Function
The ZSR series is multi-zone pump and boiler operating
control for multiple zone hydronic heating or cooling
systems. The ZSR series interfaces with low voltage
thermostats, or any other low voltage controllers having
a switching action. The ZSR series controls up to
3, 4, 5 or 6 heating circulator pumps (depending
on model selected) a primary pump and has LED
indicators to provide functional status and easy system
troubleshooting. In addition, a primary pump system
circulator is switched on whenever any zone calls for
heat.
12 VA (ZSR103/4), 20 VA (ZSR106)
Certified to CSA C22-2 No.24
Conforms to UL Standard 873
NA10334
ZSR10X series
ABS
LED
(12) 1/2" size
120 VAC, 50/60 Hz
24 VAC
20A max combined
120 VAC, 5A each
120 VAC max, 2A each
Type 2AG, 5A slow blow
110°F (43°C)
110°F (43°C)
90% non-condensing
