2.1.2 Heater Kit Installation (Optional)

1. Assemble the Heater board to two bossed with screws.
Take a reference "B" in the bottom case as below.
2. Place the Heater in the slot "A".
Heater cable should be placed away from the Main board.
3. Plug the power connector to the socket "C" (J1) of the Heater board.
4. 24VAC is recommended to use for the camera power for stable operation with heater kit.
• HEATER (IF APPLICABLE)
• POWER
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2
power source only.
CAUTION: Please reset the camera after 30 minutes when installing it in situations colder
than -10°C.
Power Supply
Power Consumption
Heater ON
Heater OFF
24VAC
10W
at 59°F (15°C)
at 77°F (25°C)
10
