North Star M157310AR Owner's Manual

Hot water/steam pressure washer –
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instructions for Set-up, Operation, Maintenance & Storage
H
W
OT
ATER
This pressure washer produces both cold and hot water high pressure spray as well as steam spray. Cleaning
chemicals may be incorporated into the spray if desired. The pressure pump for this equipment is powered by
a gasoline internal combustion engine and the water is heated by a kerosene/fuel-oil fired, open flame burner.
READ and UNDERSTAND this Owner's Manual and the Engine Owner's Manual
completely before attempting to set up and use the pressure washer! Failure to properly set
up, operate, and maintain this pressure washer could result in serious injury or death to operator
or bystanders.
•
CO Poisoning
•
Skin/Eye
Injury
•
•
Burns
•
Slips/Falls
•
•
Flying Debris
•
Fire/
Explosion
•
•
Chemical
Exposure
•
Electric shock
A summary of important safety information is provided at the end of the manual.
Any Questions, Comments, Problems, or Parts Orders
Owner's Manual
/S
P
TEAM
RESSURE
Portable Outdoor-Use Only
WARNING – READ THIS MANUAL
WARNING – SPECIAL HAZARDS
Exhaust from both the engine and burner contains carbon monoxide, a
poisonous gas that can cause carbon monoxide poisoning and possible
death if inhaled. ONLY run pressure washer OUTDOORS and at least 20
feet from the home, away from windows, vents and air intakes, to allow
proper ventilation. If you start to feel sick, dizzy, or weak while using the
pressure washer, shut off the engine and get to fresh air RIGHT AWAY.
High-pressure spray can cause serious skin or eye injury, including injection injury
if fluid pierces the skin. Injection injury can result in blood poisoning and/or
severe tissue damage.
Hot spray can scald and burn skin.
Hot surfaces of wand, engine and burner, as well as hot exhaust from both
the engine and burner can cause burns.
Spray discharge can cause puddles and slippery surfaces.
Spray-gun kickback can cause operator loss of balance and falls.
High-pressure spray can cause surface damage and flying debris.
Engine and burner sparking can ignite fuel or other flammable liquids or
vapors in the vicinity.
Hot exhaust from engine and burner can ignite combustible materials.
Cleaning chemical vapors or contact with skin may be hazardous.
Spray contact with electrical sources can cause electric shock.
Call NorthStar Product Support 1-800-270-0810
M157310A R
ITEM NUMBER: 157310
SERIAL NUMBER: _____________
– 3000
W
ASHER
1
/ 4
PSI
GPM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M157310AR and is the answer not in the manual?

Questions and answers

Related Manuals for North Star M157310AR

Summary of Contents for North Star M157310AR

  • Page 1 M157310A R ITEM NUMBER: 157310 SERIAL NUMBER: _____________ Owner's Manual Instructions for Set-up, Operation, Maintenance & Storage – 3000 ATER TEAM RESSURE ASHER Portable Outdoor-Use Only This pressure washer produces both cold and hot water high pressure spray as well as steam spray. Cleaning chemicals may be incorporated into the spray if desired.
  • Page 2 Hazard Signal Word Definitions This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER (red) indicates a hazardous situation, which if not avoided, will result in death or serious injury.

  • Page 3: Table Of Contents

    Table of Contents About Your Pressure Washer ........................ 4 Specifications ............................5 Component Identification ........................6 Safety Labeling ............................7 Special Equipment Safety Features ....................... 8 Assembly and Initial Set-Up ........................9 Step 1. Unpacking & Delivery Inspection ..................9 Step 2.

  • Page 4: About Your Pressure Washer

    About Your Pressure Washer Thank you for purchasing a NorthStar hot water pressure washer! Your machine is designed for long life, dependability, and the top performance you demand. This pressure washer is designed to: 1) Produce a high-pressure steam spray or water spray (heated or unheated) – up to 4 gallons per minute at 3000 psi.

  • Page 5: Specifications

    Specifications MODEL Model # 157310 FLOW OUTPUT Pressure Rating 3000 psi Flow Rate 4 gpm Maximum Temperature 250 F DIMENSIONS / COMPONENTS Length 64" Width 33" Height 44" 557 lbs. – dry Weight 710 lbs. – fueled Pump Type CAT 66DX Engine Horsepower 390cc Engine and Burner Fuel Tank Sizes...

