FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are
designed
to
provide
reasonable
protection
against
harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in
a particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied
of
warranties
merchantability or fitness for any purpose. Further the vendor reserves
the right to revise this publication and to make changes to the contents
here of without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice
and we will not be responsible for any mistakes found in this user's
manual. All the brand and product names are trademarks of their
respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7NCD Ultra and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar M7NCD Ultra

  • Page 1 FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits designed provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    How to setup Jumper ... 5 CPU Installation ... 5 DDR DIMM Modules: DIMMB1-2, DIMMA1 ... 6 Jumpers, Headers, Connectors & Slots... 7 DEUTSCH ...13 Spezifikationen von M7NCD Ultra ... 13 Verpackungsinhalt... 14 Einstellung der Jumper... 15 Installation der CPU... 15 DDR-DIMM-Modules: DIMMB1-2, DIMMA1... 16 Installation von DDR-Modul ...
  • Page 3: Layout Of M7Ncd Ultra

    Layout of M7NCD Ultra ※NOTE: ●represents the first pin.
  • Page 4: Component Index

    Component Index A. 5V/5VSB Selection for Keyboard and mouse (JKBV1) B. Power Source Selection for USB (JUSBV2) C. Back Panel Connector D. Frequency Selection (JCLK3) E. North Bridge Fan Header (JNFAN1) Q. Clear CMOS Function (JCMOS) F. Accelerated Graphics Port Slot (AGP1) G.
  • Page 5: English

    English M7NCD Ultra Features A. Hardware Provides Socket-462. ® Supports the AMD processor up to XP 3200+. Front Side Bus at 266/333/400 MHz. Chipset North Bridge: nFORCE2 SPP. South Bridge: MCP. High Speed 800Mb/s Hyper-Transport interface to the MCP. Main Memory Supports up to 3 DDR devices.
  • Page 6: Package Contents

    On Board Peripherals a. Rear side 2 serial ports. 1 parallel port. (SPP/EPP/ECP mode) Audio ports in horizontal position. 1 LAN port. (optional) PS/2 mouse and PS/2 keyboard. 2 USB2.0 ports. b. Front Side 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes. 4 USB2.0 ports.
  • Page 7: How To Setup Jumper

    How to setup Jumper The illustration shows how jumpers are setup. When the Jumper cap is placed on pins, the jumper is “close”. If no jumper cap is placed on the pins, the jumper is ”open”. The illustration shows a 3-pin jumper whose pin 1and 2 are “close” when jumper cap is placed on these 2 pins.
  • Page 8: Ddr Dimm Modules: Dimmb1-2, Dimma1

    CPU Fan Header: JCFAN1 Pin No. JCFAN1 System Fan Header: JSFAN1 Pin No. JSFAN1 North Bridge Fan Header: JNFAN1 Pin No. JNFAN1 DDR DIMM Modules: DIMMB1-2, DIMMA1 For Dual-channel DDR (128-bit) high performance, at least 2 or more DIMM modules must be installed. (It has to be the combination of DIMMA and DIMMB.) With only one DIMM installed, the memory performs only at 64-bit.
  • Page 9: Jumpers, Headers, Connectors & Slots

    The first hard drive should always be connected to IDE1. Peripheral Component Interconnect Slots: PCI 1-5 This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards. This PCI slot is designated as 32 bits.
  • Page 10 Assignment JSATA1/ JSATA2 Power Connectors: JATXPWER1 JATXPWER1 Front USB Header: JUSB1/ JUSB2 Assignment +5V(fused) USBP4+ JUSB1/2 Wake On LAN Header: JWOL1 JWOL1 Assignment Ground Ground Ground Assignment Assignment +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK +5V_SB +12V...
  • Page 11: Front Panel Connector: Jpanel1

