DMP Electronics DIN PC-336 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DIN PC-336x Series
User's Guide
DMP Electronics Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIN PC-336 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DMP Electronics DIN PC-336 Series

Summary of Contents for DMP Electronics DIN PC-336 Series

  • Page 1 DIN PC-336x Series User’s Guide DMP Electronics Inc.
  • Page 2 Copyright 2019 DMP Electronics Inc. Special Notice to Users DMP Electronics Inc. provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties of merchantability or fitness for any particular purpose with regard to this manual, the software, or such other information.
  • Page 3 DIN PC-336x Series User Manual Trademarks Acknowledgment is the registered trademarks of DMP Electronics Inc. Other brand names, product names or trade names appearing in this document are the properties and registered trademarks of their respective owners. All names mentioned herewith are served for identification purpose only.
  • Page 4 Do not use the modem or a telephone to report a gas leak in the vicinity of the leak.  USB connectors are supplied with Limited Power Sources. O NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS NCASING OF THIS PRODUCT LEASE CONTACT YOUR NEAREST DEALER FOR SERVICING FROM QUALIFIED TECHNICIAN DMP Electronics Inc.
  • Page 5 DMP Electronics Inc.
  • Page 6 Note: If there are other particular issues not listed in the above conditions, both parties agree to follow the General Law of Commerce with fair and reasonable discussion in handling and resolving the argument. DMP Electronics Inc.

  • Page 7: Table Of Contents

    Chapter 5 32 Taking Care of Your DIN PC 33 Cleaning Your DIN PC 34 Troubleshooting Chapter 6 37 Terms and Conditions 37 Warranty 37 Service and Support 37 Return Merchandise Authorization (RMA) Policy 37 Shipping Policy DMP Electronics Inc.
  • Page 8 DIN PC-336x Series User Manual Chapter DMP Electronics Inc.

  • Page 9: Unpacking Your Din Pc

    Item No. Description DIN PC-336x Series DIN Rail Mountable PC 3pin Plug-In Type Vertical Terminal Block Note: The accessories are subject to change without immediate notice. Check Before Use 1. DIN PC-336x Series Unit 2. 3pin Terminal Block DMP Electronics Inc.
  • Page 10 With DIN rail form factor, it supports DIN rail in top hat rail section EN 50022 version. All DIN PC-336x Series’ interfaces are on the front side, so it can be cabled up easily. The DIN PC-336x Series is an ideal choice as the front end embedded controllers for industrial automation applications. DMP Electronics Inc.
  • Page 11 DIN PC-336x Series User Manual Chapter DMP Electronics Inc.

  • Page 12: Din Pc-336X Series Overview

    K: VGA port Integrated Graphics Chip/ D-Sub 15-pin Rear and side view L: DIN Rail Mounting Clip M: Line out N: Mic in ※ DIN PC support Mic in/ Line out as option, please contact your local sales representative. DMP Electronics Inc.
  • Page 13 Reserved for SATA DOM O: USB 2.0 port Reserve for WLAN Dongle DIN Rail Information DIN PC-336x Series supports DIN rail in top hat rail section EN 50022 version. Please see dimension (mm) in picture shown below: DMP Electronics Inc.

  • Page 14: System Specifications

    ※ mSATA support (mSATA to SATA adapter equired) Peripheral USB 2.0 x 3 (External: 2 ports; Internal: 1 port) SD Card slot x 1 (Internal) Serial ports x 4 (available for listed models) Mic in & Line out (Optional) DMP Electronics Inc.

  • Page 15: Peripherals

    On function, when power and switch on, the system will be turned on automatically Connecting the Monitor B: VGA out Connection Connect your LCD display Monitor with a VGA cable (Not included in DIN PC-336x Series console bundles) to the 15pin D-Sub VGA port DMP Electronics Inc.

