EBOX-ALN3350/ ALJ3455
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBOX-ALJ3455 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DMP Electronics EBOX-ALJ3455

Summary of Contents for DMP Electronics EBOX-ALJ3455

  • Page 1 EBOX-ALN3350/ ALJ3455 User’s Guide...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the DMP Electronics Inc. Copyright 2019 DMP Electronics Inc.
  • Page 3 DMP Electronics Inc.
  • Page 4 This expense includes the cost of material and the cost of labor. Note: If there is other particular issue, not listed in the above conditions, both parties agreed to follow the General Law of Commerce with fair and reasonable discussion in handling and resolving the argument. DMP Electronics Inc.

  • Page 5: Table Of Contents

    32 Onboard Connectors Summary 33 Pin Assignments Chapter 5 38 Taking Care of EBOX 40 Troubleshooting Chapter 6 43 Terms and Condition 43 Warranty 43 Service and Support 43 Return Merchandise Authorization (RMA) Policy 43 Shipping Policy DMP Electronics Inc.
  • Page 6 EBOX-ALN3350/ ALJ3455 User Manual Chapter DMP Electronics Inc.

  • Page 7: Unpacking Ebox Mini Pc

    Power cable (available US, UK, EU, AU types ) VESA screw Note: The accessories are subject to change without immediate notice. Check before Use 1. EBOX-ALN3350/ ALJ3455 Unit 2. 40W Power adapter 3. Power cable 4. VESA screw DMP Electronics Inc.
  • Page 8 With FANLESS design, it’s ideal to be used in the environment where temperature demand is critical. OS such as Windows 10, Windows 10 IoT and Linux can be installed to meet ready-to-market demand and provide competitive advantages for customers. DMP Electronics Inc.
  • Page 9 EBOX-ALN3350/ ALJ3455 User Manual Chapter DMP Electronics Inc.
  • Page 10 Connection for external USB devices G: RJ-45 LAN Jack Realtek 8111H GigaLAN H: HDMI Output port Support HDMI display I: Mic in/Line out phone jack Realtek ALC662VD Mic in/Line out combo jack J: Power Jack Volt: DC 12V input only DMP Electronics Inc.

  • Page 11: Internal Description

    EBOX-ALN3350/ ALJ3455 User Manual Internal description Optional item MINIPCIE-WLAN-159H Wi-Fi/BT module info www.compactpc.com.tw DMP Electronics Inc.

  • Page 12: Appearance Diagram

    EBOX-ALN3350/ ALJ3455 User Manual Appearance Diagram DMP Electronics Inc.
  • Page 13 DC +12V standard input from power jack 0℃ to 60℃ (with Airflow)/ -10℃ Bootable Operating Temperature Dimension 115 x 115 x 48.5mm Mounting VESA 100 x 100mm Net Weight 660g Certifications CE, CF, VCCI OS Support Windows 10, Windows 10 IoT, Linux DMP Electronics Inc.

  • Page 14: Peripherals

    A: DC power Jack +12V@3.33A AC adapter with power cable is used for the power source Connecting the Monitor B: VGA Connection Connecting VGA display via VGA cable C: HDMI Connection Connect HDMI display via HDMI cable DMP Electronics Inc.
  • Page 15 Power LED lights up when the system turned on G: RJ-45 LAN RJ-45 LAN jack for Ethernet connection H: Microphone/ Earphone This connector can functions as audio Line out and Mic in jack with compatible cables and devices DMP Electronics Inc.
  • Page 16 EBOX-ALN3350/ ALJ3455 User Manual Chapter DMP Electronics Inc.

  • Page 17: Bios Reconfiguring

    1. AMI BIOS is used in EBOX; To reconfigure the hardware, press <Del> or <Esc> key to enter BIOS setup main menu. 2. Press “F3” key to load optimized defaults as below: 3. After setting, please press “F4” key to save & exit. DMP Electronics Inc.
  • Page 18 Press <F7> after boot up, a shortcut boot up device select menu will appear. Use direction key to select boot device and enter to boot up. BIOS COM Setting (RS-232/485/422) 1. Press <Del> or <Esc> key to enter BIOS menu after boot up, then press <Tab> and move to “Advanced” and “Super IO Configuration”. DMP Electronics Inc.
  • Page 19 EBOX-ALN3350/ ALJ3455 User Manual 2. Move to “Serial Port 1 Configuration”. 3. Next to Transmission Mode and select COM port Mode. 4. Press “F4” key to save & exit. DMP Electronics Inc.

