Summary of Contents for Biostar M7NCG Pro

  • Page 1 FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits designed provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    How to setup Jumper ... 5 CPU Installation ... 5 DDR-DIMM-Modules: DIMMB1-2, DIMMA1... 6 Jumpers, Headers, Connectors & Slots... 7 DEUTSCH ...14 Spezifikationen von M7NCG Pro ... 14 Verpackungsinhalt... 15 Einstellung der Jumper... 16 Installation der CPU... 16 DDR-DIMM-Modules: DIMMB1-2, DIMMA1... 17 Jumpers, Headers, Anschlüsse &...
  • Page 3: Layout Of M7Ncg Pro

    Layout of M7NCG Pro ※NOTE: ●represents the first pin.
  • Page 4: Component Index

    Component Index A. Power Source Selection for Keyboard and mouse (JKBV1) B. Power Source Selection for USB (JUSBV2) C. COM1-Header (JCOM1-HEADER) D. Back Panel Connector E. North Bridge Fan Header (JNFAN1) S. Digital Audio Connector (J_SPDIF1) F. Front Audio Header (JF_AUDIO1) G.
  • Page 5: English

    English M7NCG Pro Features A. Hardware Provides Socket-462. ® Supports the AMD processor up to XP 3000+. Front Side Bus at 200/266/333 MHz. Chipset North Bridge: nFORCE2 IGP. South Bridge: MCP-T Chipset. High Speed 800Mb/s Hyper-Transport interface to the MCP-T.
  • Page 6: Package Contents

    Supports 6 channels. On Board Peripherals 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes. Supports 2 VGA ports. (For NVIDIA nView) Supports 1 parallel port. (SPP/EPP/ECP mode) Supports 1 horizontal audio port. Supports 1 LAN port. (optional) Supports PS/2 mouse and PS/2 keyboard.
  • Page 7: How To Setup Jumper

    How to setup Jumper The illustration shows how jumpers are setup. When the Jumper cap is placed on pins, the jumper is “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The illustration shows a 3-pin jumper whose pin 1and 2 are “close” when jumper cap is placed on these 2 pins.
  • Page 8: Ddr-Dimm-Modules: Dimmb1-2, Dimma1

    CPU Fan Headers: JCFAN1 Pin No. JCFAN1 System Fan Headers: JSFAN1 Pin No. JSFAN1 North Bridge Fan Header: JNFAN1 Pin No. JNFAN1 DDR-DIMM-Modules: DIMMB1-2, DIMMA1 For Dual-channel DDR (128-bit) high performance, at least 2 or more DIMM modules must be installed. (It has to be the combination of DIMMA and DIMMB.) With only one DIMM installed, the memory performs only at 64-bit.
  • Page 9: Jumpers, Headers, Connectors & Slots

    The first hard drive should always be connected to IDE1. Peripheral Component Interconnect Slots: PCI 1-5 This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits.
  • Page 10: Front Panel Connector: Jpanel1

    Front Panel Connector: JPANEL1 PWR_LED JPANEL1 (+) (-) HLED Assignment Function Speaker Connector Speaker HDD LED (+) Hard Drive HDD LED (-) Ground Reset Button Reset Control IrDA Connector IRTX Front USB Header: JUSB1/2 Assignment +5V(fused) USBP4- USBP4+ JUSB1/2 Wake On LAN Header: JWOL1 JWOL1 ON/OFF Assignment...
  • Page 11 Power Connectors: JATXPWER1 JATXPWER1 Front 1394 Header: J1394A/ J1394B J1394A/ J1394B Power Source Selection for Keyboard/ Mouse: JKBV1 JKBV1 Assignment Pin 1-2 close +5V Standby Voltage Pin 2-3 close Note: In order to power-on keyboard and mouse function, “JKBV1” jumper cap should be placed on pin 2-3.
  • Page 12 Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV4 JUSBV1/JUSBV2/ Assignment JUSBV4 Pin 1-2 close +5V Standby Voltage Pin 2-3 close Note: In order to power-on USB devices function, “JUSBV1/JUSBV2/ JUSBV4” jumper cap should be placed on pin 2-3 respectively. Clear CMOS Jumper: JCMOS JCMOS Pin 1-2 Close Pin 2-3 Close...
  • Page 13 3. Wait for five seconds. 4. Set the jumper to “Pin 1-2 Close”. 5. Power on the AC. 6. Reset your desired password or clear the CMOS data. Case Open Connector: JC1 CD-ROM Audio-In Header: JCDIN1 JCDIN1 Front Panel Audio Header: JF_AUDIO1 JF_AUDIO1 Assignment Mic In/ Center...
  • Page 14 COM1 Header: JCOM1-HEADER1 Assignment RIN1 DOUT2 Ground DOUT1 -XRI1 System Operation Mode: JCLK3 JCLK3 Pin 1-2 Open Pin 1-2 Close Note: When overclock function failed and system is unable to boot-up, please follow the instruction below: Turn off the system. Closed the JCLK3 jumper.
  • Page 15: Back Panel Connectors

