Summary of Contents for DMP Electronics EBOX-3310MX-TS4C
- Page 1 EBOX-3310MX-D4C series User’s Guide...
- Page 2 Copyright 2011 DMP Electronics Inc. Special Notice to Users DMP Electronics Inc. provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied warranties of merchantability or fitness for any particular purpose with regard to this manual, the software, or such other information.
- Page 3 Trademarks Acknowledgment The EBOX-3310MX-D4C series is the registered trademarks of DMP Electronics Inc. Microsoft, Windows, and AMI are registered trademarks of Microsoft Corporation and American Megatrends Inc. in the United States and/or other countries respectively. Other brand names, product names or trade names appearing in this document are the properties and registered trademarks of their respective owners.
- Page 4 Safety Information WARNING Do not expose EBOX-3310MX-D4C series to rain or moisture, in order to prevent shock and fire hazard. Never install EBOX-3310MX-D4C series in wet locations. Do not open the cabinet to avoid electrical shock. Refer to your nearest dealer for qualified personnel servicing.
- Page 5 Regulatory FCC Class A Note This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 6 Purchase Agreement Purpose: In accordance to the general commercial conduct of Trust and Fair Trade, herewith below is the agreement for the protection for both parties, DMP and Users in pursuant of trading. Product Description: With this product, herewith also known as EBOX-3310MX-D4C series which is a simplified & an economical design of an embedded device for Special Purpose Personal Computing.
-
Page 7: Table Of Contents
Contents Chapter 1 02 Unpacking your EBOX Mini PC Chapter 2 05 EBOX-3310MX-D4C series Overview 06 System Specifications 07 Peripherals Connecting Chapter 3 12 BIOS Reconfiguring Install the driver Chapter 4 23 Technical Specifications Chapter 5 25 Onboard Connectors Summary 27 Pin Assignments Chapter 6 30 Taking Care Your EBOX VESA PC... - Page 8 Chapter...
-
Page 9: Unpacking Your Ebox Mini Pc
Unpacking Your EBOX Mini PC Congratulation! You have just acquired EBOX-3310MX-D4C series, please check the following items. Packing List: Item No. Description Q’ty EBOX-3310MX-D4C series VESA PC Max. 22.5 watts External Power Adaptor, Vin: 100~240VAC 50/60Hz, Volt: +15VDC @ 1.5A Max. Drivers CD Note: The accessories are subject to change without immediate notice. - Page 10 Preface EBOX-3310MX-D4C series: VESA PC The EBOX-3310MX-D4C series is a revolutionary device which is especially designed for limited physical space and temperature concerns. No matter you are in a jammed office, a crowded place, or public transportation, it can be easily integrated with a VESA LCD to bring you EBOX-3310MX-D4C series access at any time.
- Page 11 Chapter...
-
Page 12: Ebox-3310Mx-D4C Series Overview
EBOX-3310MX-D4C series Overview Front Panel Power LED The power LED lights up when system is turn on. HDD LED LED flashes when the system is accessing Hard Drive. SD Slot This system is bootable from SD card. (In this series only EBOX- 3310MX-S4C/ TS4C support SD card) USB v2.0 ports... -
Page 13: System Specifications
System Specification Operating System Vortex86MX+ Windows XP Home/ Pro Windows XP Embedded Main Memory Windows Embedded CE 1GB DDR2 BIOS Supported Linux Distribution list: AMI BIOS 1. Debian 4.0 2. Debian 5.0 3. Ubuntu 8.04 Resolution up to 1920 x 1200 High Colors 4. -
Page 14: Peripherals Connecting
Peripherals Connecting the Power Adaptor DC Power Jack To use EBOX-3310MX-D4C series immediately, please attach the supplied adapter for the power source. See the left diagram for visual connection. Connect the DC power jack of the power adaptor to the DC Input of EBOX-3310MX-D4C series. - Page 15 Peripherals Connecting the USB provide five external USB ports with (four at the front, one at the rear) EBOX-3310MX-D4C series and one internal USB port. SD Slot For booting device by SD Card. (In this series only EBOX-3310MX- S4C/ TS4C support SD card) USB Ports The USB ports are available for connection to USB devices such as...
- Page 16 Connecting the Keyboard and Mouse PS/2 Keyboard or Mouse (6-pin) This PS/2 Port is shared for connecting Keyboard and/or Mouse by using Split Y-Cable (not included). Connecting Serial port Serial Ports (Optional) The serial port is usually connected to a serial device like modem or terminal devices.
- Page 17 Chapter...
-
Page 18: Bios Reconfiguring
BIOS Reconfiguring Take note that AMI BIOS is used in the EBOX-3310MX-D4C series. To reconfigure the EBOX-3310MX-D4C series, press or hit the <Del> key to enter your BIOS setup main menu. Select from the menu, the desired setup for change. Press <Esc>... -
Page 19: Install The Driver
Under the Windows series OS, the following drivers need to be installed manually. 1. Ethernet driver. 2. RS-232 driver (USB to RS-232 port). 3. Video capture chip driver (for TV-IN models: EBOX-3310MX-TS4C/ TD4C). Note: COM5 port was extended from a USB port. ETHERNET DRIVER: Find the yellow question mark of Ethernet in the Device Manager under the control panel/ system. - Page 20 Click “Next” and then choose “continue anyway” to ignore the “unrecognized object” warning and restart the windows after the installation. RS-232 DRIVER ( FOR USB TO RS-232 PORT The RS-232 COM5 port from EBOX-3310MX-D4C series was extended from a USB port; you’ll need to install the RS-232 driver.
