DMP Electronics EBOX-333 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EBOX-333x series
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBOX-333 Series and is the answer not in the manual?

Questions and answers

Related Manuals for DMP Electronics EBOX-333 Series

Summary of Contents for DMP Electronics EBOX-333 Series

  • Page 1 EBOX-333x series User’s Guide...
  • Page 2 Copyright 2014 DMP Electronics Inc. Special Notice to Users DMP Electronics Inc. provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties of merchantability or fitness for any particular purpose with regard to this manual, the software, or such other information.
  • Page 3 Trademarks Acknowledgment The EBOX-333x series is the registered trademarks of DMP Electronics Inc. Microsoft, Windows, and AMI are registered trademarks of Microsoft Corporation and American Megatrends Inc. in the United States and/or other countries respectively. Other brand names, product names or trade names appearing in this document are the properties and registered trademarks of their respective owners.
  • Page 4 Safety Information WARNING  Do not expose EBOX to rain or moisture, in order to prevent shock and fire hazard.  Never install EBOX in wet locations.  Do not open the cabinet to avoid electrical shock. Refer to your nearest dealer for qualified personnel servicing.
  • Page 5 Regulatory FCC Class A Note This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 6 Purchase Agreement Purpose: In accordance to the general commercial conduct of Trust and Fair Trade, herewith below is the agreement for the protection for both parties, DMP and Users in pursuant of trading. Product Description: With this product, herewith also known as EBOX-333x series, which is a simplified & an economical design of an embedded device for Special Purpose Personal Computing.

  • Page 7: Table Of Contents

    Contents Chapter 1 02 Unpacking your EBOX Mini PC Chapter 2 05 EBOX-333x series Overview 07 System Specifications 08 Peripherals Connecting Chapter 3 10 BIOS Reconfiguring Install the driver 14 Additional information Linux installation guide Chapter 4 24 Technical Specifications Chapter 5 31 Onboard Connectors Summary 33 Pin Assignments...
  • Page 8 Chapter...

  • Page 9: Unpacking Your Ebox Mini Pc

    Unpacking Your EBOX Mini PC Congratulation! You have just acquired EBOX-333x series, please check the following items: Packing List: Q’ty Item No. Description EBOX-333x series VESA PC Max. 22.5 watts External Power Adaptor, Vin: 100~240VAC 50/60Hz, Volt: +15VDC @ 1.5A Max. Note: The accessories are subject to change without immediate notice.
  • Page 10 Preface EBOX-333x series: VESA PC The EBOX-333x series is a revolutionary device which is especially designed for limited physical space and temperature concerns. No matter you are in a jammed office, a crowded place, or public transportation, the EBOX-333x can be easily integrated with a VESA LCD to bring it to access at any time.
  • Page 11 Chapter...

  • Page 12: Ebox-333X Series Overview

    EBOX-333x series Overview Front Panel A: Power LED The power LED lights up when the system is turned on. B: SD card LED LED flashes when the system is accessed SATA storage or SD card. C: Audio Line Out or Mic In For EBOX-333x VGA version, the original setting is Audio Line out x 1.
  • Page 13 Back Panel A: DC Power Jack B: VGA port For EBOX-333x Series VGA version only. C: Power switch D: USB v2.0 ports E: RJ-45 LAN Jack LAN1 is 10/100 Mbps. LAN2 is 1 Gbps.(Optional) F: Wireless Antenna connector (optional) G: HDMI port For EBOX-333x Series HDMI version only.

  • Page 14: System Specifications

    System Specification Dimension & Weight Vortex86DX2 (933 MHz) 115 x 115 x 35 mm / 500g ~ 510g Main Memory Operating System 1GB DDR2 (32-bit DRAM bus, EBOX-3330 series) Windows 7 Home/ Pro. 2GB DDR2 (32-bit DRAM bus, EBOX-3332 series) Windows 7 Embedded Windows XP Home/ Pro.
  • Page 15 Peripherals Connecting the Power Adaptor A: DC Power Jack To use EBOX-333x series immediately, please attach the supplied adapter for the power source. See the left diagram for visual connection. Connect the DC power jack of the power adaptor to the DC Input of EBOX-333x series. B: Turning ON EBOX-333x series Switch on power as indicated on your left-side figure, the system will start .
  • Page 16 Chapter...

  • Page 17: Bios Reconfiguring

    BIOS Reconfiguring AMI BIOS is used in the EBOX-333x series. To reconfigure the EBOX-333x series, press or hit the <Del> key to enter your BIOS setup main menu as below: Select from the menu, the desired setup for change. Press <Esc> to go back to main menu. Press <F9>...

  • Page 18: Install The Driver

    INSTALL THE DRIVER: Under the Windows series OS, the following drivers need to be installed manually. 1. VGA driver 2. Ethernet driver 3. Wireless USB wifi Dongle driver ( Optional ) 4. Audio driver ( for windows XP only ) Note: Please find the mating drivers from EBOX support page...
  • Page 19 ETHERNET DRIVER: Find the yellow question mark of Ethernet in the Device Manager under the control panel/ system. Select “Update Driver Software” and choose the right path, then click “ Install this driver software anyway ” when Windows Security popped out. After installation completed, the Device Manager will update and show the correct device.
  • Page 20 AUDIO DRIVER: Unzip the downloaded file and double click the setting .exe file, then “Next” as below to install. After the installation completed, the Device Manager will update and show the correct device.

