M7NCD Ultra Features

A. Hardware
CPU
Provides Socket-462.
Supports the AMD
Front Side Bus at 266/333/400 MHz.
Chipset
North Bridge: nFORCE2 SPP.
South Bridge: MCP.
High Speed 800Mb/s Hyper-Transport interface to the MCP.
Main Memory
Supports up to 3 DDR devices.
Supports 266/333/400MHz (without ECC) DDR devices.
High performance 128 bit DDR400 Twin Bank Memory Architecture.
Maximum memory size of 3GB.
Super I/O
Chip: Winbond W83627HF.
Slots
Five 32-bit PCI bus master slots.
One AGP: AGP3.0 8X interface at 533Mb/s.
Supports AGP 2X, 4X, 8X.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Master Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
Serial ATA Chip
Chip: VIA VT6420.
Supports 2 Serial ATA (SATA) ports.
Compliant with SATA 1.0 specification.
Data transfer rates up to 150 Mb/s.
On Board AC'97 Sound Codec
Chip: ALC650.
Compliant with AC'97 specification.
AC99 2.2/2.3 interface.
Supports 6 channels.
®
processor up to XP 3200+.
3