- Page 21 VIDEO CAPTURE CHIP DRIVER: Find the yellow question mark of the unknown device under the control panel/ system. Choose update by clicking the 2nd selection to install the driver at specific location. Choose to install the driver manually. Select the sound & video type (with speaker icon) to install the driver.
- Page 22 Find the rdccap.INF under the TV-IN Capture\ WDM. (You may update driver from the CD in the package or apply from your supplier). Warning message (Windows: unrecognized object) might pop out during the installation, just continue anyway and restart the windows after completed.
- Page 23 Debian / Ubuntu Linux Installation Guide In the MX+ platform, with the newer IDE and Ethernet controller, both of the two controllers just start supported from kernel 2.6.28.3. Please refer to the guide to help you complete the installation. How to install Linux on Vortex86MX+ platform? Preparation: 1.
- Page 24 D. To unpack the kernel package and update. # dpkg -i xxx.deb # update-initramfs –k 2.6.30-vortex86mx -c # update-grub E. When these three procedures completed, type reboot to reboot system. # reboot Step3: Moving the storage installed Linux, back to VortexMX+ platform. Step4: Turn on the power to boot.
- Page 25 For Ubuntu When it start booting, press the Esc key when it boot. Confirm the Grub list first. There should has an option 2.6.30-vortex86mx, and then to boot. For Debian Please press the Esc key to confirm Grub list and press E key to confirm and modify the storage’s codename. Note: The Grub list parameters you can modify in the file /boot/grub/menu.lst.
- Page 26 Additional information for TV-in supported EBOX in Linux OS The video capture function can be activated with additional driver under the Linux OS. (Recommended OS: unbutu 9.04 with Kernel version: 2.6.28-11-generic) Installation guide: -BIOS setting: On the menu bar, open the PCI PnP menu and select the Allocate IRQ to PCI VGA to set “Yes” as indicated above.
- Page 27 Remember to check the update condition after completed the server adding. # apt-get update -install the applications for video playing # apt-get install xawtv # apt-get install tvtime Note: EBOX TV-in series are supported by most of video applications with video capture function. The instruction is based on the popular two video applications xawtv and tvtime for reference.
- Page 28 Chapter...
-
Page 29: Technical Specifications
EBOX-3310MX-D4C series Models Listing: EBOX-3310MX-TS4C: TV-In Version with 6 x USB ports, 4 x RS-232 ports, SD Card support Only and Auto Power On Support. EBOX-3310MX-TD4C: TV-In Version with 6 x USB ports, 4 x RS-232 ports, support SATA device Only and Auto Power On Support. - Page 30 Chapter...
-
Page 31: Onboard Connectors Summary
Onboard Connectors Summary Summary Table for CPU Board Description Type of Connections Pin nbrs. SODIMM-SOC-200P-1.8V SODIMM socket 200 Pin 200-pin SATA SATA socket 7-pin USB5 (Front) USB Connector 6-pin USB6 (Front) USB Connector 6-pin USB1 (Back) USB Connector 6-pin USB3 (Inside) USB Connector 6-pin Ethernet LAN... - Page 32 Rear Connectors Outline DC Power Jack PS/2 KB/Mouse RJ-45 LAN Power Switch Serial Ports RCA Jack for TV-IN (Optional) *TV-IN function Only Available on EBOX-3310MX-TS4C / TD4C.
-
Page 33: Pin Assignments
Pin Assignments J12: PS/2 Keyboard or Mouse – 6-pin Mini-Din Connector Pin # Signal Name KBCLK PMCLK KBDAT PMDAT SB5V J17: Power SW – Push Button Switch Pin # Status J16: DC-IN (15V) – 2-pin Jack Signal Name Pin # +15V Input J7: USB (90 )–... - Page 34 J10: VGA – 15-pin D-Sub Connector Pin # Signal Name Pin # Signal Name Pin # Signal Name HYSYNC VSYNC J5, J6, J18, J19: USB (USB2): For connection to external USB device –4-pin USB Type 1 Connector (H) Signal Pin # Name USB2- USB2+...
- Page 35 Chapter...
-
Page 36: Taking Care Your Ebox Vesa Pc
Taking Care of your EBOX This section gives you some guidelines on using EBOX-3310MX-D4C series – Safe using, Storing and Handling. Storing Do not place EBOX-3310MX-D4C series in a location that is subject to: Heating sources, such as stove, oven, heater, radiator or air duct Direct contact from sunlight Rain or moisture area Excessive dust accumulation area... -
Page 37: Cleaning Your Ebox Vesa Pc
Using Cables for Connection To avoid problem, use only the specified interface cables in your accessory bag. The supplier will not be responsible for the connection arising from the other unspecified peripheral equipment. Do not use cut or damaged cables for connection. Cleaning Your VESA PC Clean the VESA PC with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution. -
Page 38: Troubleshooting
Troubleshooting This section describes the techniques of resolving some basic problems that you encounter when using EBOX-3310MX-D4C series. For more troubleshooting guidelines, please contact your nearest dealer for technical support. Troubleshooting Your VESA PC A. VESA PC does not start Make sure the EBOX-3310MX-D4C series is properly secured and plugged into a power source before it is turned on. - Page 39 (BIOS Setup menu “Exit”) C. “Operating System Not Found” – A message indicating that “Operating system not found” appear when my VESA PC starts (Windows won’t start) Enter your BIOS setup main menu by pressing <DEL> key, be sure that the C: drive is enable. If Windows still does not start, follow these steps to initialize the BIOS: Turn off the EBOX-3310MX-D4C series.
- Page 40 Chapter...
-
Page 41: Terms And Condition
The Purchaser must pre-pay shipping for any defective system or parts returned under the warranty. DMP Electronics Inc. shall not be liable for risk of loss or damage during shipment of your returned system or parts if you fail to insure the shipment.
