Installation, Operation, and Maintenance Manual
HOT WATER PRESSURE WASHER
To the Owner:
Thank you for purchasing a Northstar hot water pressure washer. Your machine is designed for long life,
dependability, and the top performance you demand! Take time now to read through this manual so you will
better understand the machine's operation, maintenance and safety precautions. Everyone who operates this
machine must read and understand this manual. The time you take now will prolong your machine's life and
prepare you for its safe operation. Enjoy the exceptional performance of your Northstar hot water pressure
washer, the industry leader! The manufacturer reserves the right to make improvements in design and/or
changes in specifications at any time without incurring any obligation to install them on units previously sold.
Pump Oil
Pump is shipped with oil. Change oil plug if and check pump oil level before starting.
Use UTTO for Comet and Cat Pump oil (item# 22158) for Cat oil changes.
Water
Make sure your water flow is 20% higher than the pressure washer's flow rate.
Make sure your water is clean and particle free.
Storage
Do not allow water to freeze in the pump, hose, coil, or spray gun.
Spraying
Use any North Star brand or equivalent pressure washer chemicals.
Chemicals
Maintenance
Pump Oil: change after first 50 hours, then every 3 months or 500 hours.
Schedule
Read and understand all manuals before operating.
Any Questions, Comments, Problems or Parts Orders
In the United States
Northstar Customer Service
Call 1-800-270-0810
Hours: Monday - Friday 7:00 AM to 5:30 PM
Saturday 7:30 AM-11:30 AM Central Time
M157305B
HP:______ Volts:______ Amp:______ Ph:_____
RPM:____ PSI:____ GPM:____ Nozzle Size:_____
Pump:___________ Hose:______ Lance:_______
Max. Discharge Temperature:_____________
:
Quick Facts
Northern Tool and Equipment Co. (UK) Ltd.
Portsmouth, Hants PO3 5QD, England
ITEM NUMBER: 157305,306,307,308
SERIAL NUMBER:
Cleans dirty surfaces with high-
pressure hot water.
In the United Kingdom
Call 02392639752
Unit 2, Keel Close,
