Motor Unit Assembly Parts

12
11
KEY PART
NO. NO.
1 41C76
2 41B4245
3 41B4375-2 Terminal block w/screws
4 41C5317
41C5839
41C5806
41C5418
5 41D605-1
6 41DB001
13
9
8
DESCRIPTION
Belt cap and sprocket
Line cord
Wire harness (logic)
High voltage wire harness
DC motor wire harness
Light socket wire harness
Motor 80kg/100kg
Receiver logic board
assembly with end panel
7
5
10
KEY PART
NO. NO.
7 41B5351-7
8 41C168
9 41D630-2
10 41A5490-17 Cover
11 175C147
12 108D78
13 41A5893-1
41B591
41A5726
72A35
40
1
2
3
4
DESCRIPTION
Power supply
Transformer and harness
Bracket: light socket, limit
switch
Light socket
Light lens
BBU housing ONLY
NOT SHOWN
Battery replacement for BBU
BBU circuit board
Fuse