  • Page 21: Additional Information

    Additional information: For Windows 7 OS or Windows 7 Embedded OS, the sleep function is hidden if you selected from the start menu. To customize the settings, first go to Start > Control Panel > Power Options, or simply search for "Power Options"...

  • Page 22: Linux Installation Guide

    Linux installation guide For Debian7.0/Ubuntu10.04 Regarding the system installation of Debian7.0/Ubuntu10.04, please follow the steps and suggestions to complete the system installation on the EBOX-333x Series platform. There we provided is a brief instruction to assist clients, but you can configure it by yourself with system’s asking.
  • Page 23 2. Basic system installation.  For Debian7.0, after booting from the installation CD, moving straight to install system would get a text only system, please choose Graphic Install if GUI is necessary for your application.  The system would start to ask questions for basic configuration. Such as the language, keyboard map and time zone…etc.
  • Page 24  As installation processing, the system would need you to make decisions about how the partitions your disk for the system? Following the default option is using entire disk, for the beginner. Then choose the “all files in one partition. Other allocation is also available, depends on customers’...
  • Page 25  The next question is about the agreement of the installation of the GRUB boot loader to the MBR area? Answer YES and wait system to complete the installation as last procedure.  When it's completed, the disc tray will eject and inform you, then press continue to restart and be ready to enjoy the new system! The Debian7.0 The Ubuntu10.04...
  • Page 26 3. Kernel and graphic driver installation. Install the Kernel Package (Console mode).  For Debian7.0, you can skip this procedure for kernel installation; Because system could work with default kernel version (3.2.0).  Clicking the icon of the terminal from the application. And download the kernel 2.6.32-21 from below link then to store the kernel package.
  • Page 27  Or you can remove the default kernel 2.6.32-??-generic that be arranged as a higher priority than the kernel we installed for the EBOX-333x platform, with the instruction below through the terminal.  First, check what version be installed as default in the system: # grep –w linux-image-2.6.32 /var/log/dpkg.log ...
  • Page 28 Install the VGA driver (Console mode)  Switch to console mode by pressing key <Ctrl> + <Alt> + <F1>, then copy the VGA driver rdc_drv.so to the driver folder /usr/lib/xor/modules/drivers/, before that, you can download the driver from links below for Debian7 and Ubuntu10.04 individually. The Ubuntu10.04 Xorg Version is 1.7.6 The Debian 7.0 Xorg Version is 1.12.4 VGA Driver (click...
  • Page 29 4. The system configuration: Enable the Auto login System / Administration / Login Screen Execute the utility “Login Screen” and enter the password to process it Set the Log in as “user account” automatically. Disable the power saving mode when system idle, System / Preference / Screensaver Unmarked the option “Active the screensaver when computer is idle”...
  • Page 30 Chapter...

  • Page 31: Technical Specifications

    Technical Specification EBOX-3330 Series VGA, LAN x 1, RS-232 Model Type EB-3330-SS EB-3330-C1 EB-3330-C2 EB-3330-C3 EB-3330-C4 Processor Vortex86DX2 (933MHz) BIOS AMI BIOS Memory Onboard 1GB DDR2 Integrated Graphics Chip/ D-Sub 15-pin Ethernet 10/100 Mbps LAN x 1 (RJ-45 connector, Built-in PXE diskless boot) USB (2.0) External: 3 ports (Front x 2, Rear x 1) Internal: 1 port HD Audio...
  • Page 32 EBOX-3330 Series VGA, LAN x 2, RS-232 Model Type EB-3330-L2SS EB-3330-L2C1 EB-3330-L2C2 EB-3330-L2C3 EB-3330-L2C4 Processor Vortex86DX2 (933MHz) BIOS AMI BIOS Memory Onboard 1GB DDR2 Integrated Graphics Chip/ D-Sub 15-pin Ethernet 10/100 Mbps LAN x 1, 1G LAN x 1 (RJ-45 connector, Built-in PXE diskless boot) USB (2.0) External: 3 ports (Front x 2, Rear x 1) Internal: 1 port HD Audio...
  • Page 33 EBOX-3330 Series HDMI, LAN x 1, RS-232 Model Type EB-3330-SSDMI EB-3330-C1DMI EB-3330-C2DMI EB-3330-C3DMI EB-3330-C4DMI Processor Vortex86DX2 (933MHz) BIOS AMI BIOS Memory Onboard 1GB DDR2 HDMI Ethernet 10/100 Mbps LAN x 1 (RJ-45 connector, Built-in PXE diskless boot) USB (2.0) External: 3 ports (Front x 2, Rear x 1) Internal: 1 port HD Audio Mic in PS/2 for Keyboard / Mouse x 1...
  • Page 34 EBOX-3330 Series HDMI, LAN x 2, RS-232 Model Type EB-3330-L2SSDMI EB-3330-L2C1DMI EB-3330-L2C2DMI EB-3330-L2C3DMI EB-3330-L2C4DMI Processor Vortex86DX2 (933MHz) BIOS AMI BIOS Memory Onboard 1GB DDR2 HDMI Ethernet 10/100 Mbps LAN x 1, 1G LAN x 1 (RJ-45 connector, Built-in PXE diskless boot) USB (2.0) External: 3 ports (Front x 2, Rear x 1) Internal: 1 port HD Audio...
  • Page 35 EBOX-333x series Models with LAN x 1 Listing: EB-3330-SS: Standard Version EB-3300-C1: Standard Version with RS-232 port x 1 EB-3330-C2: Standard Version with RS-232 ports x 2 EB-3330-C3: Standard Version with RS-232 ports x 3 EB-3330-C4: Standard Version with RS-232 ports x 4 EB-3330-851: Standard version with RS-485 port x 1 EB-3330-852: Standard version with RS-485 ports x 2 EB-3330-851C1: Standard version with RS-485 port x 1 &...
  • Page 36 EBOX-333x series Models with LAN x 2 Listing: EB-3330-L2SS: Standard Version with LAN x 2 EB-3330-L2C1: Standard Version with LAN x 2, RS-232 port x 1 EB-3330-L2C2: Standard Version with LAN x 2, RS-232 ports x 2 EB-3330-L2C3: Standard Version with LAN x 2, RS-232 ports x 3 EB-3330-L2C4: Standard Version with LAN x 2, RS-232 ports x 4 EB-3330-L2851: Standard version with LAN x 2, RS-485 port x 1 EB-3330-L2852: Standard version with LAN x 2, RS-485 ports x 2...
  • Page 37 Chapter...

