TABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ..............4 IMPORTANT SAFETY INSTRUCTIONS ............4 INSTALLATION ................10 Parts and Specifications..................10 Installation Place Requirements..............12 Connecting the Water Inlet Hose ..............13 Installing the Drain Hose .................14...
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk.
Page 5
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • Use a new hose or hose-set supplied with the appliance. Reusing old hoses can cause a water leak and subsequent property damage.
Page 6
• Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
Page 7
• Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
Page 8
• Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the socket outlet. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
Page 9
Disposal • Before discarding an old appliance, unplug it. Cut off the cable directly behind the appliance to prevent misuse. • Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation.
INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View * This feature is only available on some models. Door Handle Tempered Glass Dispenser Drawer Fabric Softener Dispenser Bleach Dispenser Drum Levelling Feet...
Page 11
* This feature is only available on some models. Cold and Hot Water Inlet Hoses Drain Hose Tie Strap* Specifications Model T1369NEFTF Power Supply 220 V~, 50 Hz Dimension 590 mm X 606 mm X 960 mm (Width X Depth X Height) Product Weight Approx.
WARNING • Repairs to the appliance must only be carried out by qualified personnel. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact the LG Electronics service centre. 10 cm 2 cm 2 cm •...
Connecting the Water Inlet Connecting the Hose to the Water Hose Before connecting the water inlet hose to the water Connecting Screw-Type Hose to Tap tap, check the hose fitting type and then choose with Thread the correct instruction. Screw the hose connector onto the water supply Note for Connection tap.
Installing the Drain Hose Connecting the Hose to the Appliance Before connecting the drain hose, check your drain hose model and choose the correct instruction. Screw the water inlet hose to the water inlet valve on the back of the appliance. •...
Levelling the Appliance Checking the Level Levelling the appliance prevents unnecessary noise and vibration. Check whether the appliance is perfectly level after installation. • If the appliance rocks when pushing the top plate of the appliance diagonally, adjust the feet again.
OPERATION Operation Overview NOTE • The Auto Restart function allows the cycle to restart by itself in case of power failure. It Using the Appliance resumes from the stage where it stopped. Before the first wash, select the Normal programme and add a half amount of detergent. Preparing Laundry Start the appliance without laundry.
Page 17
Checking the Fabric Care Label • Wash delicates (stockings, underwired bras) in a wash net. This will tell you about the fabric content of your • Close zippers, hooks and strings to make sure clothes and how it should be washed. that these items do not snag other clothes.
Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring diluted liquid detergent into the drum might Detergent Dosage cause the clothes to be damaged, bleached, discoloured. • Detergent should be selected according to fabric type, colour, soil level and washing temperature and should be used according to NOTE...
Page 19
Adding Fabric Softeners Adding Liquid Bleaches • Softener should be used according to the • Before starting the appliance, pour the softener manufacturer’s instructions. measured amount of bleach directly into the bleach dispenser a. Avoid splashing or • Pour the measured amount of fabric softener overfilling.
Control Panel Control Panel Features * Extra Function : Hold 3 seconds POWER Button • Press the POWER button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. START/PAUSE Button •...
Page 21
Display • The display shows the settings, remaining estimated time, options, and status messages. When the appliance is turned on, the default settings in the display will light up. 88:88 : When a programme is selected, the default time for that programme is displayed. The time •...
Washing Programme • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be Wash programmes are designed for the best wash damaged if they are allowed to float. It is performance for different types of clothes. recommended to purchase a separate laundry •...
Extra Options and Silent Functions Use this programme to wash clothes quietly especially during late night and dawn. You can use the extra options and functions on • This programme has a longer washing time some programmes to customize the cycle. than the Normal programme.
Page 24
Wash • This function cannot be set for less than 3 hours. Adjusting the wash time setting modifies the cycle • To cancel this function, press Delay button times and/or wash actions. repeatedly until the reservation is cancelled • Press Wash button until the desired wash time or press the POWER button to turn off and on is selected.
Page 25
Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the POWER button. Press the Rinse button. Press the Spin button. Press the Rinse button.
• If the data transfer is poor due to poor call Use this function if you need an accurate diagnosis quality, you may not receive the best diagnosis by an LG Electronics customer information centre service. when the appliance malfunctions or fails. Use this function only to contact the service representative, not during normal operation.
