FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here of and specially disclaims any implied warranties of merchantability or fitness
for any purpose. Further the vendor reserves the right to revise this publication
and to make changes to the contents here of without obligation to notify any party
beforehand.
Duplication of this publication, in part or in whole is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we will not
be responsible for any mistakes found in this user's manual. All the brand and
product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7NCG and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar M7NCG

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    CPU Installation ... 4 DDR DIMM Modules: DIMMB1/DIMMB2/ DIMMA1... 5 Jumpers, Headers, Connectors & Slots ... 6 ESPAÑOL ...12 Características del M7NCG (para V1.3) ... 12 Contenido del Paquete... 13 Disposición del M7NCG ... 14 Instalación de la CPU ... 15 Instalación de la CPU ...
  • Page 3: English

    English M7NCG Features(for V 1.3) ® Supports the AMD Socket462 processor up to XP 3000+. Running at 200/266/333MHz Front Side Bus. Chipset North Bridge: IGP Chipset. South Bridge: MCP-T/ MCP Chipset. High Speed 800Mb/s Hyper-Transport interface to the MCP-T. Main Memory Supports up to 3 DDR devices.
  • Page 4: Package Contents

    On Board Peripherals Supports 360K, 720K, 1.2MB, 1.44MB and 2.88MB floppy disk drivers. Supports 2 serial ports. Supports 1 multi-mode parallel port. (SPP/EPP/ECP mode) Supports PS/2 mouse and PS/2 keyboard. Supports 2 back USB2.0 ports and 4 front USB2.0 ports. (Optional) BIOS AWARD legal Bios.
  • Page 5: Layout Of M7Ncg

    Layout of M7NCG JKBMS1 JKBV1 JUSBLAN1 JCOM1 JUSBV2 JPRNT1 JCLK3 JVGA1 JSPKR1 Winbond SP-OUT JLIN1 LINE-IN JGAME1 JMIC1 MIC-IN JNFAN1 Chip Codec J_CODECSEL J1394A JCFAN1 PCI1 MCP-T PCI2 BIOS PCI3 1394A Chip JUSB1 JUSB2 JUSBV1 J1394B FDD1 JATXPWER1 IDE2 IDE1...
  • Page 6: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU. Press the lever down.
  • Page 7: Ddr Dimm Modules: Dimmb1/Dimmb2/ Dimma1

    DDR DIMM Modules: DIMMB1/DIMMB2/ DIMMA1 For Dual-channel DDR (128-bit) high performance, at least 2 or more DIMM modules must be installed. (It has to be the combination of DIMMA and DIMMB.) With only one DIMM installed, the memory performs only at 64-bit. DRAM Access Time: 2.5V Unbuffered DDR 200/266/333/400 MHz Type required.
  • Page 8: Jumpers, Headers, Connectors & Slots

    Peripheral Component Interconnect Slots: PCI1-3 This motherboard is equipped with 3 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in most ports. This PCI slot is designated as 32 bits.
  • Page 9 Wake On LAN Header: JWOL1 JWOL1 Front USB Header: JUSB1/ JUSB2 Pin Assignment Pin Assignment JUSB1/2 5V/ 5V_SB Selection for KB: JKBV1 JKBV1 Contactos 1-2 on Contactos 2-3 on Front 1394 Header: J1394A/ J1394B Pin Assignment Pin Assignment J1394A/ B Wake up Ground 5V_SB...
  • Page 10 5V/ 5V_SB Selection for USB: JUSBV1/JUSBV2/JUSBV4 JUSBV1/ 2/ 4 Pin 1-2 on Pin 2-3 on Front Panel Connector: JPANEL1 PWR_LED (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button PWR_LED ==> Power LED ON/ OFF Audio Subsystem: JF_AUDIO1/ JCDIN1 JF_AUDIO1 JAUDIO1...
  • Page 11 Assignment Mic In Mic Power RT Line Out Reserved LFT Line Out ⌦ JF_AUDIO1 only support 2CH. Front Panel Audio Connector/ Jumper Block Jumper Setting Pin 5 and 6 Audio line out signals are routed Pin 9 and 10 to the back panel audio line out connector. No jumpers Audio line out and mic in signals are installed...
  • Page 12 Remove AC JCMOS1 power line Pin2-3 close AC power Reset the passwort as your will Frequency Selection: JCLK3 Open==> 133/166MHz Close==> 100MHz JCLK3 Case Open Connector: JC1 CNR Codec Primary/Secondary Selection: J_CODECSEL J_CODECSEL Pin 1-2 Pin 2-3 wait 15 JCMOS seconds Pin1-2 close or clear CMOS data...
  • Page 13 Digital Audio Connector: J_SPDIF1 SPDIF_OUT VCC5 J_SPDIF1 Back Panel Connectors JKBMS1 JUSBLAN1 JPRNT1 PS/2 LAN(Optional) Mouse Parallel PS/2 COM1 Keyboard JCOM1 The LED indicator for Lan port status: Status Normal Speed Right light: green 10Mbps Left light: no Right light: green 100Mbps Left light: orange JGAME1...
  • Page 14: Español