    Back Panel Connectors JKBMS1 JUSBLAN1 JPRNT1 JGAME1 PS/2 LAN(Optional) Mouse Parallel Game Port PS/2 Speaker Line In VGA2 VGA1 Keyboard JVGA2 JVGA1...
  • Page 16: Deutsch

    Deutsch Spezifikationen von M7NCG Pro A. Hardware Unterstützung für Sockel 462. Unterstützung für den AMD FSB mit 200/266/333 MHz. Chipsatz Northbridge: nFORCE2 IGP. Southbridge: MCP-T Chipset. 800Mb/s Hohe-Geschwindigkeit : Hyper-Transport -Interface zu den Chipsatz MCP-T. Hauptspeicher Unterstützung für 3 DDR Geräte.
  • Page 17: Verpackungsinhalt

    Onboard-Audio Chip: ALC650. Entspricht die Spezifikation von AC’97. AC99 2.2/2.3 Interface. Unterstützung für 6-Kanal. Onboard-Peripheriegeräte 1 Floppy-Port mit Unterstützung für 2 Diskettenlaufwerke.(360KB, 720KB, 1.2MB, 1.44MB und 2.88MB) 2 VGA-Schnittstellen. (Für Nvidia nView) 1 parallele Schnittstelle. (SPP/EPP/ECP-Modus) 1 horizontales Audio-Port. 1 LAN-Port. (optional) Unterstützung für PS/2-Maus und PS/2-Tastatur.
  • Page 18: Einstellung Der Jumper

    Einstellung der Jumper Die Abbildung verdeutlicht, wie Jumper eingestellt werden. Pins werden durch die Jumper-Kappe verdeckt, ist der Jumper ”geschlossen”. Keine Pins werden durch die Jumper-Kappe verdeckt, ist der Jumper “geöffnet”. Die Abbiildung zeigt einen 3-Pin Jumper dessen Pin1 und Pin2 ”geschlossen“ sind, bzw. es befindet sich eine Jumper-Kappe auf diesen beiden Pins.
  • Page 19: Ddr-Dimm-Modules: Dimmb1-2, Dimma1

    CPU-Lüfter Headers: JCFAN1 JCFAN1 System-Lüfter Headers: JSFAN1 JSFAN1 Northbridge-Lüfter Header: JNFAN1 JNFAN1 DDR-DIMM-Modules: DIMMB1-2, DIMMA1 Für Dual-Kanal DDR (128-Bit) High-Performance, muss man mindestens 2 oder mehr DIMM-Module installieren. (Es ist unbedingt, daß man DIMMA mit DIMMB als ein Paar benutzt.) Wenn man nur ein DIMM installiert, funktioniert der Spreicher nur 64-Bit.
  • Page 20: Jumpers, Headers, Anschlüsse & Slots