  • Page 6: Component Identification

    Component Identification Ref # Description Ref # Description Exhaust Vent Control Panel Pump Engine Battery Box Burner Fuel Filter/Water Separator High Pressure Water Outlet Gas Cap Engine on/off key switch Gas Tank Pump Oil Sight Glass Fuel Cap Hose Hook Fuel Tank Gun Hook REFERENCE GUIDE...

  • Page 7: Safety Labeling

    Safety Labeling DANGER FOR OUTDOOR USE ONLY ! Using this pressure washer indoors CAN KILL YOU IN MINUTES. Engine exhaust and burner exhaust contain carbon monoxide. This is a poison you cannot see or smell. IMPORTANT! TURN HEAT SWITCH TO OFF POSITION WHEN NOT IN USE.

  • Page 8: Special Equipment Safety Features

    Special Equipment Safety Features High Pressure WARNING-If the high-pressure safety device ever discharges water, Safety Device turn the engine off and do not use the machine. The device will no longer (Rupture Disc) function properly. See a dealer or call Product Support at 1-800-270- 0810.

  • Page 9: Assembly And Initial Set-Up

    Assembly and Initial Set-Up Steps for Assembly / Initial Set-Up Step 1. Unpacking & Delivery Inspection Step 2. Assembly Step 3. Initial Pump & Engine Preparation Step 4. Battery Installation Each of these steps is discussed in the below: Step 1. Unpacking & Delivery Inspection Find and separate the components identified in Figure 2- Overview of Pressure Washer Components and Figure 3- Hardware Bag.
  • Page 10 Assembly and Initial Set-Up Grommet Qty 6 Nozzle Qty 6 Owner’s Manual Honda Manual Qty: 1 Qty: 1 Hose Hook Wheel Retainer QTY 1 QTY 4 M8 Nylock Nut 5/16” Nut 5/16” Washer QTY 2 QTY 2 QTY 8 4 ft. Braided Hose 5/16”...

  • Page 11: Step 2. Assembly

    Assembly and Initial Set-Up Step 2. Assembly You must assemble your pressure washer before it can be used. See below: Lift back of unit by handles to install rear wheels, then lift front of unit to install front wheels. Fasten wheel with retainer. NOTE: It is recommended that two people lift this unit while a third slides the wheels onto the axles.

  • Page 12: Step 3. Initial Pump & Engine Preparation

    Assembly and Initial Set-Up a. Rear Wheels Have two people lift the back of the pressure washer by the handles while a third person slides the wheels onto the Rear Axle. Fasten each wheel with a wheel retainer using a hex wrench.

  • Page 13: Step 4. Battery Installation

    Assembly and Initial Set-Up Step 4. Battery Installation Install a 12-volt standard lawn and garden battery (Group U1) with a minimum 18 amp- hour rating. The engine will run, but the burner will not fire unless a battery is installed. The battery is to be supplied by the customer and should be installed in the protective battery compartment located near the engine.

  • Page 14: Moving And Handling

    Moving and Handling WARNING The pressures washer is heavy. It can crush and cause serious injury if it rolls out of control or tips over. Follow the instructions below for safely moving the pressure washer. Moving and Handling Lift Here Handles Figure 7 Breaks...

  • Page 15: Before Each Use

    Before Each Use Follow the steps below prior to each use of the pressure washer. Steps to Follow Before Each Use Step 1. Check Equipment Step 2. Add Fuel(s) Step 3. Select Suitable Worksite Step 1. Check Equipment Check/add Check/add pump oil. pump oil Caution: Never run the pump without sufficient lubrication! 1.

  • Page 16: Step 2. Add Fuel(S)

    Before Each Use 1) Check hoses, fittings, wand, trigger gun and connections for signs of wear, cracks, looseness, or leaks. Replace as required. 2) Check and clean the nozzle orifice. 3) Clean inlet filter. (See Maintenance instructions) Inspect fuel Always inspect (engine and burner) fuel systems & check for leaks system BEFORE starting pressure washer.
  • Page 17 Before Each Use Note: A running or still-hot engine or burner is hot enough to ignite fuel. 2) Fill fuel tank OUTDOORS – never indoors. Fuel vapors can ignite if they collect inside an enclosure and explosion can result. 3) Stay away from all sources of heat, sparks, and flames. Do not smoke. 4) Never pump fuel directly into the gas tank or burner at a gas station –...