  • Page 20: At Mode Setting (Auto Power On Function)

    EBOX-ALN3350 supports “Auto Power On function”, system will boot up automatically after power restored. 1. In BIOS Menu, move to “Chipset” and “South Cluster Configuration”. 2. Set “System State after Power Failure” as “Always On”, press “F4” key to save & exit. DMP Electronics Inc.

  • Page 21: Serial Port Console Redirection

    2. Set “Terminal Type” as “VT100+”, press “F4” key to save & exit. Terminal Type Emulation: [ANSI]: Extended ASCII char set; [VT100]: ASCII char set; [VT100+]: Extended VT100 to support color, function keys, etc. [VT-UTF8]: Uses UTF8 encoding to map Unicode chars onto 1 or more Bytes. DMP Electronics Inc.

  • Page 22: Os Selection

    Three optional settings: [Windows], [Intel Linux] and [MSDOS]. Note: User need to go to this item to select the OS mode before installing corresponding OS drivers, otherwise problems will occur when installing drivers. 3. After setting, press “F4” key to save & exit. DMP Electronics Inc.

  • Page 23: Pxe Diskless Boot Selection

    1. Move to “Advanced” for “Network Stack Configuration” and make further setting. 2. Set “Network Stack” Enabled and Ipv4 & Ipv6 PXE Support will appear. Note: Ipv4 & Ipv6 stand for Internet Protocol version 4 & 6, when set to Enabled, PXE diskless boot will be created. DMP Electronics Inc.

  • Page 24: Drivers Installation Guide

    Chipset driver: (Intel® Chipset Device Software) 1. Unzip the downloaded file and execute SetupChip.exe, then click “Next” to install: 2. A license agreement message will pop out, click Accept and install. 3. Click Finish to complete the setup process. DMP Electronics Inc.

  • Page 25: Graphic Driver

    1. Execute igxpin.exe and click “Next” to install: 2. A license agreement message will pop out, click Accept and install. 3. After installed, select “Yes, I want to restart this computer now” and click Finish to reboot. DMP Electronics Inc.

  • Page 26: Audio Driver

    EBOX-ALN3350/ ALJ3455 User Manual Audio driver: 1. Execute Setup.exe and installer will pop out, then click “Next” to install: 2. After installed, select “Yes, I want to restart this computer now” and click Finish to reboot. DMP Electronics Inc.

  • Page 27: Lan Driver

    EBOX-ALN3350/ ALJ3455 User Manual LAN driver: 1. Execute Setup.exe and InstallShield Wizard will pop out, then click “Next” to install: 2. After installed, click “Finish” to exit the wizard. DMP Electronics Inc.

  • Page 28: Txe Driver

    Trusted Execution Engine is a computer hardware technology primary goals are: Attestation of the authenticity of a platform and its operating system. 1. Execute SetupTXE.exe and click “Next” to install: 2. Check “I accept the term in the License Agreement and click “Next” to install. 3. Click “Finish” after successfully installed. DMP Electronics Inc.

  • Page 29: Irmt Driver

    1. Execute Setup.exe and click “Next” to install: 2. Check “I accept the term in the License Agreement and click “Next” to install. 3. Click “Finish” after successfully installed. DMP Electronics Inc.

  • Page 30: Ish Driver

    EBOX-ALN3350/ ALJ3455 User Manual ISH driver: (Intel® Integrated Sensor Solution) Intel® Integrated Sensor Solution installs Intel Integrated Sensor Solution driver to EBOX. 1. Double click SetupISS.exe and click install. 2. Click “Finish” after successfully installed. DMP Electronics Inc.
  • Page 31 EBOX-ALN3350/ ALJ3455 User Manual Chapter DMP Electronics Inc.