MAINTENANCE Cleaning the Appliance WARNING Periodically • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, Tub Clean electric shock, or death. This function is a special to help to clean the inside •...
Page 28
Cleaning the Water Inlet Filter CAUTION Water inlet filter collects lime or any small objects • Clean the lint filter after at least 2 - 3 washes. that may be in water supplied to the appliance. • Do not drop the filter on the floor. Clean the water inlet filter regularly.
Page 29
Wash the filter. How to Keep the Appliance from Freezing After closing the tap, disconnect the cold water inlet hose from the tap, and remove water while keeping the hose facing downwards. Close the lid and then insert the lower part of the filter into the wash drum.
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting.
Page 31
Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. • Turn off the appliance and then press the POWER button. Press the FOREIGN OBJECTS Spin button without selecting a cycle to drain and spin the laundry. When ERROR the spin is complete, remove the clothes and then find and remove any objects caught in the pulsator gap.
Page 32
Symptoms Possible Cause & Solution Sensor for clothes-sensing is defective. CLOTHES SENSING • Manually redistribute the laundry if laundry have become tangled. ERROR Motor’s revolution is too low. Contact-point of Connector is defective. • Unplug the appliance and wait 60 seconds. Reconnect power and try again.
Page 33
Operation Symptoms Possible Cause & Solution Water inlet hose connection is loose at tap or appliance. Water leaking • Check hoses for leaks, cracks and splits. • Tighten hose connections. House drain pipes are clogged. • The appliance pumps out water very rapidly. Check for water backing up out of the drain pipe during drain.
Page 34
Symptoms Possible Cause & Solution Control panel has powered off due to inactivity. Appliance will not operate. • This is normal. Press the POWER button to turn on the appliance. Appliance is unplugged. • Make sure that the cord is plugged securely into a working outlet. Water supply is turned off.
Page 35
Symptoms Possible Cause & Solution Filter is clogged. Appliance is not filling properly. • Make sure the inlet filters on the fill valves are not clogged. Water inlet hose(s) may be kinked. • Check that inlet hose(s) are not kinked or clogged. Insufficient water supply.
Page 36
Symptoms Reason Bleach or softener dispensed too soon. • Dispenser compartment is overfilled causing bleach or softener to Staining dispense immediately. ALWAYS measure bleach to prevent overfilling. • Close the dispenser drawer gently. Bleach or softener was added directly to the laundry in the drum. •...
• Costs associated with removal of your Product from your home for repairs. • The removal and reinstallation of the Product if it is installed in an inaccessible location or is not installed in accordance with published installation instructions, including LG’s owner’s and installation manuals.
Page 42
التلف أو العطل الناتج عن تيار كهربي أو جهد غير صحيح، أو أعمال السباكة أو االستخدام التجاري أو الصناعي، أو استخدام .LG الملحقات، أو المكونات، أو مواد التنظيف المستهلكة غير المعتمدة من شركة التلف الناتج عن النقل والتوصيل، بما في ذلك الخدوش، و/أو االعوجاج، و/أو كسر أج ز اء، و/أو أي تلف آخر في تشطيب المنتج، ما لم تكن...
Page 43
السبب األعراض .عدم إفراغ حمولة الجهاز بشكل سريع الكرمشة .أزل دائ م ً ا األغ ر اض من الجهاز بمجرد اكتمال الدورة .زيادة حمولة الجهاز .يمكن وضع الحمولة كاملة في الجهاز، ولكن دون تكديس كمية كبيرة من األغ ر اض داخل الحلة .ينبغي...
Page 44
األسباب المحتملة والحلول األعراض . ٍ خرطوم التصريف ملت و .تأكد من أن خرطوم التصريف غير ملتو .ال يقوم الجهاز بتصريف المياه .يوضع خرطوم التصريف على ارتفاع أعلى من 2.1 م عن األرض .تأكد من عدم وضع خرطوم التصريف على ارتفاع أعلى من 2.1 م من قاعدة الجهاز .استخدام...
