OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is
installed correctly and safely. Leave these instructions near the
product after installation for future reference.
T1366NEFV
T1366NEFVF
EN ENGLISH
MFL70702218
Rev.01_060319
Copyright © 2019 LG Electronics Inc. All Rights Reserved
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG T1366NEFV
Summary of Contents for LG T1366NEFV
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. T1366NEFV T1366NEFVF EN ENGLISH www.lg.com MFL70702218 Rev.01_060319 Copyright © 2019 LG Electronics Inc. All Rights Reserved...
-
Page 3: Table Of Contents
TABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS ..............4 IMPORTANT SAFETY INSTRUCTIONS ............4 INSTALLATION ................10 Parts and Specifications..................10 Installation Place Requirements..............12 Connecting the Water Inlet Hose ..............13 Installing the Drain Hose .................14... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. - Page 5 • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • Use a new hose or hose-set supplied with the appliance. Reusing old hoses can cause a water leak and subsequent property damage.
- Page 6 • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
- Page 7 • Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
- Page 8 • Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the outlet socket. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
- Page 9 Disposal • Before discarding an old appliance, unplug it. Cut off the cable directly behind the appliance to prevent misuse. • Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation.
-
Page 10: Installation
INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View * This feature is only available on some models. Door Tempered Glass Dispenser Drawer Fabric Softener Dispenser Bleach Dispenser Drum Levelling Feet Drain hose*... - Page 11 2 water supply hoses Drain hose Anti-rat cover (Hot + Cold) Screw for Anti-rat cover (Optional) Specifications Model T1366NEFV T1366NEFVF Power Supply 220-240 V~, 50 Hz Dimension 590 mm X 606 mm X 960 mm (Width X Depth X Height) Product Weight...
-
Page 12: Installation Place Requirements
WARNING • Repairs to the appliance must only be carried out by qualified personnel. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact the LG Electronics service centre. 2 cm 2 cm 10 cm •... -
Page 13: Connecting The Water Inlet Hose
Connecting the Water Inlet Connecting the Hose to the Water Hose Before connecting the water inlet hose to the water Connecting Screw-Type Hose to Tap with tap, check the hose fitting type and then choose Thread the correct instruction. Screw the hose connector onto the water supply tap. -
Page 14: Installing The Drain Hose
Installing the Drain Hose Connecting the Hose to the Appliance Before connecting the drain hose, check your drain hose model and choose the correct instruction. Screw the water inlet hose to the water inlet valve on the back of the appliance. Installing the Drain Hose with the •... -
Page 15: Levelling The Appliance
Levelling the Appliance Assembling the Anti-Rat Cover You can insert the anti-rat cover according to the type to protect the appliance from the rat. Checking the Level Levelling the appliance prevents unnecessary Flat Type noise and vibration. Check whether the appliance Insert the flat type of the anti-rat cover to the is perfectly level after installation. -
Page 16: Operation
OPERATION Operation Overview NOTE • The Auto Restart function allows the cycle to restart by itself in case of power failure. It Using the Appliance resumes from the stage where it stopped. Before the first wash, select the Normal programme and add a half amount of detergent. Start the appliance without laundry. -
Page 17: Preparing Laundry
Preparing Laundry NOTE • The dashes under the symbol give you Sort laundry for best washing results, and then information about the type of fabric and the prepare laundry according to the symbols on the maximum allowance of mechanical stress. care labels. -
Page 18: Adding Detergents, Softeners And Bleaches
Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring diluted liquid detergent into the drum might Detergent Dosage cause the clothes to be damaged, bleached, discoloured. • Detergent should be selected according to fabric type, colour, soil level and washing temperature and should be used according to NOTE... - Page 19 Adding Fabric Softeners Adding Liquid Bleaches • Softener should be used according to the • Before starting the appliance, pour the softener manufacturer’s instructions. measured amount of bleach directly into the bleach dispenser a. Avoid splashing or • Pour the measured amount of fabric softener overfilling.
