Page 2: Table Of Contents
Table of Contents 1.0 Purpose........................... 3 2.0 General Requirements, Warnings and Limitations............3-4 2.1 General Fall Protection Requirements 2.2 System Warnings and Limitations 3.0 Xenon Kit Diagrams and Component Descriptions............5-6 4.0 Installation of Xenon Horizontal Lifeline Kits..............7-11 4.1 Installation of D-Bolt Anchor to Beam or Structure 4.2 Installation of Universal Intermediate Brackets 4.3 Installation of Horizontal Lifeline Assembly 4.4 Tensioning Horizontal Lifeline... -
Page 3: Purpose
Us er I nst ruc ti o n s - E n g l is h Thank You Thank you for your purchase of Miller Fall Protection equipment. Miller brand products are produced to meet the highest standards of quality at our ISO 9001 certified facility. Miller Fall Protection equipment will provide you with years of use when cared for properly. -
Page 4: System Warnings And Limitations
Us er I nst ruc ti o n s - E n g l is h 2.2 System Warnings and Limitations System Compatibility System Requirements Xenon Kits are designed for use with Miller approved com- The Horizontal Lifeline System shall be designed, installed and used, under the supervision of a qualified person, ponents. -
Page 5: Xenon Kit Diagrams And Component Descriptions
Us er I nst ruc ti o n s - E n g l is h 3.0 Xenon Kit Diagrams and Component Descriptions D-Bolt Anchor Single Shock Absorber Xenon Kit Shock Absorber Swageless Cable Fitting Intermediate Support Bracket D-Bolt Anchor Thimble D-Bolt Anchor Cable Clips... - Page 6 Us er I nst ruc ti o n s - E n g l is h Part No. Component Name Qty. Description System Kit Components 5/8” (16mm) stainless steel D-anchor with hex bolt (5/8” - 11 UNC x 5”), hex nut and split lockwasher, rated 416SS D-Bolt Anchor to 10,000 lbs.
-
Page 7: Installation Of Xenon Horizontal Lifeline Kits
Us er I nst ruc ti o n s - E n g l is h 4.0 Installation of Xenon Horizontal Lifeline Kits • Before installation, carefully inspect all components of the system according to the manufacturer’s instructions (see 8.0 Inspection and Maintenance). -
Page 8: Installation Of Universal Intermediate Brackets
Us er I nst ruc ti o n s - E n g l is h 4.2 Installation of Universal Intermediate Brackets (Required for Multiple-Span Systems only) The intermediate brackets are designed to allow free-floating or fixed positioning. Most often free-floating positioning is desired. -
Page 9: Installation Of Horizontal Lifeline Assembly
Us er I nst ruc ti o n s - E n g l is h 4.3 Installation of Horizontal Lifeline Assembly WARNING: Always wear gloves when inspecting or installing a cable lifeline. **Procedures A through C apply to the assembly required on one end of the lifeline. A. - Page 10 Us er I nst ruc ti o n s - E n g l is h C. Swageless Cable Fitting to Inline Shock Absorber (see Figure 5) 1. Remove cotter pin and bolt from jaw anchor head of cable fitting. Fig.
-
Page 11: Tensioning Horizontal Lifeline
Us er I nst ruc ti o n s - E n g l is h 4.4 Tensioning Horizontal Lifeline IMPORTANT: It is essential that the lifeline be properly tensioned before use. Failure to do so will affect fall clearance re- quirements and the potential fall forces which may be imposed upon the worker and the system. -
Page 12: Operation/Use Of Xenon Shuttle On The Horizontal Lifeline
Us er I nst ruc ti o n s - E n g l is h 5.0 Operation/Use of Xenon Shuttle on the Horizontal Lifeline Jaws 1. Inspect all equipment before use according to the manufac- Press and hold turer’s instructions. button 2. -
Page 13: Fall Clearance
Us er I nst ruc ti o n s - E n g l is h 6.0 Fall Clearance Always know your fall clearance before proceeding with the use of a horizontal lifeline system. Total Fall Clearance Required* Total Fall Clearance Required* Fall Clearance from Horizontal Lifeline for One to Two Workers... - Page 14 Us er I nst ruc ti o n s - E n g l is h Total Fall Clearance Required* for One to Two Workers and Three to Four Workers when using a Self-Retracting Lifeline/Fall Limiter with a Xenon HLL System Single-Span Systems System/ Single...
-
Page 15: Training
Failure to do so may result in serious injury or death. Contact Miller Fall Protection • System must not be altered in any way. Sperian Fall Protection, Inc. if instruction manual is needed. • Use caution when working in or near hazardous environments. -
Page 16: Inspection And Maintenance Log
Inspection and Maintenance Log Registre D'inspection et D'entretien Registro de Inspección y Mantenimiento DATE OF MANUFACTURE:_________________________________________________ DATE DE FABRICATION / FECHA DE FABRICACIÓN MODEL NUMBER:________________________________________________________ NUMÉRO DE MODÈLE / NÚM. DE MODELO DATE PURCHASED:______________________________________________________ DATE D’ACHAT / FECHA DE COMPRA INSPECTION MAINTENANCE CORRECTIVE... -
Page 17: Warranty
® MILLER FALL PROTECTION PRODUCTS TOTAL SATISFACTION ASSURANCE At Miller Fall Protection, we have been providing quality Miller brand fall protection equipment to millions of workers worldwide since 1945. LIMITED LIFETIME WARRANTY BACKED BY OVER 60 YEARS IN THE FALL PROTECTION BUSINESS We sincerely believe that our fall protection equipment is the best in the world. - Page 18 Toll Free: 800.873.5242 Fax: 800.892.4078 Download this manual at: www.millerfallprotection.com Téléchargez ce manuel à l’adresse: www.millerfallprotection.com Puede bajar por Internet este manual en: www.millerfallprotection.com Sperian Fall Protection, Inc. P.O. Box 271, 1345 15th Street Franklin, PA 16323 USA...
