HealthyAir Source Capture HA-SSC-G4-AE Owner's Manual

Aerosol extractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Source Capture
Aerosol Extractor
HA-SSC-G4-AE
Owner's Manual

Table of Contents

800-259-2535
www.HealthyAir.com
®
1
2
3
4
5
6
7-10
11-12
13-15
16
17-21
22
23
24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Source Capture HA-SSC-G4-AE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HealthyAir Source Capture HA-SSC-G4-AE

Summary of Contents for HealthyAir Source Capture HA-SSC-G4-AE

  • Page 1: Table Of Contents

    Source Capture ® Aerosol Extractor HA-SSC-G4-AE Owner's Manual Table of Contents HealthyAir® Series 1213 Filters Important Safety Instructions Technical Specifications Packaging Reference Packaging Notice Component Reference 7-10 Assembly Instructions 11-12 Operation Guidelines 13-15 Filter Replacement Maintenance 17-21 Basic Service and Troubleshooting...

  • Page 2: Healthyair® Series 1213 Filters

    ® HealthyAir Model HA-SSC-G4-AE Source Capture Aerosol Extractor with ® HealthyAir Series 1213 Filters ® HealthyAir ® ® HealthyAir HealthyAir eHEPA® Filter Pre-Filter Activated Carbon Filter...

  • Page 3: Important Safety Instructions

    WARNING Unplug the power cord before servicing or replacing filters. Failure to do so could result in serious personal injury and death. I. Important Safety Instructions Read the Owner's Manual and Important Safety Instructions carefully. Failure to follow these instructions could cause a malfunction of the filter or unsatisfactory performance.

  • Page 4: Technical Specifications

    II. Technical Specifications Model Number HA-SSC-G4-AE-W/B Rated Voltage 120V/60HZ Power Consumption 200W Weight 48 lbs. (22 kg) Base Dimensions 16x14x20 in (40×35×51 cm) Flex Hose Length 5 ft. (1.52 m) Air Flow Rate 200 cfm (325 m Noise Level 56 dB...

  • Page 5: Packaging Reference

    III. Packaging Reference The Source Capture Air Purification System is shipped in two (2) cartons, as follows: Carton 1: (1) Air Purification Unit w/ (3) Filters, (4) Wheel Casters, (1) Remote Control, (1) Power Cord, (1) Screwdriver, (1) Manual Carton 2: (1) Flex Hose w/ Hood, (1) Inlet Tube, (1) Hose Clamp...

  • Page 6: Packaging Notice

    IV. Packaging Notice NOTICE Before operating the machine, do the following: 1. Open the Access Door 2. Remove the HEPA and Activated Carbon Filter 3. Remove the plastic wrapping from the filter! 4. Re-install the HEPA and Activated Carbon Filter 5.

  • Page 7: Component Reference

    V. Component Reference 1. Outer Frame 9. eHEPA Filter 18. Flex Hose 2. Blower/Motor 10. eGrid 19. Hood 3. Base Plate 11. Pre-Filter 20. Display Panel 4. Caster Wheels 12. LED Cable Plug 21. Main PCB 5. Motor Mounting Plate 13.

  • Page 8: Assembly Instructions

    VI. Assembly Instructions 6.1 Install Wheel Casters 6.1.1 Place the unit on its side on a flat surface, as shown in Fig. 1. 6.1.2 Locate the four (4) Caster Wheels and the Screwdriver that are provided in Carton 1. 6.1.3 Unscrew and remove the screws that are pre-mounted onto the Base Plate on the bottom of the unit.
  • Page 9 VI. Assembly Instructions 6.2 Install Inlet Tube 6.2.1 Unscrew and remove the six (6) M5x16 screws that are pre- mounted around the 4” Ø cutout on the top of the unit, as shown in Fig. 2. 6.2.2 Position the Inlet Tube on top of the unit, such that the tube aligns with the 4”...
  • Page 10 VI. Assembly Instructions 6.3 Install Flex Hose The Flex Hose is constructed of interlocking bands that enable its length and shape to be adjusted. Note that, the Flex Hose will unravel if it is lengthened or bent past its tolerance point. The diameter of the Flex Hose can be also slightly adjusted by twisting the hose.
  • Page 11 VI. Assembly Instructions 6.4 Unwrap and Reinstall Filters 6.4.1 Open and remove the Access Door, located on the Back Panel of the unit, by unscrewing the two (2) Thumb Screws. When opening the Access Door for the first time, some force may be required to pry open and break the seal.

