating faults can occur if the unit is maintained insufficiently or incorrectly. Munters Service can offer a service plan adapted to suit the conditions of a specific installation. See contact details at the back of this manual. -
Page 22: Filter Change
ComDry M190Y Dehumidifier 7.3. Filter change Process air Push the filter frame down. Pull the filter frame out and remove it from the unit. Remove the old filter. Replace it with a new filter and install the frame. -
Page 23: Fault Tracing
Check rotor drive belt and drive motor. fault Check through the dry air outlet that the rotor ro- tates at approximately ten revolutions per hour. If rotor does not rotate, contact Munters. Alarm message: Unit is connected to the Check mains supply. -
Page 24: Technical Specification
ComDry M190Y Dehumidifier 9. Technical specification 9.1. Dimensions and service space Dimensions in mm ØD ØE ØD ØE Weight 11.5 kg... -
Page 25: Capacity Diagram
The diagram shows approximate process air dehumidification capacity as a function of the process air temperature for three different air humidity conditions. For detailed information, contact your nearest Munters office. X-axis = Temperature, process air (°C) Y-axis = Dehumidification capacity (kg/h) -
Page 26: Fan Curve
ComDry M190Y Dehumidifier 9.3. Fan curve Process air ComDry M190Y A (Pa) B (m³/h) Density 1,2 kg/m A. Static pressure (Pa) B. Airflow (m /hour... -
Page 27: Technical Data
ComDry M190Y Dehumidifier 9.4. Technical data Process air Free-blowing air 50/60 Hz (m³/h) Rated airflow at 60 Pa (m³/h) Max. static pressure 50/60 Hz (Pa) Fan motor power (kW) 0,09 Reactivation air Rated airflow at 90 Pa (m³/h) Max. static pressure (Pa) -
Page 28: Disposal
ComDry M190Y Dehumidifier 10. Disposal The unit and consumables must be disposed of in accordance with applicable legal requirements and regulations. Contact your local authorities. If the rotor or filters have been exposed to chemicals that are dangerous to the environment the risk must be assessed. -
Page 29: Contact Munters
ComDry M190Y Dehumidifier 11. Contact Munters EUROPE AUSTRIA Tel: +43 1 616 4298-92 51 ITALY Tel: +39 0183 521377 luftentfeuchtung@munters.at marketing@munters.it BELGIUM Tel: +3215285611 NETHERLANDS Tel: +31 172 43 32 31 service@muntersbelgium.be vochtbeheersing@munters.nl CZECH REPUBLIC Tel: +420 775 569 657 POLAND Tel.: + 48 58 305 35 17... - Page 32 www.munters.com...