    4 Festplatten angeschlossen werden können. Die erste Festplatte sollte immer an IDE1 angeschlossen werden. Peripheral Component Interconnect Slots: PCI1-5 Dieses Motherboard ist mit 5 standardmäßigen PCI-Slots ausgestattet. PCI steht für Peripheral Component Interconnect und bezieht sich auf einem Busstandard für Erweiterungskarten, Schnittstellen ersetzt hat.
  • Page 21 Anschlüsse für die Vorderseite: JPANEL1 PWR_LED JPANEL1 Belegung Funktion Lautsprecher Kein Anschluss Kein Lautsprecher HDD LED (+) Festplatte HDD LED (-) Masse Zurücksetzn- Knopf Reset Control Kein Kein IrDA- Anschluss IRTX Front USB Header: JUSB1/2 +5V(geschmelzt) JUSB1/2 Wake On LAN Header: JWOL1 JWOL1 ON/OFF (+) (-)
  • Page 22 Stromversorgungsanschluss: JATXPWER1 JATXPWER1 Front 1394 Header: J1394A/ J1394B J1394A/ J1394B *Schlüsse: Kein Pin. Auswahl von Stromversorgungsmodi für Tastatur/ Maus: JKBV1 JKBV1 Beschreibung Pin 1-2 geschlossen +5V reservierte Spannung Pin 2-3 geschlossen Anmerkung: Um die “power-on by Keyboard and Mouse“ Funktion zu behandeln, sollen Pin2-3 durch die Jumperkappe verdeckt werden.
  • Page 23 Auswahl von Stromsversorgungsmodi für USB: JUSBV1/ JUSBV2/ JUSBV4 JUSBV1/JUSBV2/ Beschreibung JUSBV4 Pin 1-2 geschlossen +5V_SB Pin 2-3 geschlossen Anmerkung: Um die “power-on by USB-Geräte” Funktion zu behandeln, sollen pin2-3 von JUBV1/ JUBV2/ JUSBV4 durch die. Jumper zum Löschen CMOS: JCMOS JCMOS Pin 1-2 geschlossen Pin 2-3 geschlossen...
  • Page 24 ※ Prozeß zum Löschen des CMOS: 1. Ausschalten Sie den AC-Netzstecker. 2. Lassen Sie Pin 2-3 von JCOMS1 geshclossen sein. 3. Bitte warten Sie 15 Sekunden. 4. Lassen Sie Pin 1-2 von JCOMS1 geshclossen sein. 5. Schließen Sie den AC-Netzstecker an. 6.
  • Page 25 *Reserviert: Nicht in Gebrauch Digital Audio Anschluss: J_SPDIF1 J_SPDIF1 COM1 Header: JCOM1-HEADER1 Belegung RIN1 DOUT2 Masse DOUT1 -XRI1 System Operation Modus: JCLK3 JCLK3 Pin 1-2 geschlossen Pin 1-2 geöffnet Anmerkung: Wenn “Überspanng Funktion” nicht gelungen ist folgen Sie bitte die Instruktion darunter: Bitte vausschalton Sie den AC-Notzstecker.
  • Page 26 Schließen Sie den AC-Netzstecker wieder. Anschlüsse für die Rückwand JKBMS1 JUSBLAN1 JPRNT1 JGAME1 LAN(optional) PS/2- Maus Parallel Game-Port PS/2- Lautsprecher- Line-In VGA2 VGA1 Tastatur Ausgang JVGA2 JVGA1...
  • Page 27: Dual Vga Port

    Dual VGA Port * Supporting when using integrated NVIDIA VGA . Enter “Display Properties”, then click on “Advanced” and finally click on “GeForce4 MX Integrated GPU”, you will find the following functions: Standard: Display for only one monitor.
  • Page 28 Clone: Display the same view on the primary and secondary monitor. Horizontal Span: The view can be enlarged horizontally from the primary to the secondary monitor.
  • Page 29 Vertical Span: The view can be enlarged vertically from the primary to the secondary monitor. In addition, just like the “Horizontal Span”, this functionality also allows you to work two different tasks on two monitors (primary and secondary) simultaneously.
  • Page 30 Dual View: This functionality allows you to work two different tasks on two monitors (primary and secondary) simultaneously. For Dual View, you have to differentiate the primary and the secondary monitor: a. Connect the monitor cables to VGA ports. b. Enter OS. c.
  • Page 32: Studiofun

    StudioFun! Introduction StudioFun! is a media-player based on optimized GNU/Linux distribution. It plays DVD, VCD, MP3, Audio CD and various other known file formats. You can take snapshots of video and customize the saved images as screensavers. You can also store the images on USB mass storage devices like flash disks and USB floppy disks.
  • Page 33: Error Messages

