  • Page 1 DC-S Series Installation Manual DC-S6481HRA Powered by...

  • Page 2: Before Reading This Manual

    Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.

  • Page 3: Safety Precautions

    Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.

  • Page 4: Fcc Compliance Statement

    © 2024 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    • Network bandwidth limitation and MAT features for You can use the IDIS Discovery program to change more efficient use of network bandwidth network camera settings or the IDIS Solution Suite •...

  • Page 7: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Mount Adapter, Screws Allen Wrench Ferrite Core Waterproofing accessory (Bushing, Glue)

  • Page 8: Overview

    Part 1 – Introduction Overview SD Memory Card Slot • Body Assembly Standards Product color and design may vary depending on the For tightening the body. model. • Lens AF Zoom Lens is mounted. • IR LED A sensor in the middle monitors lighting levels and Body activates the IR LED during low-lighting conditions.

  • Page 9: Pendant (Inner View)

    You can configure, manage, and upgrade this camera and monitor its images from a remote computer over the network. For more information on network connection setup, refer to the IDIS Discovery operation manual. The table below shows the network cable specifications.

  • Page 10: Factory Reset

    It's also possible to do a factory reset by pressing and releasing the reset switch while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system.

  • Page 11: Installation

    Part 1 – Introduction Installation Installation Installation of this product does not require the use of • Check the wall or ceiling to see if it needs to be special tools. reinforced. The camera may fall off if the wall or For more information on other devices comprising the ceiling is not strong enough to support its weight.
  • Page 12 Part 1 – Introduction Assemble the mount adapter to the camera body Assemble the pendant and the body by matching and secure it by using the mount adapter screws (3 the installation direction guides. Rotate the camera points). body clockwise to position the reference mark in the upper section and the lower section as shown in the figure.

  • Page 13: Dimensions

    Part 1 – Introduction Dimensions Ø242mm (9.52”) Ø43.5mm (1.71”)

  • Page 14: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP® NVR or non DirectIP® NVR, VMS such as IDIS Solution Suite Compact. With DirectIP® NVR-based Layout Audio In Audio Out Alarm Out 24 VAC Sensor In Power Monitor Out...

  • Page 15: With Non Directip® Nvr-Based Layout

    Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP® NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 16: Part 3 - Appendix

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 10 or below.

  • Page 17: Specifications

    Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/1.8" CMOS Max. Resolution 2688x1520 Scanning Mode Progressive Scan Lens type AF Zoom Lens Focal Length f=6.91 mm ~ 248.76 mm (36x) Aperture F1.35 ~ F4.6 Iris Control P-Iris Angular Field of View...
  • Page 18 Part 3 - Appendix Network Video Compression H.265, H.264(MP), M-JPEG Bitrate Control VBR, CBR Max. Frame Rate 30ips : 2688 x 1520(WDR) Audio Compression ADPCM 16K, G.726, G.711 u-Law, G.711 a-Law Supported Resolution 2688 x 1520, 1920 x 1080, 1280 x 720, 640 x 360 Multi-Video Streaming Quadruple Ethernet...
  • Page 19 Part 3 - Appendix -40°F *** It may not operate normally in an environment where the ambient temperature is below -40°C( -4°F *** If the product is left unattended in an environment where the ambient temperature is below -20°C( ) and the power is turned on, it will boot after internal heating for 5 minutes for normal operation.
  • Page 20 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...

This manual is also suitable for:

Dc-s6481hra