  • Page 16: Sd Card Recommendation

    SD card: Kingston Canvas Select SDXC UHS-I 64GB Class 10 BIOS: AMI BIOS OS:WES7 (Windows embedded standard 7) Disk benchmark software: CrystalDiskMark 6.0.2 Test result: Seq Q32T1 Seq Q32T1 Read Write SD card Speed 21.34 MB/ s 15.39 MB/ s DMP Electronics Inc.
  • Page 17 DIN PC-336x Series User Manual Chapter DMP Electronics Inc.

  • Page 18: Bios Reconfiguring

    Move to Advance “Primary IDE Pin Select”:  Parallel IDE = use 2.5” SATA HDD or SATA DOM as main storage.  SD Card = use SD card as main storage. Press <F10> to save the setting and exit. DMP Electronics Inc.
  • Page 19 Boot up DIN PC unit and press <Del> to get into BIOS menu. Move to Boot “Boot Settings Configuration” and press Enter. Set your main storage as 1 boot. Press <F10> to save the setting and exit. DMP Electronics Inc.

  • Page 20: Pxe Diskless Boot Setting

    Boot up DIN PC unit and press <Del> to get into BIOS menu. Move to Boot then select “Boot Settings Configuration” and press ENTER. Move to “Boot From LAN” and choose “Used INT 19h” then press “F10” to save setting and exit. DMP Electronics Inc.
  • Page 21 Boot up DIN PC unit and press <Del> to get into BIOS menu. Move to Security then select “I/O Interface Security” and press ENTER. Disable “COM5” and “COM6 port interface“ then press “F10” to save the setting and exit. DMP Electronics Inc.
  • Page 22 Select “Security” then move to “I/O Interface Security” and press ENTER. Enable “COM5 port Interface” and “COM6 port interface“ then press “F10” to save setting and exit. Or move to EXIT and select “load Optimal Defaults” then press “F10” to save the setting. DMP Electronics Inc.

  • Page 23: Drivers Installation Guide

    Unzip the downloaded file and double click the setting .exe file, then “Next”as below to install: After VGA driver installation completed, you will have to restart the computer. Then you will be able to select the resolution up to 1920 x 1080 pixels. DMP Electronics Inc.
  • Page 24 After installation completed, the Device Manager will update and show the correct device. Following the procedure above, update 2 question mark with 1G LAN driver. Following the procedure above, update 3 question mark with WLAN dongle driver (Optional). DMP Electronics Inc.
  • Page 25 DIN PC-336x Series User Manual Audio driver: Unzip downloaded file and double click the setting .exe file, then “Next” as below to install. After the installation completed, the Device Manager will update and show the correct device. DMP Electronics Inc.

  • Page 26: Additional Information

    Adjust Utility Application to “Show icon and notifications”. A blue icon = Graphic Utility appears on screen, double click it. In Graphic Utility, go to Rotation section. Select the direction of rotation then press Apply to test and OK to save the changes. DMP Electronics Inc.