    Español Características del M7NCG (para V1.3) Soporta procesador AMD Corriendo a 200/266/333MHz FSB. Chipset North Bridge: IGP Chipset. South Bridge: MCP-T/ MCP Chipset. High Speed 800Mb/s Hyper-Transport interface para el MCP-T. Memoria Principal Soporta hasta 3 dispositivos DDR. Soporto 200/266/333/400MHz (sin ECC) dispositivos DDR.
  • Page 15: Contenido Del Paquete

    Soporta 2 puertos serie. Soporta 1 multi-modo del puerto paralelo (modos SPP/EPP/ECP) Soporta ratón PS/2 y teclado PS/2. Soporta 2 puertos USB2.0 traseros y 4 puertos USB2.0 delanteros. (Opcional) BIOS AWARD legal Bios. Soporta APM1.2. Soporta ACPI. Soporta función USB. Sistemas Operativos Ofrece alto rendimiento en MS-DOS, Windows 2000, Windows Me, Windows XP, SCO UNIX etc.
  • Page 16: Disposición Del M7Ncg

    Disposición del M7NCG JKBMS1 JKBV1 JUSBLAN1 JCOM1 JUSBV2 JPRNT1 JCLK3 JVGA1 JSPKR1 Winbond Salida del Altavoz JLIN1 Entrada de JGAME1 Linea JMIC1 Entrada del MIC JNFAN1 Chip Codec J_CODECSEL J1394A JCFAN1 PCI1 MCP-T PCI2 PCI3 1394A Chip JUSB1 JUSB2 JUSBV1...
  • Page 17: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 18: Módulos Ddr Dimm: Dimmb1/Dimmb2/ Dimma1

    Módulos DDR DIMM: DIMMB1/DIMMB2/ DIMMA1 Para un alto funcionamiento, Dual-channel DDR (128-bit), por lo menos 2 o más módulos DIMM debe ser instalado. (Tiene que ser la combinación del DIMMA y DIMMB.) Con solamente un DIMM instalado, la memoria funciona solamente a 64-bit. DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266/333/400 MHz Tipo requerido.
  • Page 19: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalida Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 20 Cabezal Wake On LAN: JWOL1 JWOL1 Cabezal Frontal USB: JUSB1/ JUSB2 Contactos Asignacion Contactos Asignacion Data (-) Data (+) Tierra 5V/ 5V_SB Selección para KB: JKBV1 JKBV1 Contactos 1-2 on Contactos 2-3 on Cabezal Frontal 1394: J1394A/ J1394B Contactos Asignacion Contactos Asignacion Tierra J1394A/ B Wake up...
  • Page 21 5V/ 5V_SB Selección para USB: JUSBV1/JUSBV2/JUSBV4 JUSBV1/ 2/ 4 Contactos 1-2 on Contactos 2-3 on Conector del Panel Frontal: JPANEL1 PWR_LED (+) (-) HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==> Conector Infrarojo ==>...
  • Page 22 Contactos Asignacion Entrada del MIC Corriente del MIC RT Salida de Linea Reservado LFT Salida de Linea ⌦JF_AUDIO1 only support 2CH. Conector del Panel Frontal de Audio/ Jumper Block Jumper Setting La senal de salida de linea del Audio Contacto 5 & 6 encamina al conector de la salida de linea Contacto 9 &...
  • Page 23 Quite el cable JCMOS1 de corriente Contactos del AC 2-3 cerrado Encienda Reconfigure la contrasena deseada o borre datos CMOS Selección de Frecuencia: JCLK3 Abierto ==> 133/166MHz Cerrado ==> 100MHz JCLK3 Conector de la Carcasa Abierta: JC1 Selección CNR Codec Primario/ Secundario: J_CODECSEL J_CODECSEL Contacto Contacto...
  • Page 24 Conector Digital de Audio: J_SPDIF1 SPDIF_OUT VCC5 J_SPDIF1 Conectores del Panel Trasero JKBMS1 JUSBLAN1 JPRNT1 LAN(Opcional) Raton PS/2 Paralelo Teclado COM1 PS/2 JCOM1 Estado del Indicador LED del puerto LAN Estado Normal Velocidad Indicador Derecho: Verde 10Mbps Indicador Izquierdo: Nada Indicador Derecho: Verde 100Mbps Indicador Izquierdo: Naranja...
  • Page 25: Deutsch