    Front Panel Connector: JPANEL1 PWR_LED JPANEL1 Assignment Function Speaker Connector Speaker HDD LED (+) Hard Drive HDD LED (-) Ground Reset Button Reset Control IrDA Connector IRTX Power Source Selection for Keyboard/ Mouse: JKBV1 JKBV1 Assignment Pin 1-2 close +5V Standby Voltage Pin 2-3 close Note: In order to power-on keyboard and mouse function, “JKBV1”...
  • Page 12 Power Source Selection for USB: JUSBV1/ JUSBV2/ JUSBV4 JUSBV1/JUSBV2/ Assignment JUSBV4 Pin 1-2 close +5V Standby Voltage Pin 2-3 close Note: 1. In order to power-on USB devices function, “JUSBV1/JUSBV2/ JUSBV4” jumper cap should be placed on pin 2-3 respectively. 2.
  • Page 13 ※ Clear CMOS Procedures: 1. Remove AC power line. 2. Set the jumper to “Pin 2-3 Close”. 3. Wait for five seconds. 4. Set the jumper to “Pin 1-2 Close”. 5. Power on the AC. 6. Reset your desired password or clear the CMOS data. Case Open Connector: JC1 CD-ROM Audio-In Header: JCDIN1 JCDIN1...
  • Page 14 System Operation Mode: JCLK3 JCLK3 Pin 1-2 Close Pin 1-2 Open Note: When overclock function failed and system is unable to boot-up, please follow the instruction below: Turn off the system. Closed the JCLK3 jumper. Turn on the system. Enter CMOS setup menu and load defaults settings. Turn off the system.
  • Page 15: Deutsch

    Deutsch Spezifikationen von M7NCD Ultra A. Hardware Unterstützung für Sockel 462. Unterstützung für den AMD FSB mit 266/333/400 MHz. Chipsatz Northbridge: nFORCE2 SPP. Southbridge: MCP. Hauptspeicher Unterstützung für 3 DDR Geräte. Unterstützung für 266/333/400MHz (ohne ECC) DDR Geräte. 128-Bit High-Performance DDR400 mit der Twin-Bank Architektur.
  • Page 16: Verpackungsinhalt

    Onboard-Peripheriegeräte a. Rückwand 2 Seriell-Ports. 1 parallele Schnittstelle. (SPP/EPP/ECP-Modus) 1 horizontales Audio-Port. 1 LAN-Port. (optional) Unterstützung für PS/2-Maus und PS/2-Tastatur. 2 USB2.0-Ports. b. Vorderseite 1 Floppy-Port mit Unterstützung für 2 Diskettenlaufwerke.(360KB, 720KB, 1.2MB, 1.44MB und 2.88MB) 4 USB2.0-Ports. 1 Audio-Header für die Vonderseite Abmessungen ATX Form-Factor: 24.4 X 30.4cm (W X L) B.
  • Page 17: Einstellung Der Jumper

    Einstellung der Jumper Die Abbildung verdeutlicht, wie Jumper eingestellt werden. Pins werden durch die Jumper-Kappe verdeckt, ist der Jumper ”geschlossen”. Keine Pins werden durch die Jumper-Kappe verdeckt, ist der Jumper “geöffnet”. Die Abbiildung zeigt einen 3-Pin Jumper dessen Pin1 und Pin2 ”geschlossen“ sind, bzw. es befindet sich eine Jumper-Kappe auf diesen beiden Pins.
  • Page 18: Ddr-Dimm-Modules: Dimmb1-2, Dimma1

    CPU-Lüfter Headers: JCFAN1 JCFAN1 System-Lüfter Headers: JSFAN1 JSFAN1 Northbridge-Lüfter Header: JNFAN1 JNFAN1 DDR-DIMM-Modules: DIMMB1-2, DIMMA1 Für Dual-Kanal DDR (128-Bit) High-Performance, muss man mindestens 2 oder mehr DIMM-Module installieren. (Es ist unbedingt, daß man DIMMA mit DIMMB als ein Paar benutzt.) Wenn man nur ein DIMM installiert, funktioniert der Spreicher nur 64-Bit.
  • Page 19: Installation Von Ddr-Modul