Page 45
األسباب المحتملة والحلول األعراض .تم إيقاف تشغيل لوحة التحكم بسبب التوقف عن التشغيل .لن يعمل الجهاز .هذا أمر طبيعي، اضغط على زر طاقة لتشغيل الغسالة .تم فصل الطاقة عن الجهاز .تأكد من توصيل السلك بأمان في مقبس يعمل .تم إيقاف إمداد الماء .قم...
Page 46
التشغيل األسباب المحتملة والحلول األعراض .إن توصيل خرطوم إمداد الماء بالصنبور أو الجهاز غير م ُ حكم .افحص الخ ر اطيم للتأكد من عدم وجود تسريب أو انفصال أو تشققات تسرب الماء .اربط الخرطوم بإحكام .انسداد أنابيب خرطوم التصريف يقوم الجهاز بضخ الماء بسرعة كبيرة. افحص الماء الذي يتم إخ ر اجه من أنبوب التصريف أثناء عملية...
Page 47
الضوضاء التي قد تسمعها األسباب المحتملة والحلول األعراض .قد توجد أجسام غريبة مثل المفاتيح أو القطع المعدنية أو دبابيس السالمة في حلة الغسيل قم بإيقاف تشغيل الجهاز، وافحص حلة الغسل بح ث ً ا عن أجسام غريبة. إذا استمر صدور صوت صوت...
Page 48
األسباب المحتملة والحلول األعراض .عملية إعادة توازن غير ناجحة إن العملية التلقائية إلعادة توازن الحمولة غير ناجحة. تم إيقاف الدورة مؤق ت ً ا للسماح بضبط عطل عدم توازن .الحمولة يدو ي ً ا .الحمولة صغيرة للغاية .أضف المزيد من األغ ر اض ل ت ُ مكن الجهاز من خلق توازن بين الغسيل .تم...
Page 49
يمكن أن يؤدي تشغيل الجهاز إلى األعطال واألخطاء. تشمل الجداول التالية األسباب المحتملة ومالحظات لحل رسائل الخطأ أو األعطال. يمكنك معالجة . الجدول التالي سيساعدكLG Electronics معظم المشكالت بنفسك، وبالتالي تدخر الوقت والمال، حيث إنك لست بحاجة إلى االتصال بمركز خدمة...
Page 50
كيفية حماية الجهاز من التجمد .قم بغسل الفلتر بعد غلق الصنبور، افصل خرطوم اإلدخال البارد من الصنبور، وأزل .الماء مع الحفاظ على توجيه الخرطوم ألسفل ،أغلق الغطاء ثم أدخل الجزء السفلي من المصفاة في حلة الغسيل ثم اضغط على الجزء العلوي من المصفاة حتى تسمع صوت .طقطقة...
Page 51
تنظيف فلتر الوبر تنظيف فلتر إدخال الماء ي ُ عد الفلتر من األجزاء الهامة لتحقيق فعالية أداء الغسيل، لذلك فهو يحتاج يعمل فلتر إدخال المياه على جمع ترسيب الجير أو أي أجسام صغيرة .منك إلى عناية خاصة. نوصي بتنظيف الفلتر بصفة منتظمة قد...
Page 52
الصيانة تنظيف الجهاز بصورة دورية تحذير افصل الجهاز قبل التنظيف لتجنب خطر التعرض لصدمة تنظيف الحوض كهربائية. قد يؤدي عدم اتباع هذا التحذير إلى التعرض إلى ،إصابة خطيرة، أو نشوب حريق، أو التعرض لصدمة كهربائية هذه الوظيفة هي وظيفة خاصة للمساعدة على تنظيف الجزء الداخلي .أو...
Page 53
إذا كان نقل البيانات ردي ئ ً ا بسبب تدني جودة المكالمة، فقد ال .تتلقى أفضل خدمة تشخيص استخدم هذه الوظيفة إذا كنت بحاجة لتشخيص دقيق عن طريق مركز عندما تحدث أعطالLG Electronics معلومات العمالء في شركة أو فشل بالجهاز. استخدم هذه الوظيفة فقط لالتصال بممثل الخدمة، ليس .أثناء عملية التشغيل العادية...
Page 54
الغسيل اليدوع .عند الحاجة إلى دورة شطف ودوران أو دوران فقط أو شطف فقط أو غسيل فقط، يمكن ضبط ذلك يدو ي ً ا غسيل فقط شطف فقط دوران فقط الشطف والدوران أو .اضغط على زر طاقة .اضغط على زر غسيل .اضغط...