    Installation This option will do the basic installation of the distribution. The installation works on pre-installed windows or GNU/Linux distribution. On selecting the ’installation’ option the installer boots and displays a dialog box indicating the space required and waits for a confirmation. Selecting Ok will continue the installation while selecting Cancel will terminate the installation and reboot the machine.
  • Page 34: Booting To Studiofun

    Recovery In case of a MBR corruption, this option should be used. It will automatically probe the hard disk master boot record and find out the installed operating system(s). On success it will re-install the boot loader with correct options in the MBR. Any custom boot loader option specified from other GNU/Linux installations will get over written by the newly probed one.
  • Page 35: Media Control

    After complete boot up, you get to the main Desktop screen. The following section is a complete description of the Desktop application. Desktop This is the main shell of the StudioFun software. It basically comprises of two categories, one is the main "media control" part and the other is the "control panel". Media control The media control part of the Desktop has the following controls: This control will glow whenever a VCD is detected in a DVD/CD-ROM drive.
  • Page 36: Control Panel

    present in the DVD/CD-ROM drive. This control will glow whenever a DVD is detected in a DVD drive. The DVD will be auto-played only when it is put in to the drive when the Desktop (StudioFun! shell) is up and running, otherwise, the control will simply glow to inform the user about a DVD present in the DVD/CD-ROM.
  • Page 37 1. Select Region Clicking this icon will invoke the application for selection DVD region settings. Refer to section 5.2 Select DVD Region application for more details. 2. Screensaver Clicking this icon will invoke the screensaver application. Refer to section 5.3 Screensaver for more details.
  • Page 38: Software Details

    Software Details XINE XINE is a multimedia player. It plays back Audio CD, DVD, and VCD. It also decodes multimedia files like AVI, MOV, WMV, and MP3 from local disk drives. It interprets many of the most common multimedia formats available - and some of the uncommon formats, too.
  • Page 39 MPEG-Video (.mpv, .m2v) MPEG-Audio (.mp2, .mp3) WAV (.wav) Video Codecs MPEG 1/2 MPEG 4 (aka OpenDivX) MS MPEG 4 Chapter 5: Software Details 10 Windows Media Video 7 m. Motion JPEG • Remote Control support. • Usage of StudioFun! with CelomaChrome skin Select VCD button to play a VCD disc Select DVD button to play a DVD disc Select CDDA button to play a Audio cd...
  • Page 40: Select Region

    j. Select hide button to hide the control panel of the player m. k. Select menu button to use menu’s while playing DVD l. Select control button to adjust brightness / color Select setup button to modify the settings of the player Select f.scr button to show the video output of the player in full screen mode Select snap button to take a snapshot of the currently...
  • Page 41: Screensaver

    Screensaver Screensaver The xscreensaver daemon waits until the keyboard and mouse have been idle for a period, and then runs a graphics demo chosen at random. The demo is terminated as soon as there is any mouse or keyboard activity. The xscreensaver-demo program is the graphical user interface to xscreensaver.
  • Page 42: Display Settings

    2. Only one Screen Saver: When user chooses this option, screensaver displays only one graphics demo. 3. Blank Screen Only: When user chooses this option, screensaver only blanks the screen instead of displaying the graphics demo. 4. Disable Screen Saver: When user chooses this option, screensaver is disabled. •...
  • Page 43: File Manager

    three resolutions. • 640x480 • 800x600 • 1024x768 The current resolution of the Display will be selected by default. It requires restart of the StudioFun to reflect the changes made. File Manager Overview File manger is an utility to copy files from deferent devices to hard disk and vice versa. User can copy files from devices such as, floppy, cdrom and flashdisk to hard disk.
  • Page 45: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 46: Problemlösung

    Problemlösung MÖGLICHE URSACHE Das System hat keine Spannungsversorgung. Die Stromanzeige leuchtet nicht, der Lüfter im Inneren Stromversorgung wird eingeschaltet. Tastaturleuchten sind nicht an. MÖGLICHE URSACHE System funktioniert nicht. Tastaturleuchten sind an, die Stromanzeige leuchtet, die Festplatte dreht sich. MÖGLICHE URSACHE Das System wird von der Festplatte nicht hochgefahren, vom CD-ROM-Treiber aber ja.
  • Page 47 05/21/2003...