  • Page 32: Onboard Connectors Summary

    52-pin Ethernet x 2 G-LAN RJ45 connector 8-pin SIM card holder SIM card holder 6-pin Audio jack Mic in/Line out Combo connector 2-pin USB 3.0 x 4 USB 3.0 connector 9-pin COM (RS-232/485/422) 2.0mm 9-pin header 9-pin DMP Electronics Inc.

  • Page 33: Pin Assignments

    Hot Plug Detect TMDS_CLK+ J4: VGA – 15-pin D-Sub connector Pin # Signal Name Pin # Signal Name Pin # Signal Name HYSYNC VSYNC J5: SATAIII connector Pin # Signal Name Pin # Signal Name Receive- Transmit+ Receive+ Transmit- DMP Electronics Inc.
  • Page 34 PERP0 / MSATA_RXN 1.5V SMB_CLK SMB_DATA PERTN0 / MSATA_TXN PERTP0 / MSATA_TXP USB_D- USB_D+ 3.3V LED_WWAN# / NC 3.3V LED_WLAN# / NC LED_WPAN# / NC Reserved / NC 1.5V Reserved / NC Reserved / NC 3.3V MSATA_DET DMP Electronics Inc.
  • Page 35 LPC_CLK RESET# 3.3V PERN0 PERP0 1.5V SMB_CLK SMB_DATA PERTN0 PERTP0 USB_D- USB_D+ 3.3V LED_WWAN# / NC 3.3V LED_WLAN# / NC LED_WPAN# / NC Reserved / NC 1.5V Reserved / NC Reserved / NC 3.3V Reserved / NC DMP Electronics Inc.
  • Page 36 J13: RS-232/485/422 9-pin D-Sub connector Pin # Signal Name Pin # Signal Name DCD/ RS-422 TX-/ RS-485 DATA- DSR1 RXD/ RS-422 TX+/ RS-485 DATA+ RTS1 TXD1/ RS-422RX+ CTS1 DTR1/ RS-422RX- LEDS: POWER ON/ OFF LED Color State Blue Power On DMP Electronics Inc.
  • Page 37 EBOX-ALN3350/ ALJ3455 User Manual Chapter DMP Electronics Inc.

  • Page 38: Taking Care Of Ebox

    TV reception causing interference or poor signal display. When happens, relocate the EBOX by a suitable distance away from it. Do not drop EBOX from working table nor place heavy objects on top of it. DMP Electronics Inc.
  • Page 39 When a solid object falls or a liquid spills onto EBOX, turn off EBOX immediately; unplug the LAN and power cables. Contact a qualified person or your dealer to check the EBOX before you use it again. Always disconnect the power cord from the power source before cleaning EBOX. DMP Electronics Inc.

  • Page 40: Troubleshooting

    Go to “Save & Exit” menu using the Direction keys <↑↓> and choose the option “Restore Defaults”, then press <Enter>. A message dialog appears as seen below, hit “Y” key and presses <Enter> to save and recover to the factory setting. “Restore Defaults (Y/N)? Y” DMP Electronics Inc.
  • Page 41 If EBOX unit connected to a CD/ DVD or USB Drivers, remove all peripherals. And restart to check if Windows operating system starts properly. If EBOX unit continues to display the message “Operating system not found,” and Windows does not start, please contact nearest dealer for servicing. DMP Electronics Inc.
  • Page 42 EBOX-ALN3350/ ALJ3455 User Manual Chapter DMP Electronics Inc.

  • Page 43: Warranty

    6. A copy of the invoice for the RMA product(s) will also be shipped to Purchaser. 7. The freight of return to DMP Electronics Inc. is charged to the Purchaser's account and accompanied by an RMA number. Any Returns with freight collect will be refused and returned to you. After Repairing, the cost of freight will be paid by Seller.

This manual is also suitable for:

Ebox-aln3350Ebox-alj3455-8gbEbox-aln3350-8gbEbox-alj3455-4gbEbox-aln3350-4gb
