1. Introduction Congratulations with the purchase of your monitor. This LCD monitor is a color active matrix thin-film- transistor (TFT) liquid crystal (LCD) to provide superior display performance. 2. Safety This monitor is only be suitable for use in an interior environment where there are not sealed, not subject to dust, dirt, condensation (Pollution Degree 2) (IP20).
5. Monitor specifications Panel Manufactures Part No. LM230WF3-SLE1 Absolute Maximum Ratings Item Unit Typical Remarks Operating Temperature °c Storage Temperature °c Operation Humidity Storage Humidity Input characteristics Description Signal Unit Typical Remarks Power in (2,5mm plug) Input 11.4 12,6 Consumption RGB Input Analog RGB Sync...
6. Operation Color LED: This LED shows the state of controller. Green is the “normal state”. Red is the “Off mode”. (Can’t find Sync. signals) Amber is the “DPMS mode” (Display Power Management Signaling). PC Settings: The PC needs to be set to an appropriate graphics mode that has the same resolution with the LCD panel to have clear screen image.
7. OSD MENU The chosen OSD settings will be stored in memory. The OSD menu can be cleared from the screen by pressing the MENU button otherwise it will be automatically cleared after a few seconds of non‐use. OSD Main Menu [PICTURE] [COLOR] [OSD]...
Page 7
OSD GUI Control Table MAIN SUB MENU CONTROL MENU Brightness 50(0~100) Contrast 50(0~100) Sharpness 2( 0 ~ 4) Picture H Position 50(0 ~100) V Position 50(0 ~100) PC ONLY Clock 50(0 ~100) Phase 30(0 ~100) Color Status Management User(User, Warm, Normal, Cool) 50(0~100) Color Green...
8. Driver software touch screen (optional 150TFTS2302M[G]) 3M TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on “3M Touch Systems” web site for the following operating systems: • Windows • Linux (2.6/3.0 Kernel) •...
9. Mounting instructions Monitor Mounting This monitor can be mounted with eight M4 mount holes. Follow the steps described below: Place the monitor into the machine. Place the M4 screws on the both sides of the monitor. Tighten the nuts until the monitor is firmly secured to the machine (do not use screws longer then 5mm in the monitor).
10. Accessories Part number Description Power supply input 100/240V 150-0049 output 12V 5A 22-0012-4 Power cable Euro lead 1.80M 149-0112-11 VGA cable 1.80m 149-0147 USB cable type a-b m/m 1.80M 149-0121 DVI-D Cable 2 mtr 18+1 149-0111-2 Serial cable 2m 23“...