Page 55
نقع شطف يمكن تحديد هذا الخيار لغسيل المالبس شديدة االتساخ عن طريق نقعها .استخدم هذا الخيار لتغيير عدد م ر ات الشطف .في الماء لبعض الوقت لتسهيل إزالة األوساخ والبقع العنيدة .اضغط على زر شطف لتغيير عدد م ر ات الشطف اضغط...
Page 56
المزيد من الخيارات والوظائف مادم استخدم هذا البرنامج لغسيل المالبس بهدوء، خاصة خالل الساعات يمكنك استخدام الخيارات والوظائف اإلضافية في بعض البرامج .المتأخرة من الليل والصباح الباكر .لتخصيص الدورة .يستغرق هذا البرنامج وق ت ً ا أطول من برنامج عادع يمكن...
Page 57
برنامج الغسيل ضع فرش السرير ثم انقعها وأغرقها في المياه لتقليل احتمالية طفوها. في حالة طفو األغ ر اض أثناء الغسل أو التدوير، فقد .يتعرض الجهاز أو المالبس إلى الضرر برامج الغسيل م ُ صممة لتحقيق أفضل أداء للغسيل لكل نوع مختلف من .المالبس...
Page 58
شاشة العرض تعرض شاشة العرض اإلعدادات، والوقت المتبقي ال م ُ قدر، والخيا ر ات، ورسائل الحالة. عندما يتم تشغيل الجهاز، ستضيء اإلعدادات .االفت ر اضية في شاشة العرض 88:88 .: عند اختيار البرنامج، يتم عرض الوقت االفت ر اضي له. يمكن تغيير الوقت تب ع ً ا لتغير البرنامج --:-- ., سيظهر...
Page 59
لوحة التحكم ميزات لوحة التحكم * Extra Function : Hold 3 seconds طاقة زر .اضغط على زر طاقة لتشغيل الجهاز أو إغالقه .يتوقف الجهاز تلقائ ي ً ا عن التشغيل بعد وقت محدد من انتهاء الغسيل تشغيلفتوقف مغقت زر .اضغط على زر تشغيلفتوقف مغقت لبدء دورة الغسيل أو إيقافها مؤق ت ً ا .اضغط...
Page 60
إضافة مبيضات سائلة إضافة منعم األقمشة يجب استخدام منعم األقمشة وف ق ً ا لتعليمات الشركة المصنعة قبل تشغيل الجهاز، اسكب الكمية التي قمت بمعايرتها من المب ي ّض مباشر ة ً في موزع المب ي ّض . تجنب الرش أو الملء .له...
Page 61
،إضافة المنظفات، ومنعمات األقمشة تنبيه والمبيضات استخدام منظفات الغسيل السائلة دون تخفيف، أو ترك المالبس لفترة طويلة بعد إضافة منظفات الغسيل المخففة بالماء في حوض الغسيل قد يسبب ضرر ً ا بالمالبس أو يؤدي إلى تبييضها مقدار المنظف .أو تغيير ألوانها يجب...
Page 62
التحقق من ملصق االهتمام بالنسيج امسح األوساخ والبقع من خالل نقع األوساخ والبقع بمقدار صغير من المنظف المذاب في الماء ثم استخدم الفرشاة .سيوضح لك هذا الملصق محتويات أقمشة مالبسك وطريقة غسلها .إل ز التها تنبيه الرموز الموجودة على ملصقات العناية ال...
Page 63
التشغيل لمحات عامة عن التشغيل مالحظة تتيح وظيفة إعادة البدء التلقائي إعادة تشغيل الدورة تلقائ ي ً ا في حال انقطاع التيار الكهربائي. وتستأنف الدورة التشغيل من استخدام الجهاز .عند نقطة التوقف قبل الغسل ألول مرة، قم باختيار عادع البرنامج وأضف نصف كمية .المنظف.