    4 Festplatten angeschlossen werden können. Die erste Festplatte sollte immer an IDE1 angeschlossen werden. Peripheral Component Interconnect Slots: PCI1-5 Dieses Motherboard ist mit 5 standardmäßigen PCI-Slots ausgestattet. PCI steht für Peripheral Component Interconnect und bezieht sich auf einem Busstandard für Erweiterungskarten, Schnittstellen ersetzt hat.
  • Page 20 Dieser Chip bietet zwei Serial-ATA-Kanäle sowie einen Parallel-ATA-Kanal für bis zu zwei Geräte. Es entspriecht der Speczifikation von SATA 1.0. JSATA1/ JSATA2 Anschlüsse für die Vorderseite: JPANEL1 PWR_LED JPANEL1 Belegung Funktion Lautsprecher Kein Anschluss Kein Lautsprecher HDD LED (+) Festplatte HDD LED (-) Masse Zurücksetzn-...
  • Page 21 Wake On LAN Header: JWOL1 JWOL1 Stromversorgungsanschluss: JATXPWER1 JATXPWR1 Auswahl von Stromversorgungsmodi für Tastatur/ Maus: JKBV1 JKBV1 Beschreibung Pin 1-2 geschlossen +5V reservierte Pin 2-3 Spannung geschlossen Anmerkung: Um die “power-on by Keyboard and Mouse“ Funktion zu behandeln, sollen Pin2-3 durch die Jumperkappe verdeckt werden. Belegung +5V_SB Masse...
  • Page 22 Auswahl von Stromsversorgungsmodi für USB: JUSBV1/ JUSBV2/JUSBV4 JUSBV1/JUSBV2/ Beschreibung JUSBV4 Pin 1-2 geschlossen +5V_SB Pin 2-3 geschlossen Anmerkung: 1. Um die “power-on by USB-Geräte” Funktion zu behandeln, sollen pin2-3 von JUBV1/ JUBV2/ JUSBV4 durch die. 2. Für S3-Modus, die Jumper-Kappe von “JUSBV1/ JUSBV2/ JUSBV4”...
  • Page 23 ※ Prozeß zum Löschen des CMOS: 1. Ausschalten Sie den AC-Netzstecker. 2. Lassen Sie Pin 2-3 von JCOMS1 geshclossen sein. 3. Bitte warten Sie 15 Sekunden. 4. Lassen Sie Pin 1-2 von JCOMS1 geshclossen sein. 5. Schließen Sie den AC-Netzstecker an. 6.
  • Page 24 System Operation Modus: JCLK3 JCLK3 Pin 1-2 Geöffnet Pin 1-2 Geschlossen Anmerkung: Wenn “Überspanng Funktion” nicht gelungen ist folgen Sie bitte die Instruktion darunter: Bitte vausschalton Sie den AC-Notzstecker. Lassen Sie Pin 1-2 von JCLK3 geschlossen sein. Schließen Sie den AC-Notzstecker an. Betreten Sie “CMOS Setup Menü”...
  • Page 25: Watchdog Technology

    Watchdog Technology It is important to know that when overclocking, the system can be at a vulnerable state. Therefore, the BIOSTAR Watchdog Technology was designed to protect your PC under dangerous over-clock situations. Any over-clocking that reaches the threshold settings, the Watchdog Technology will disable your system from rebooting in the BIOS setting.
  • Page 26: Studiofun

    StudioFun! Introduction StudioFun! is a media-player based on optimized GNU/Linux distribution. It plays DVD, VCD, MP3, Audio CD and various other known file formats. You can take snapshots of video and customize the saved images as screensavers. You can also store the images on USB mass storage devices like flash disks and USB floppy disks.
  • Page 27: Error Messages

    Installation This option will do the basic installation of the distribution. The installation works on pre-installed windows or GNU/Linux distribution. On selecting the ’installation’ option the installer boots and displays a dialog box indicating the space required and waits for a confirmation. Selecting Ok will continue the installation while selecting Cancel will terminate the installation and reboot the machine.
  • Page 28: Booting To Studiofun