-
Page 20: Control Panel
Control Panel Control Panel Features POWER Button • Press the POWER button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. START/PAUSE Button • Press the START/PAUSE button to start or pause a wash cycle. •... - Page 21 Display • The display shows the settings, remaining estimated time, options, and status messages. When the appliance is turned on, the default settings in the display will light up. • 18:88 : When a programme is selected, the default time for that programme is displayed. The time can change as options are selected.
-
Page 22: Washing Programme
Washing Programme Duvet Use this programme to wash a blanket or Wash programmes are designed for the best wash bedclothes that have the hand wash sign on the performance for different types of clothes. care label. • Press the Program button to select the •... -
Page 23: Option Programme
Option Programme Silent Use this programme to wash clothes quietly especially during late night and dawn. Soil Level • This programme has a longer washing time Use this option to select the wash strength. than the Normal programme. • 3 levels are selected for Heavy, Normal and •... - Page 24 Rinse Delay • Use this option to change the number of rinses. Use this function to delay ending time. The appliance will start automatically and finish after a • Press Rinse button to change the number of specified time interval. rinses.
- Page 25 Child Lock Use this function to disable the controls. This function can prevent children from changing programmes or operating this appliance. NOTE • Once this function is set, all buttons are locked except the POWER button. • When the controls are locked, and the remaining time are alternatively shown on the display during the wash while the child lock is...
- Page 26 Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the POWER button. Press the Rinse Press the Rinse Press the Wash Press the Spin button.
-
Page 27: Smart Functions
• If the data transfer is poor due to poor call Use this function if you need an accurate diagnosis quality, you may not receive the best diagnosis by an LG Electronics customer information centre service. when the appliance malfunctions or fails. Use this function only to contact the service representative, not during normal operation. -
Page 28: Maintenance
MAINTENANCE Cleaning the Appliance WARNING Periodically • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, Tub Clean electric shock, or death. This function is a special to help to clean the inside •... - Page 29 Cleaning the Lint Filter • For models without a lint filter, the lint is discharged when the water drains during The filter is an important part for an efficient washing. washing performance result, so take a special • After finishing this programme, open the care.
- Page 30 Wash the filter. How to Keep the Appliance from Freezing After closing the tap, disconnect the cold water inlet hose from the tap, and remove water while keeping the hose facing downwards. Close the lid and then insert the lower part of the filter into the wash drum.
-
Page 31: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 32 Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. • Turn off the appliance and then press the POWER button. Press the FOREIGN OBJECTS Spin button without selecting a cycle to drain and spin the laundry. When ERROR the spin is complete, remove the clothes and then find and remove any objects caught in the pulsator gap.
- Page 33 Symptoms Possible Cause & Solution Sensor for clothes-sensing is defective. CLOTHES SENSING • Manually redistribute the laundry if laundry have become tangled. ERROR Motor’s revolution is too low. Contact-point of Connector is defective. • Unplug the appliance and wait 60 seconds. Reconnect power and try again.
- Page 34 Operation Symptoms Possible Cause & Solution Water inlet hose connection is loose at tap or appliance. Water leaking • Check hoses for leaks, cracks and splits. • Tighten hose connections. House drain pipes are clogged. • The appliance pumps out water very rapidly. Check for water backing up out of the drain pipe during drain.
- Page 35 Symptoms Possible Cause & Solution Control panel has powered off due to inactivity. Appliance will not operate. • This is normal. Press the POWER button to turn on the appliance. Appliance is unplugged. • Make sure that the cord is plugged securely into a working outlet. Water supply is turned off.
- Page 36 Symptoms Possible Cause & Solution Filter is clogged. Appliance is not filling properly. • Make sure the inlet filters on the fill valves are not clogged. Water Inlet hose(s) may be kinked. • Check that inlet hose(s) are not kinked or clogged. Insufficient water supply.
- Page 37 Symptoms Reason Bleach or softener dispensed too soon. • Dispenser compartment is overfilled causing bleach or softener to Staining dispense immediately. ALWAYS measure bleach to prevent overfilling. • Close the dispenser drawer gently. Bleach or softener was added directly to the laundry in the drum. •...
-
Page 38: No Limited Warranty