    Deutsch M7NCG Features(for V 1.3) Unterstützung für AMD Prozessor(Sockel462 ) bis zu XP 3000+. FSB mit 200/266MHz.. Chipsatz Northbridge: IGP. Southbridge: MCP-T/ MC . 800Mb/s Hohe Geschwindigkeit : Hyper-Transport -Interface zu den MCP-T Chipsatz. Hauptspeicher Unterstützung für 3 DDR Geräte.
  • Page 26: Verpackungsinhalt

    On Board Peripherals 1 Floppy-Port mit Unterstützung für 2 Diskettenlaufwerke.(360KB, 720KB, 1.2MB, 1.44MB und 2.88MB) 2 serielle Schnittstellen. 1 parallele Schnittstelle mit Unterstützung für SPP/EPP/ECP-Modus. Unterstützung für PS/2-Maus und PS/2 -Tastatur. Unterstützung für sechs USB2.0-Ports. (hintenX4, vornX2) BIOS Unterstützung für AWARD legal Bios. Unterstützung für APM1.2.
  • Page 27: Layout Des M7Ncg

    Layout des M7NCG JKBMS1 JKBV1 JUSBLAN1 JCOM1 JUSBV2 JPRNT1 JCLK3 JVGA1 JSPKR1 Winbond SP-OUT JLIN1 LINE-IN JGAME1 JMIC1 MIC-IN JNFAN1 Chip Codec J_CODECSEL J1394A JCFAN1 PCI1 MCP-T PCI2 PCI3 1394A Chip JUSB1 JUSB2 JUSBV1 J1394B FDD1 JATXPWER1 IDE2 IDE1 BAT1...
  • Page 28: Installation Der Cpu

    Installation der CPU Ziehen Sie den Hebel seitwärts von der Sockel und neigen Sie ihn um 90-Grad nach oben. Suchen Sie Pin A im Sockel und den weißen Punkt oder die Abschnittkante in der CPU. Passen Sie Pin A mit dem weißen Punkt/der Abschnittkante zusammen und legen Sie danach die CPU ein.
  • Page 29: Ddr-Dimm-Modules: Dimmb1/Dimmb2/ Dimma1

    DDR-DIMM-Modules: DIMMB1/DIMMB2/ DIMMA1 Für Dual-Kanal DDR(128bit) mindenstens zwei oder mehr DIMM-Modules installieren. (Der Speicher mußt in der Kombination von DIMMA und DIMMB installiert werden.) DRAM Zugriffszeit: 2.5V unbuffered DDR 200/266/333/400 MHz Typen erfordert. DRAM Typen: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184 pin) DIMM-Sockel DDR-Module Standort...
  • Page 30: Jumper, Header, Anschlüsse & Slots

    Hardware-skalierbare Riser-Card-Schnittstelle, welche nur Audio, Netzwerk und Modem unterstützt. Peripheral Component Interconnect Slots: PCI1-3 Dieses Motherboard ist mit 3 standardmäßigen PCI-Slots ausgestattet. PCI steht für Peripheral Component Interconnect und bezieht sich auf einem Busstandard für Erweiterungskarten, der den älteren ISA-Busstandard in den meisten Schnittstellen ersetzt hat.
  • Page 31 Wake On LAN Header: JWOL1 JWOL1 Front USB Header: JUSB1/ JUSB2 Pin Beschreibung Pin Beschreibung JUSB1/2 Front 1394 Header: J1394A/ J1394B Pin Beschreibung Pin J1394A/ B 5V/ 5V_SB Auswahl für USB: JUSBV1/JUSBV2/JUSBV4 JUSBV1/ 2/ 4 Pin 1-2 geschlossen Pin 2-3 geschlossen Erwachen Grund 5V_SB...
  • Page 32 Anschlüsse auf der Vorderseite: JPANEL1 PWR_LED (+) (-) HLED ==> Lautsprecheranschl. HLED ==> Festplattenanzeige ==> Reset-Taste ==> Infrarotanschl. ==> Sleep-Taste PWR_LED ==> Stromanzeige EIN/ AUS ==> Ein-/ Ausschalttaste Audio Subsystem: JF_AUDIO1/ JCDIN1 JF_AUDIO1 JAUDIO1 (Front Audio Header) (Front Audio Header) Beschreibung Mic-In Mic Power...
  • Page 33 Audio-Anschl sse f r die Vorderseite/ Jumper-Block Jumper-Einstellen Audio-Ausgang-Singals werden zu der Audio- Pin 5 und 6 Ausgang-Anschluss an der R ckwand geleitet. Pin 9 und 10 Audio-Ausgang- und Mic-In-Singals sind verf gbar Kein Jumper f r Audio-Anschl sse an der Vorderseite. installieren Clear CMOS Jumper: JCMOS JCMOS1...
  • Page 34 Frequenz Auswahl: JCLK3 geoffnet==> 133/166MHz geschlossen==> 100MHz JCLK3 Case Open Connector: JC1 Gehause-Offnen Case Open Signal Signal Grund Ground Auswahl für Primär/Sekundär CNR-Codec: J_CODECSEL J_CODECSEL Pin 1-2 Pin 2-3 Digital-Audio-Anschluss: J_SPDIF1 SPDIF_OUT VCC5 J_SPDIF1 Beschreibung Onboard-Primar- Codec CNR-Primar-Codec Grund...
  • Page 35 Anschlüsse auf der Rückseite RJ45USB1 JKBMS1 LAN(optional) PS/2- Maus PS/2- COM1 COM1 Tastatur JCOM1 Die Signallampe für Lan-Port Status: Status Geschwindigkeit Lampe von rechts: grün 10Mbps Lampe von links: kein Lampe von rechts: grün 100Mbps Lampe von links: orange JPRNT1 JGAME1_USB1 Parallel Game-Port...
  • Page 36: Français