  • Page 12: Operation Guidelines

    VII. Operation Guidelines 7.1 Source Capture System Positioning Place the HealthyAir® Source Capture Aerosol Extractor in the desired location and adjust the Flex Hose to position the Hood approximately 6” from the source. 7.2 Source Capture System Activation 7.2.1 Plug the Power Cord into the Power Socket, located on the bottom of the side panel of the unit, and then plug the other end of the cord into a wall power socket.
  • Page 13 VII. Operation Guidelines 7.3 Source Capture System Controls • TIMER button is for operation of the timing clock. When this feature is in use the unit will automatically shut off after the set time expires. The system's default timing is 4 hours of operation. To set the timer manually, press the TIMER button once for every hour you wish to run the machine (i.e.

  • Page 14: Filter Replacement

    VIII. Filter Replacement 8.1 Replacement Filters The HealthyAir® Source Capture Aerosol Extractor Model HA-SSC-G4- AE utilizes the HealthyAir® Series 1213 Replacement Filters, as follows: • HealthyAir® Pre-Filter: Model No. HA-PF-1213 • HealthyAir® eHEPA® Filter: Model No. HA-EH-1213 • HealthyAir® Activated Carbon Filter: Model No. HA-PF-1213 Note that, only manufacturer supplied HealthyAir®...
  • Page 15 VIII. Filter Replacement 8.2 Filter Replacement 8.2.4 Install a new set of HealthyAir® Series 1213 Replacement Filters. 8.2.5 Reinstall the Access Door, ensuring that the Access Door is properly inserted back into its track. Once the Access Door is properly aligned and set in place, secure it by screwing in the Thumb Screws.
  • Page 16 VIII. Filter Replacement 8.3 Filter Change Indicator Light Reset Once the filters have been replaced and the unit is powered on, the Filter Change indicator light may continue to flash. To reset the filter change timer and deactivate the flashing light, go through the following reset procedure: 8.3.1 Unplug the Power Cord from the Power Socket, wait a couple seconds and plug the Power Cord back into the Power Socket.

  • Page 17: Maintenance

    IX. Maintenance 9.1 Cleaning Filter Compartment Visually inspect the interior of the Filter Compartment when the filters are removed from the unit during the filter replacement process. If debris has accumulated in the Filter Compartment, clean the interior of the unit as follows: 9.1.1 Turn the Power Off, unplug the Power Cord from the Power Socket, remove the Access Door, and remove the filters from the...

  • Page 18: Basic Service And Troubleshooting

    X. Basic Service and Troubleshooting The Basic Service Guide should cover most performance issues. If you continue to experience issues after referring to this list, please contact Healthy Air Inc. 10.1 Air Purification System Inoperable If the unit fails to power on, the issue may be the result of one of the following causes.
  • Page 19 X. Basic Service and Troubleshooting 10.3 Air Purification System Power On but Fan Inoperable If the unit powers on but the fan fails to operate, the issue may be the result of a faulty motor and will require service by the manufacturer or a professionally licensed electrician.
  • Page 20 X. Basic Service and Troubleshooting 10.5 eGrid Activity Indicator Light Not Lit If the eGrid Activity indicator light fails to turn on when the eHEPA® system is on, the issue may be the result of one of the following causes and will require service by the manufacturer or a professionally licensed electrician.
  • Page 21 X. Basic Service and Troubleshooting 10.7 Flex Hose Unravels If the Flex Hose is lengthened or expanded past its tolerance point, the hose may come apart and unravel. The issue may be the result of one of the following causes and may require replacement parts. Possible Cause Solution Expanded past tolerance...
  • Page 22 X. Basic Service and Troubleshooting 10.11 Reduced Airflow and/or Odor Absorption If the fan/motor is properly functioning, but the unit exhibits reduced airflow and/or reduced odor absorption the issue may be the result of one of the following causes and may require replacement filters. Possible Cause Solution Pre-Filter is fully loaded...

  • Page 23: Electrical Wiring Schematic

    XI. Electrical Wiring Schematic Fig. 9 – Electrical Wiring Schematic...

  • Page 24: 1-Yeart Limited Warranty

    Healthy Air Inc. only makes this 1-Year Limited Warranty ("Limited Warranty") to the original retail purchaser who submits the enclosed Warranty Registration Card within 10 days of purchase by email to Sales@HealthyAir.com. This Limited Warranty applies only to the repair or replacement of any manufactured or supplied part of this product which, upon inspection by Healthy Air Inc.

  • Page 25: Product Registration Form

    Sales@HealthyAir.com. Note that, the Model Number and Serial Number are written on the sticker located at the bottom of the side panel of the unit. Please contact us at (800) 259-2535 or visit www.HealthyAir.com for Customer Service and Orders. Name:...