  • Page 38: Onboard Connectors Summary

    Onboard Connectors Summary Summary Table for CPU Board Description Type of Connections Pin nbrs. SODIMM-SOC-200P-1.8V SODIMM socket 200 Pin 200-pin SATA SATA socket 7-pin USB1 (Front) USB Connector 6-pin USB2 (Front) USB Connector 6-pin USB3 (Back) USB Connector 6-pin USB4 (Inside) USB Connector 6-pin Ethernet LAN...
  • Page 39  Rear Connectors Outline A: DC Power Jack B: VGA C: RJ-45 LAN 1 D: USB E: Power Switch F: Serial Ports G: PS/2 KB/Mouse H:HDMI I: G-LAN, RJ-45 LAN2...

  • Page 40: Pin Assignments

    Pin Assignments J19: PS/2 Keyboard or Mouse – 6pin Mini-Din Connector Pin # Signal Name KBCLK PMCLK KBDAT PMDAT SB5V J16: Power SW – Push Button Switch Pin # Status J15: DC-IN (15V) – 2pin Jack Pin # Signal Name +15V Input J5, J6, J8: USB2.0 (180 ) : 4pin USB Type 1 Connector ( Horizontal Type )
  • Page 41 J17: HDMI – 19pin HDMI Connector Pin # Signal Name Pin # Signal Name Pin # Signal Name TMDS Data2+ TMDS Data0 Shield TMDS Data2 Shield TMDS Data0– TMDS Data2– TMDS Clock+ DDC/CEC Ground TMDS Data1+ TMDS Clock Shield +5 V Power TMDS Data1 Shield TMDS Clock–...
  • Page 42 Chapter...

  • Page 43: Taking Care Your Ebox Vesa Pc

    Taking Care of your EBOX This section gives you some guidelines on using EBOX-333x series – Safe using, Storing and Handling. Storing Do not place EBOX-333x series in a location that is subject to:  Heating sources, such as stove, oven, heater, radiator or air duct ...

  • Page 44: Cleaning Your Ebox Vesa Pc

    Using Cables for Connection To avoid the problem, use only the specified interface cables in your accessory bag. The supplier will not be responsible for the connection arising from the other unspecified peripheral equipment. Do not use cut or damaged cables for connection. Cleaning Your VESA PC Clean the VESA PC with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution.

  • Page 45: Troubleshooting

    Troubleshooting This section describes the techniques of resolving some basic problems that you encounter when using EBOX-333x series. For more troubleshooting guidelines, please contact your nearest dealer for technical support. Troubleshooting Your VESA PC A. VESA PC does not start Make sure the EBOX-333x series is properly secured and plugged into a power source before it is turned on.
  • Page 46 (BIOS Setup menu “Exit”) C. “Operating System Not Found” – A message indicating that “Operating system not found” appear when the VESA PC starts (Windows won’t start) Enter the BIOS setup main menu by pressing <DEL> key, be sure that the correct boot drive is enabled.
  • Page 47 Chapter...

  • Page 48: Terms And Condition

    The Purchaser must pre-pay shipping for any defective system or parts returned under the warranty. DMP Electronics Inc. shall not be liable for risk of loss or damage during shipment of your returned system or parts if you fail to insure the shipment.
