M7NBA BIOS Setup
BIOS Setup....................................................................................... 1
1 Main Menu.................................................................................................... 3
2 Standard CMOS Features.............................................................................. 6
3 Advanced BIOS Features.............................................................................. 9
4 Advanced Chipset Features......................................................................... 12
5 Integrated Peripherals ................................................................................. 16
6 Power Management Setup........................................................................... 21
7 PnP/PCI Configurations .............................................................................. 24
8 PC Health Status ......................................................................................... 26
9 Frequency Control....................................................................................... 28
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iDEQ 200N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Biostar iDEQ 200N

Summary of Contents for Biostar iDEQ 200N

  • Page 1: Table Of Contents

    M7NBA BIOS Setup BIOS Setup... 1 1 Main Menu... 3 2 Standard CMOS Features... 6 3 Advanced BIOS Features... 9 4 Advanced Chipset Features... 12 5 Integrated Peripherals ... 16 6 Power Management Setup... 21 7 PnP/PCI Configurations ... 24 8 PC Health Status ...

  • Page 2: Bios Setup

    M7NBA BIOS Setup BIOS Setup Introduction This manual discussed Award™ Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off.
  • Page 3 M7NBA BIOS Setup PCI Bus Support This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR SDRAM (Double Data Rate Synchronous DRAM) are supported. Supported CPUs This AWARD BIOS supports the AMD Using Setup In general, you use the arrow keys to highlight items, press <Enter>...

  • Page 4: Main Menu

    M7NBA BIOS Setup 1 Main Menu Once you enter Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu. !! WARNING !! The information about BIOS defaults on manual (Figure 1,2,3,4,5,6,7,8,9) is just for reference, please refer to the BIOS...
  • Page 5 M7NBA BIOS Setup Input/ Output features. Power Management Setup This submenu allows you to configure the power management features. PnP/PCI Configurations This submenu allows you to configure certain “Plug and Play” and PCI options. PC Health Status This submenu allows you to monitor the hardware of your system. Frequency/ Voltage Control This submenu allows you to change CPU Vcore Voltage and CPU/PCI clock.
  • Page 6 M7NBA BIOS Setup Set User Password If the Supervisor Password is not set, then the User Password will function in the same way as the Supervisor Password. If the Supervisor Password is set and the User Password is set, the “User” will only be able to view configurations but will not be able to change them. Save &...

  • Page 7: Standard Cmos Features

    M7NBA BIOS Setup 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp> or <PgDn> keys to select the value you want in each item. Figure 2.
  • Page 8 M7NBA BIOS Setup Main Menu Selections This table shows the selections that you can make on the Main Menu. Item Options Date mm : dd : yy Time hh : mm : ss IDE Primary Master Options are in its sub menu.
  • Page 9 M7NBA BIOS Setup Item Options Halt On All Errors No Errors All, but Keyboard All, but Diskette All, but Disk/ Key Base Memory Extended Memory Total Memory Description Select the situation in which you want the BIOS to stop the POST process and notify you.

  • Page 10: Advanced Bios Features

    M7NBA BIOS Setup 3 Advanced BIOS Features Figure 3. Advanced BIOS Setup Boot Seq & Floppy Setup First/ Second/ Third/ Boot Other Device These BIOS attempt to load the operating system from the device in the sequence selected in these items. The Choices: Floppy, LS120, HDD-0, SCSI, CDROM, HDD-1, HDD-2, HDD-3, ZIP100, USB-FDD, USB-ZIP, USB-CDROM, USB-HDD, LAN, HPT370, Disabled, Enabled.
  • Page 11 M7NBA BIOS Setup Cache Setup External Cache This option you to enable or disable “Level 2” secondary cache on the CPU, which may improve performance. The Choices: Enabled (default) Disabled Virus Warning This option allows you to choose the Virus Warning feature that is used to protect the IDE Hard Disk boot sector.

  • Page 12: Apic Mode

    M7NBA BIOS Setup The Choices: 250 (default), 500,750,1000. Security Option This option will enable only individuals with passwords to bring the system online and/or to use the CMOS Setup Utility. System Setup (default) This will only apply if passwords are set from the Setup main menu. APIC Mode By selecting Enabled enables ACPI device mode reporting from the BIOS to the operating system.

  • Page 13: Advanced Chipset Features

    M7NBA BIOS Setup 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM. It also coordinates communications with the PCI bus. The default settings that came with your system have been optimized and therefore should not be changed unless you are suspicious that the settings have been changed incorrectly.
  • Page 14 M7NBA BIOS Setup CPU Interface Optimal (Default) This item allows you to use the most stable CPU/ FSB parameters. Aggressive This item allows you to use overclocked CPU/ FSB parameters. Memory Frequency Select “Auto” for best performance. The Choices: By SPD (Default), 50%, 60%, 66%, 75%, 80%, 83%, 100%, 120%, 125%, 133%, 150%, 166%, 200%, Auto.
  • Page 15 M7NBA BIOS Setup AGP Spread Spectrum This item allows you to select the AGP Spread Spectrum. The Choices: 0.5% (Default). Frame Buffer Size This item allows you to select the Frame Buffer Size. The Choices: 32M (Default), 8M, 16M, 64M, 128M, Disabled. AGP Aperture Size (MB) Select the size of the Accelerated Graphics Port (AGP) aperture.
  • Page 16 M7NBA BIOS Setup Video RAM Cacheable Enabling this option allows caching of the video RAM, resulting a better system performance. However, if any program writes to this memory area, a system error may result. The Choices: Disabled (default), Enabled.