  • Page 27: Turn Off The Display Function Setting

    DIN PC-336x Series does not support sleep function, it cannot wake up after sleep. To avoid the unwakeable sleep, please disable the function by setting “Put the computer to sleep” to “Never”. DMP Electronics Inc.
  • Page 28 Next the system will detect multiple network interfaces on the DIN PC-336x Series, and users have to decide the primary network interface, both of them could be chosen. Note: the Ethernet cable must be plugged in during this period. DMP Electronics Inc.
  • Page 29 Please remark both the Debian desktop environment and standard system utilities, then click to continue. It would start the package installation, and around hundred packages would be installed, after installation completed, the next indicatation message would pop up. DMP Electronics Inc.
  • Page 30 Answer YES to complete the installation as last procedure.  When it's completed, the disc tray will eject with pop-up message, press continue to restart and be ready to enjoy the new system! The Debian7.0 The Ubuntu10.04 DMP Electronics Inc.
  • Page 31 Reboot and make sure all the display is normal then set the resolution as requested. The supported resolutions: 1920x1080 (16:9) 1280x1024 (5:4) 1280x768 (16:10) 1600x1200 (4:3) 1440x900 (16:10) 1280x720 (16:9) 1680x1050 (16:10) 1280x960 (4:3) 1024x768 (4:3) 1400x1050 (4:3) 1366x768 (16:9) 800x600 (4:3) 1440x960 (3:2) 1360x768 (16:9) 640x480 (4:3) 1400x960 DMP Electronics Inc.
  • Page 32 Set the Log in as “user account” automatically. Disable the power saving mode when system is idle, System / Preference / Screensaver Unmarked the option “Active the screensaver when computer is idle”. Click close to complete the system configuration. DMP Electronics Inc.
  • Page 33 To add the parameters “pci=nomsi” in the line of Linux of GRUB as figure as below. The MSI/MSI-X must disabled for application of Gigabit LAN (RTL- 8111/8168) on the DIN PC-336x Series, and it could be set permanent by edition of file /boot/grub/grub.cfg. DMP Electronics Inc.
  • Page 34 DIN PC-336x Series User Manual Chapter DMP Electronics Inc.

  • Page 35: Onboard Connectors Summary

    I : Terminal Block Header E: RJ-45 LAN, 10/100 Mbps B: COM2 port J: Line out F: RJ-45 LAN, 1 Gbps C: COM5/ GPIO P9 K: Mic in G: USB 2.0 x 2 D: COM6/ GPIO P8 H: VGA port DMP Electronics Inc.

  • Page 36: Pin Assignments

    PORT 83 J9 : GPIO P9 - 9pin D-Sub connector (available in GPIO version) Pin # Signal Name Pin # Signal Name PORT 90 PORT 94 PORT 91 PORT 95 PORT 96 PORT 92 PORT 97 PORT 93 DMP Electronics Inc.
  • Page 37 DTR/ 422RX- J13 : COM 5 & COM 6 - 9pin D-Sub connector (RS-232) Pin # Signal Name Pin # Signal Name J10: LAN: RJ-45 connector Pin # Signal Name Pin # Signal Name FTXD+ FTXD- FRXIN+ FRXIN- DMP Electronics Inc.
  • Page 38 DIN PC-336x Series User Manual Chapter DMP Electronics Inc.

  • Page 39: Taking Care Of Your Din Pc

    When this happens, relocate the DIN PC-336x Series by a suitable distance away from the set. Do not drop the DIN PC-336x Series from the working table nor place heavy objects on top of it. DMP Electronics Inc.

  • Page 40: Cleaning Your Din Pc

    LAN and power cables. Contact a qualified person or your dealer to check the DIN PC before you use it again. Always disconnect the power cord from the power source before cleaning the DIN PC. DMP Electronics Inc.

  • Page 41: Troubleshooting

    Direction keys <↑↓> to choose “AUTO” and then go back to the main menu by pressing <ESC>. Move your cursor down with Direction keys <↓>, and choose “Save Settings and Exit”, a message dialog appears as seen below, hit <Enter>. “Save current settings and exit (Y/N)? Y” DMP Electronics Inc.
  • Page 42 And restart to confirm that the Windows operating system starts properly. If DIN PC- 336x Series continues to display the message ”Operating system not found,” and Windows does not start, please contact your nearest dealer for servicing. DMP Electronics Inc.
  • Page 43 DIN PC-336x Series User Manual Chapter DMP Electronics Inc.

  • Page 44: Terms And Conditions

    The Purchaser must pre-pay shipping for any defective system or parts returned under the warranty. DMP Electronics Inc. shall not be liable for risk of loss or damage during shipment of your returned system or parts if you fail to insure the shipment.

This manual is also suitable for:

D-3360-851221c2D-3360-852c2D-3362-c4D-3360-222c2D-3362-851221c2D-3362-852c2 ... Show all