    Français M7NCG Particularités (pour V1.3) : CPU : Soutient le processeur d'AMD ® Socket462 jusqu'à XP 3000 +. Dirigeant à Autobus de Côté 200/266/333MHz de Devant. Chipset : Pont du Nord : IGP Chipset. Pont du Sud : MCP-T/MCP Chipset.
  • Page 37 À bord Périphériques : Soutient 360Ko, 720Ko, 1.2MB, 1.44MB et 2.88MB des conducteurs de disquette. Soutient 2 ports périodiques. Soutient 1 multi-mode le port parallèle. (SPP/EPP/ECP mode) Soutient souris de PS/2 et clavier de PS/2. Soutient 2 ports d’USB2.0 en arrière et 4 ports d’USB2.0 en avant. (facultatif) BIOS : ACCORDENT le BIOS légal.
  • Page 38: Dessin D'm7Ncg

    Dessin d’M7NCG JKBMS1 JKBV1 JUSBLAN1 JCOM1 JUSBV2 JPRNT1 JCLK3 JVGA1 JSPKR1 Winbond SP-OUT JLIN1 LINE-IN JGAME1 JMIC1 MIC-IN JNFAN1 Chip Codec J_CODECSEL J1394A JCFAN1 PCI1 MCP-T PCI2 PCI3 1394A Chip JUSB1 JUSB2 JUSBV1 J1394B FDD1 JATXPWER1 IDE2 IDE1 BAT1 J_SPDIF1...
  • Page 39: 9Th Touch Tm Is Nice Touch

    9th Touch is NICE TOUCH [9th Touch] means users could enjoy the speed, safety & convenience when respective booting requirement. The easiest way is just to touch 「F9」 function key during booting procedure to choose any device you like to boot for the system. Forget about entering CMOS, rebooting activities.
  • Page 40: Bios Star -[ Flasher™ ]

    CMOS and do it. Flasher Step by Step 1. Download the latest BIOS file from the BIOSTAR website to a floppy disk. 2. Insert the disk that contains the newest BIOS file into the floppy drive. 3. Power ON the computer.
  • Page 41 6. Press " Arrow Up/Down " key to choose BIOS file, refer to Figure 2 Press [Enter] to load the BIOS from the floppy disk, refer to Figure 3. Figure 1 Figure 2...
  • Page 42 8. At the prompt "Are you sure to flash (Y/N) ", press [Y] to flash BIOS or [N] to cancel the flashing process, refer to Figure 4. After pressing [Y], the flash starts to process, refer to Figure 5. Figure 3 Figure 4...
  • Page 43 10. A message " Flash done, Restart System (Y/N) " will appear if the system was successfully updated the BIOS, refer to Figure 6. 11. Press [Enter], then the flashing is done! Figure 6...
  • Page 44: Watchdog Technology

    Watchdog Technology It is important to know that when overclocking, the system can be at a vulnerable state. Therefore, the BIOSTAR Watchdog Technology was designed to protect your PC under dangerous over-clock situations. Any over-clocking that reaches the threshold settings, the Watchdog Technology will disable your system from rebooting in the BIOS setting.
  • Page 45: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning. PROBABLE System does not boot from hard disk drive, can be booted from CD-ROM drive.
  • Page 46: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
  • Page 47: Problemlösung

    Problemlösung MÖGLICHE URSACHE Das System hat keine Spannungsversorgung. Die Stromanzeige leuchtet nicht, der Lüfter im Inneren der Stromversorgung wird nicht eingeschaltet. Tastaturleuchten sind nicht an. MÖGLICHE URSACHE System funktioniert nicht. Tastaturleuchten sind Stromanzeige leuchtet, die Festplatte dreht sich. MÖGLICHE URSACHE Das System wird von der Festplatte nicht hochgefahren, vom CD-ROM-Treiber aber ja.
  • Page 48 26/02/2003...