  • Page 17: Integrated Peripherals

    M7NBA BIOS Setup 5 Integrated Peripherals Figure 5. Integrated Peripherals IDE Function Setup The chipset contains a PCI IDE interface with support for two IDE channels. Select “Enabled” to activate the first and / or second IDE interface. If you install a primary and / or secondary add-in IDE interface, select “Disabled”...
  • Page 18 M7NBA BIOS Setup IDE Primary / Secondary Master / Slave UDMA Ultra DMA/100 functionality can be implemented if it is supported by the IDE hard drives in your system. As well, your operating environment requires a DMA driver (Windows 95 OSR2 or a third party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/100, select Auto to enable BIOS support.

  • Page 19: Onchip Usb

    M7NBA BIOS Setup Init Display First This item allows you to decide to active whether PCI Slot or on-chip VGA first. The Choices: Onboard/AGP, PCI Solt (default). OnChip USB This item allows you to set the onchip USB. The Choices: V1.1+V2.0 (default), Disabled, V1.1. USB Keyboard Support The default value is Disabled.
  • Page 20 M7NBA BIOS Setup chip. The Choices: Normal, ASKIR, IrDA (default). RxD, TxD Active This item allows you to determine which Infrared (IR) function of onboard I/O chip. The Choices: Hi / Lo (default), Hi / Hi, Lo / Hi, Lo / Lo. IR Transmission Delay This item allows you to enable/disable IR transmission delay.
  • Page 21 M7NBA BIOS Setup The Choices: 201 (default), 209, Disabled. Midi Port Address Midi Port Base I/O Address. The Choices: 330 (default), 300, 290, Disabled. Midi Port IRQ This determines the IRQ in which the Midi Port can use. The Choices: 10 (default), 5...

  • Page 22: Power Management Setup

    M7NBA BIOS Setup 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI function This item displays the status of the Advanced Configuration and Power Management (ACPI).

  • Page 23: Soft-Off By Pwr-Bttn

    M7NBA BIOS Setup There are four options of Power Management, three of which have fixed mode settings Min. Power Saving Minimum power management. Suspend Mode = 1 hr. HDD Power Down = 15 min Max. Power Saving Maximum power management only available for sl CPU’s. Suspend Mode = 1 min.

  • Page 24: Pwron After Pwr-Fail

    M7NBA BIOS Setup Soft-Off state when the system has “hung.” The Choices: Delay 4 Sec, Instant-Off (default). WOL (PME#) From Soft-Off This item allows you to enable or disable the WOL (PME#) From Soft-Off. The Choices: Disabled (Default), Enabled. WOR (RI#) From Soft-Off This item allows you to enable or disable the WOR (RI#) From Soft-Off.

  • Page 25: Pnp/Pci Configurations

    M7NBA BIOS Setup 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
  • Page 26 M7NBA BIOS Setup non-PnP ISA add-on cards. PCI / ISA PnP signifies that a resource is assigned to the PCI Bus or provides for ISA PnP add-on cards and peripherals. The Choices: Disabled (default), Enabled. Resources Controlled By By Choosing “Auto(ESCD)” (default), the system BIOS will detect the system resources and automatically assign the relative IRQ and DMA channel for each peripheral.By Choosing “Manual”, the user will need to assign IRQ &...

  • Page 27: Pc Health Status

    M7NBA BIOS Setup 8 PC Health Status Figure 8. PC Health Status Current CPU Temperature Show you the current CPU temperature. Current JCFAN1 Speed This field displays the current CPUFAN1 speed. Current SYSFAN Speed This field displays the current SYSFAN speed. Current JCFAN2 Speed This field displays the current CPUFAN2 speed.
  • Page 28 M7NBA BIOS Setup Show H/W Monitor in POST If you computer contain a monitoring system, it will show PC health status during POST stage. The item offers several delay time to select you want. The Choices: Enabled (default), Disabled.

  • Page 29: Frequency Control

    M7NBA BIOS Setup 9 Frequency Control Figure 9. Frequency Control CPU Voltage Regulator This item allows you to select CPU Voltage Regulator. The Choices: Default (default), -0.025V, -0.050V, -0.075V, -0.100V, +0.025V, +0.050V, +0.075V. AGP Voltage Regulator This item allows you to select AGP Voltage Regulator. The Choices: 1.5V (Default), 1.6V, 1.7V, 1.8V.