    Recovery In case of a MBR corruption, this option should be used. It will automatically probe the hard disk master boot record and find out the installed operating system(s). On success it will re-install the boot loader with correct options in the MBR. Any custom boot loader option specified from other GNU/Linux installations will get over written by the newly probed one.
  • Page 29: Media Control

    After complete boot up, you get to the main Desktop screen. The following section is a complete description of the Desktop application. Desktop This is the main shell of the StudioFun software. It basically comprises of two categories, one is the main "media control" part and the other is the "control panel". Media control The media control part of the Desktop has the following controls: This control will glow whenever a VCD is detected in a DVD/CD-ROM drive.
  • Page 30: Control Panel

    present in the DVD/CD-ROM drive. This control will glow whenever a DVD is detected in a DVD drive. The DVD will be auto-played only when it is put in to the drive when the Desktop (StudioFun! shell) is up and running, otherwise, the control will simply glow to inform the user about a DVD present in the DVD/CD-ROM.
  • Page 31: Select Region

    1. Select Region Clicking this icon will invoke the application for selection DVD region settings. Refer to section 5.2 Select DVD Region application for more details. 2. Screensaver Clicking this icon will invoke the screensaver application. Refer to section 5.3 Screensaver for more details.
  • Page 32: Software Details

    Software Details XINE XINE is a multimedia player. It plays back Audio CD, DVD, and VCD. It also decodes multimedia files like AVI, MOV, WMV, and MP3 from local disk drives. It interprets many of the most common multimedia formats available - and some of the uncommon formats, too.
  • Page 33 MPEG-Video (.mpv, .m2v) MPEG-Audio (.mp2, .mp3) WAV (.wav) Video Codecs MPEG 1/2 MPEG 4 (aka OpenDivX) MS MPEG 4 Chapter 5: Software Details 10 Windows Media Video 7 m. Motion JPEG • Remote Control support. • Usage of StudioFun! with CelomaChrome skin Select VCD button to play a VCD disc Select DVD button to play a DVD disc Select CDDA button to play a Audio cd...
  • Page 34: Select Region

    j. Select hide button to hide the control panel of the player m. k. Select menu button to use menu’s while playing DVD l. Select control button to adjust brightness / color Select setup button to modify the settings of the player Select f.scr button to show the video output of the player in full screen mode Select snap button to take a snapshot of the currently...
  • Page 35: Screensaver

    Screensaver Screensaver The xscreensaver daemon waits until the keyboard and mouse have been idle for a period, and then runs a graphics demo chosen at random. The demo is terminated as soon as there is any mouse or keyboard activity. The xscreensaver-demo program is the graphical user interface to xscreensaver.
  • Page 36: Display Settings

    2. Only one Screen Saver: When user chooses this option, screensaver displays only one graphics demo. 3. Blank Screen Only: When user chooses this option, screensaver only blanks the screen instead of displaying the graphics demo. 4. Disable Screen Saver: When user chooses this option, screensaver is disabled. •...
  • Page 37: File Manager

    three resolutions. • 640x480 • 800x600 • 1024x768 The current resolution of the Display will be selected by default. It requires restart of the StudioFun to reflect the changes made. File Manager Overview File manger is an utility to copy files from deferent devices to hard disk and vice versa. User can copy files from devices such as, floppy, cdrom and flashdisk to hard disk.
  • Page 39: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 40: Problemlösung

    Problemlösung MÖGLICHE URSACHE Das System hat keine Spannungsversorgung. Die Stromanzeige leuchtet nicht, der Lüfter im Inneren Stromversorgung wird eingeschaltet. Tastaturleuchten sind nicht an. MÖGLICHE URSACHE System funktioniert nicht. Tastaturleuchten sind an, die Stromanzeige leuchtet, die Festplatte dreht sich. MÖGLICHE URSACHE Das System wird von der Festplatte nicht hochgefahren, vom CD-ROM-Treiber aber ja.
  • Page 41 09/29/2003...
