Summary of Contents for Keithley 4200A-SCS-PK1
- Page 1 Model 4200A-SCS Parameter Analyzer Quick Start Guide 4200A-SCS-PK1...
-
Page 2: Safety Precautions
Measurement Category II (as referenced in IEC 60664) connections require protection for high transient overvoltages often associated with local AC mains connections. Certain Keithley measuring instruments may be connected to mains. These instruments will be The following safety precautions should be observed before using this product and any marked as category II or higher. - Page 3 If you are using a test fi xture, keep the lid closed while power is applied to the device under selected parts should be purchased only through Keithley Instruments to maintain test. Safe operation requires the use of a lid interlock.
-
Page 4: Power And Environmental Specifi Cations
Power and environmental specifi cations For indoor use only. Carefully consider and confi gure the appropriate Power Supply 100 VAC to 240 VAC, 50 Hz to 60 Hz output-off state, source levels, and compliance levels before connecting the instrument to Maximum VA 1000 VA a device that can deliver energy. - Page 5 Microsoft Windows operating system and For additional support information, see http://www.tek.com/keithley. mass storage. When running a test sequence, you can view results and plots for completed tests while the sequence is still running so you can begin analyzing results sooner.
-
Page 6: Unpack And Inspect The Instrument
Remove the packaging insert. Remove the 4200A-SCS. Inspect the instrument for any obvious signs of physical damage. Report any damage to the shipping agent In the 4200A-SCS-PK1 bundle, you should have received the immediately. 4200A-SCS Parameter Analyzer with: • 4200-SMU medium-power (two) •... - Page 7 4200-PA remote preamplifi er 4200-TRX-2 ultra-low noise triaxial cables (two) CAP-31 protective caps with triaxial connectors (two) 4200A-SCS-PK1 Quick Start Guide (not shown; this document) Refer to the packing list for additional items that might have shipped with your instrument.
-
Page 8: Connect The Instrument
42.4 V peak, or 60 VDC for equipment rated for dry disconnect power sources when a test fi xture cover is opened. locations. Keithley Instruments products are only rated for • Where possible, use automatic handlers so operators are not dry locations. -
Page 9: Install The Instrument
Install the instrument If you need voltages greater than ±40 V, you must also connect The 4200A-SCS can be used on a bench or in a rack. Please the exterior of the test fi xture enclosure to protective earth see the instructions that came with your rack-mount kit if you are (safety ground). - Page 10 The 4200A-SCS functions on all current ranges and up to High-voltage test fi xtures, such as the Keithley Instruments LR:8028, can be used with applications that are greater than ±40 V without asserting the interlock. When the interlock ±40 V.
-
Page 11: Test Connections
3-lug triaxial connectors. The 8101-PIV test fi xture The location of the rear panel interlock connector is shown that is included with the 4200A-SCS-PK1 allows the 4200A-SCS in the following graphic. to be connected to a discrete device. - Page 12 Power on the 4200A-SCS The 4200A-SCS operates from a line voltage of 100 V to 240 V at a frequency of 50 Hz or 60 Hz. Make sure the operating voltage The power cord supplied with the Model in your area is compatible. 4200A-SCS contains a separate protective earth (safety ground) wire for use with grounded outlets.
- Page 13 To power on the 4200A-SCS: When fi rst starting a Clarius+ application, you must answer “Yes” to an on-screen license agreement. Answering “No” Make sure the power is off. The power switch, on the front makes your system nonfunctional until you reinstall the panel in the lower right corner, is not lit when power is off.
- Page 14 Change powerline frequency To change the powerline frequency: Close Clarius. Run KCon. The default powerline frequency is set to 60 Hz. If the setting is wrong, the 4200A-SCS cannot properly reject powerline Select KI 4200A SCS in the Confi guration Navigator. The left pane is the Confi...
- Page 15 FAQs Safety Introduction Connect I-V test Next steps...
- Page 16 Make connections for the I-V test If you are using the supplied test fi xture, connect the MOSFET and test fi xture as shown in this diagram.
- Page 17 Item Description Notes 4200A-SCS Parameter Analyzer 4200-TRX Ultra-Low Noise Preamplifi er Triaxial-to-triaxial cable that connects 4200-PA to Triaxial Cables a test fi xture 4200-MTRX Ultra-low noise SMU triaxial cable (mini-triaxial, connects 4200-SMU units to a test fi xture) TG-439 nMOSFET (DUT) Plug into the test socket that is labeled DC ONLY 8101-PIV Component Test Fixture 4200-PA Remote Preamplifi...
- Page 18 Perform an I-V test on a MOSFET The fi rst time Clarius opens, the project tree is displayed and the default project is loaded. The next graphic shows the tests in this project. To work with a test: Select vds-id (located under 4terminal-n-fet).
- Page 19 To confi gure the test: Select Confi gure to open the pane shown here. This is The vds-id settings should be: where you defi ne the test. • SMU3: Provide a voltage step function for four different gate voltages (2 V, 3 V, 4 V, and 5 V). •...
- Page 20 Run the vds-id test Clarius can run a single test or a sequence of tests. To run a single test, check the test and select it in the project tree. The test should be highlighted. When you select , only that test will run.
- Page 21 To run a sequence of tests, check the tests you want to run, then check and select the device, subsite, or project item that contains the tests. For example, in the following graphic, when you click , all the checked tests under 4terminal-n-fet run. FAQs Safety Introduction...
- Page 22 View the vds-id test results To view vds-id test data, you can use the Analyze sheet, which is similar to a Microsoft Excel spreadsheet, and the graph. To view vds-id test results: Select Analyze. Select an icon next to View to choose the type of information you would like to see: •...
- Page 23 Export data or graphs Test results are automatically saved in Clarius, however, based on the vds-id test data you received, you can choose to save the data, graph, or both to an external fi le with a unique fi lename, depending on your needs. Note that the graph output is determined by the Graph Defaults setting in My Settings (you can choose .jpg or .bmp format).
- Page 24 Customize the graph The graph shown below was customized to include the Legend box, Title, and use different colors for the graph series. These options are available through the Graph Settings button. To customize a graph: Select Graph Settings. To include a Legend and Title, select those options from the Graph Settings menu.
- Page 25 FAQs Safety Introduction Connect I-V test Next steps...
- Page 26 FAQs A confi guration error has been detected and I cannot How should I clean the front-panel display? launch Clarius. What should I do? If you need to clean the front-panel LCD touchscreen display, This occurs when the physical confi guration does not use a soft dry cloth.
-
Page 27: Next Steps
To access the Learning Center, click Help in the Clarius menu, press F1 while using Clarius, or select the desktop See: www.tek.com/keithley for support and additional information icon. about the instrument. The 4200A-SCS Learning Center includes the following: •... - Page 28 Contact Information: Find more valuable resources at TEK.COM Australia* 1 800 709 465 Austria 00800 2255 4835 Copyright © 2016, Tektronix. All rights reserved. Balkans, Israel, South Africa and other ISE Countries +41 52 675 3777 Tektronix products are covered by U.S. and foreign Belgium* 00800 2255 4835 patents, issued and pending.