Page 64
ضبط مستوى الجهاز التحقق من ضبط المستوى يمنع ضبط مستوى الجهاز الضوضاء غير الضرورية واالهتزاز. تحقق .مما إذا كان المستوى مناس ب ً ا بعد التركيب في حالة تأرجح الجهاز عند الضغط على اللوحة العلوية .للجهاز بشكل قطري، قم بتعديل األقدام مرة أخرى ضبط...
Page 65
تركيب خرطوم التصريف توصيل الخرطوم بالجهاز ث ب ّت خرطوم إدخال المياه بمسمار بصمام إدخال المياه الموجود في ظهر قبل توصيل خرطوم التصريف، تأكد من طراز خرطوم التصريف .الجهاز .الخاص بك واختر التعليمات الصحيحة بالنسبة للط ر ا ز ات ذات المدخل الواحد، فال تقم بتوصيل الخرطوم...
Page 66
توصيل خرطوم إدخال المياه توصيل الخرطوم بصنبور الماء قبل توصيل خرطوم إدخال الماء بالصنبور، تحقق من نوع الخرطوم توصيل الخرطوم اللولبي بالصنبور المزود بأسنان .المالئم ثم اختر تعليمات التركيب الصحيحة المسمار موصل خرطوم على صنبور إمدادات المياه. تشديد اليد فقط مالحظات...
Page 67
أن تؤدي اإلصالحات التي تتم من قبل أشخاص ليس لديهم خبرة إلى التعرض إلى إصابة أو عطل خطير. اتصل بمركز خدمة .LG Electronics يجب توصيل قابس الطاقة بمقبس تيار مناسب مر ك َّ ب ومؤرض .وف ق ً ا لجميع القوانين واللوائح المحلية...
Page 69
التركيب األجزاء والمواصفات مالحظة .يمكن تغيير الشكل والمواصفات دون إخطار بذلك من أجل تحسين جودة الجهاز المنظر األمامي .* هذه الخاصية متاحة في بعض الطرازات فقط الباب الحامل زجاج مق س ّ ى درج الموزع موزع منعم القماش موزع المب ي ّض الحوض...
Page 70
.من مقبس الخرج احرص دائ م ً ا على اإلمساك به بإحكام قبل أن تقوم بجذبه في وضعية مستقيمة بتفكيك الجهازLG Electronics يجب أن يقوم فقط موظف خدمة مؤهل من مركز خدمة شركة في حالLG Electronics أو إصالحه أو تعديله. تواصل مع مركز معلومات العمالء في شركة...
Page 71
.حريق أو وقوع انفجار .ال تقترب أب د ًا من الجهاز في أثناء تشغيله. انتظر حتى تتوقف حلة الغسيل تما م ً ا LG Electronics في حال حدوث تسرب مائي من الجهاز، افصل مقبس الطاقة واتصل بمركز .لمعلومات العمالء أغلق صنابير المياه لتحرير الضغط عن الخراطيم والصمامات والحد من التسرب عند حدوث قطع...
Page 72
مناطق مطبخ الموظفين في المتاجر والمكاتب وبيئات العمل األخرى؛ منازل المزارعين؛ بواسطة العمالء في الفنادق، والفنادق الصغيرة والبيئات السكنية؛ بيئات نوع المبيت واإلفطار؛ .المناطق المخصصة لالستخدام المشترك في الوحدات السكنية والمغاسل .يجب أن يكون ضغط ماء اإلمداد ما بين 03 و008 كيلو باسكال .السعة...
Page 73
إرشادات السالمة يتمثل الغرض من إرشادات السالمة التالية في الحيلولة دون وقوع المخاطر غير المتوقعة أو األضرار .الناجمة عن التشغيل غير اآلمن أو غير الصحيح للمنتج .يتم تقسيم اإلرشادات إلى "تحذير" و"تنبيه" على النحو الموضح أدناه ،يتم عرض هذا الرمز لإلشارة إلى األمور وعمليات التشغيل التي يمكن أن تسبب مخاطر فاحرص...
Page 74
جدول المحتويات قد يحتوي هذا الدليل على صور أو محتوى يختلف عن الطراز .الذي قمت بشرائه .يخضع هذا الدليل للمراجعة من الشركة المص ن ّ عة 4 ................إرشادات السالمة 4 ..................إرشادات السالمة الهامة 8 ..................التركيب 8 ..................األجزاء والمواصفات 10 ................
