- Page 1 BCS-series Bluetooth Ceiling Speaker Set Item ref: 953.164, 953.165UK User Manual Version 1.2...
- Page 2 Damage caused by misuse is not covered by the warranty Introduction Thank you for choosing the Adastra BCS-series Bluetooth ceiling speaker set for your ceiling speaker installation. This unit is designed to provide a discreet and expandable solution for background music or other sound application. Please read this manual to gain the best results from your product and avoid damage through misuse.
- Page 3 Installation The BCS-system is supplied as a set of two speakers – one active and one passive. Decide where the active speaker is to be situated and bear in mind that it may be the target for a Bluetooth sending device and will need to be connected to the mains using the power supply included.
- Page 4 Take the bare ends of the speaker lead from the passive speaker and connect to the terminals on the active speaker marked “PASSIVE SPEAKER”, ensuring the polarity (+ and -) matches the previously made connections to the passive speaker. If a wired audio input is to be fed to the speakers, connect using a stereo RCA lead and feed this through the ceiling or wall hole for the active speaker.
- Page 5 Pair the smartphone or tablet by scanning for available Bluetooth devices and selecting to pair with “Adastra BCS**S” (where “**” is the speaker size 52 or 65). If there is more than one Bluetooth ID called “BCS**S”, it may mean that the Bluetooth function needs to be deactivated on some active speakers that are acting as “slave”...
- Page 6 Specifications Model BCS52S BCS65S Output power: max. 2 x 20W 2 x 25W Output power: rms 2 x 15W 2 x 20W LF driver 135mmØ (5.25“) 165mmØ (6.5“) Frequency response 80Hz - 20kHz 70Hz - 20kHz Dimensions active 97 x 205mmØ 98 x 234mmØ...
