  • Page 1 DC-S Series Installation Manual DC-S1283FX DC-S1283WHX Powered by...
  • Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
  • Page 4 © 2016 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    • Network bandwidth limitation and MAT features for ethernet. more efficient use of network bandwidth You can use the IDIS Discovery program to change • Easy network access via UPnP (Universal Plug and network camera settings or the IDIS Solution Suite...

  • Page 7: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Ferrite Core Open Source Guide Quick Guide Screws (4 ea.)

  • Page 8: Overview

    Part 1 – Introduction Overview Product color and design may vary depending on the model. Indoor and Outdoor Body • To remove/insert the SD memory card or perform the factory reset, make sure that the waterproof sealing is screwed to the dome cover tightly when reconnecting the dome cover.
  • Page 9 Part 1 – Introduction • M3 Screw Hole Body – Bottom Side View When installing an outdoor camera, use the provided M3 screws to secure the sun shield on to the camera body. (frame ground) is marked beside the M3 screw hole of the camera body.
  • Page 10 Part 1 – Introduction Outdoor Sun Shield Wall/Ceiling Installation Hole Install Screw Hole Safety Wire M4 Screw Hole M5 Screw Hole Pipe Hole • Wall/Ceiling Installation Hole Used to screw the camera in place on a wall or a ceiling. •...

  • Page 11: Cable

    For more information on network connection setup, purchase a separate speaker system with a built-in refer to the IDIS Discovery operation manual. amplifier. • Power – V_O, GND: Connect the cable's signal line and ground line to these ports and the connector on Connect the power adapter.

  • Page 12: Factory Reset

    It's also possible to do a factory reset by pressing and releasing LAN Cable the reset switch while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more information on factory reset, refer to the IDIS Discovery operation manual.

  • Page 13: Installation

    Part 1 – Introduction Installation Screw the indoor bracket to the wall or ceiling by using the wall/ceiling mounting screws provided with the camera. Installation of this product does not require the use of special tools. Make a cable hole in the wall or ceiling. For more information on other devices comprising the overall system, refer to their respective installation manuals.

  • Page 14: Outdoor

    Part 1 – Introduction Outdoor Use the provided M5 screws to secure the outdoor bracket on to the sun shield. Connect the cable from the camera to the pipe. In case that a universal nut is attached to a pipe Connect the sun shield and outdoor bracket first, then Turn the universal nut to connect the camera to the connect it to the pipe as follows:...

  • Page 15: Dimensions

    Connect the cable from the camera to the pipe. Use the provided M5 screws to screw the sun shield to the outdoor bracket. Ø200 mm(7.87”) Connect external devices, the network cable, and the power adapter. DC-S1283WHX Supply the power. Ø230 mm(9.06”)

  • Page 16: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Power Alarm Out Sensor In Network Camera Monitor Out...

  • Page 17: With Non Directip™ Nvr-Based Layout

    Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 18: Part 3 - Appendix

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below.

  • Page 19: Specifications

    Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.8" CMOS Max. Resolution 1920x1080 Scanning Method Progressive scan Lens Type AF Zoom Lens Focal Length f=4.3 mm to 129.0 mm Aperture F1.6 to F5.0 Iris Control DC Auto Iris Angular Field of View...
  • Page 20 Part 3 - Appendix Network Video Compression H.264(MP), M-JPEG Bitrate Control H.264 – VBR Max. Frame Rate 30fps : 1920 x 1080 Audio Compression G.726, G.711 Supported DirectIP 1920x1080, 1280x720, 704x480, 640x360, 352x240 Resolution Non DirectIP 1920x1080, 1280x720, 704x480, 352x240 Multi-Video DirectIP Quadruple...
  • Page 21 Power Source DC-S1283FX 12 V , 24 V , PoE (Power over Ethernet) (IEEE 802.3af, Class 3) DC-S1283WHX**** 12 V , 24 V , PoE (Power over Ethernet) (IEEE 802.3at, Class 4) Power Consumption 12 V : Max. 10.6W (With heater on: Max. 27.7W) 24 V : Max.