  • Page 18: Step 3. Select A Suitable Worksite

    Before Each Use Step 3. Select Suitable Outdoor Worksite Before using the pressure washer, you must understand the criteria for selecting a suitable location for operation. Note that this pressure washer is for OUTDOOR USE only. WARNING You must choose a suitable site for operating your pressure washer to avoid equipment damage and/or injury and possible death from carbon monoxide poisoning, fire/explosion, uncontrolled equipment movement/tip over, or slips and falls.
  • Page 19 Before Each Use WARNING Never attempt to attach ductwork to the engine muffler or burner exhaust to allow for installation inside an enclosure. This could cause hot air deflection, heat build-up, and increased exhaust backpressure, resulting in possible exhaust leakage or overheating and damage to the pressure washer.

  • Page 20: Operation

    Operation After you have checked and fueled the equipment and positioned it in a suitable worksite, it is time to start your pressure washer. The following are the procedures necessary for safe, successful operation of your pressure washer. WARNING Carefully read and make sure you understand all instructions and safety information before using the pressure washer.
  • Page 21 Operation including homes, garages, basements, sheds, boxes, pick-up truck beds, RVs, or boats. These spaces can trap poisonous gases, EVEN if you run a fan or open windows. Attach garden Acquire a suitable garden hose and attach to the water supply. hose to water 1.
  • Page 22 Operation 3. Release the collar, making sure it springs back and re-seats to its original (non-retracted) position. (Figure 8b). Check the connection by pulling on the hose to ensure a positive connection. Correct Insertion Not Fully Inserted Figure 8b Collar Seated Collar NOT Seated Select spray Your pressure washer is equipped with five high-pressure nozzles and one...

  • Page 23: Step 2. Set Up For Chemical Spray (If Desired)

    Operation 1. Make sure the engine is off and the hose line depressurized. 2. To install the nozzle, pull the collar back and twist the nozzle firmly into the coupler on the end of the wand. (Figure 9a) Lance Coupler Nozzle Collar Figure 9a...
  • Page 24 Operation cause pump damage if introduced upstream through the pump's water inlet. • It mixes the cleaning chemical into a low-pressure spray. Cleaning chemicals applied under low pressure adhere better to the surface being cleaned, allowing the formula time to react and remove dirt more effectively.

  • Page 25: Step 3. Spraying

    Operation Step 3. Spraying Safety rules Before starting the pressure washer, review the following general safety for operation rules for operation: Conditions for Use Know how to stop. Be thoroughly familiar with proper use of the equipment and all controls and connections. Know how to stop the pressure washer and depressurize system quickly if needed (see "Step 6.
  • Page 26 Operation the locked position when not spraying. Leaving unattended. Always turn off the pressure washer and relieve system pressure before leaving the sprayer unattended. Prompt Emergency Response Seek medical aid for suspected injection injury. If injured by high-pressure fluid, no matter how small the wound is, see a doctor at once.
  • Page 27 Operation by rotating it to the locked position. 3. Follow the instructions in the Engine Manual for starting the engine. - If the engine doesn't start on the first try, pressure may build up in the pump. Relieve pressure by squeezing the spray gun trigger before attempting to start engine again.
  • Page 28 Operation the heat exchanger during operation. Turn the heat switch ON and adjust the thermostat to the desired temperature. (For steam spraying, set the temperature at 212F or higher and use yellow steam nozzle.) WARNING: • NEVER attempt to immediately run or re-light the burner if it doesn't ignite the first time.
  • Page 29 Operation ladder or scaffolding, ensure it is firmly anchored from sway or tip-over. Be aware of puddles and slippery surfaces. Ensure there is adequate drainage to prevent pooling of water. • Prevent surface damage & flying debris – Surfaces being sprayed must be strong enough to withstand high-pressure spray or damage may result.
  • Page 30 Operation WARNING: Do not attempt to alter the unloader valve's maximum pressure. Excess pressure could cause serious injury from escaping high-pressure fluids and/or pump damage. Any alteration other than turning the adjustment knob will void your warranty. Unloader Figure 11 If temporarily interrupting spraying, rotate trigger safety latch downward to the locked position to guard against accidental trigger release.

  • Page 31: Step 4. Stopping

    Operation Step 4. Stopping Stop the engine using the following steps: WARNING: Never disconnect the high-pressure hose from the pump or spray gun while the system is pressurized. Relieve pressure by squeezing the spray gun trigger after the engine is turned OFF.
  • Page 32 Storage Choose a storage Choose a storage location that is: o Clean and dry. location o Away from sources of heat, open flames, sparks, or pilot lights, even if the pressure washer's engine and burner fuel tanks are empty. Residual fuel fumes from tank can ignite. o Away from extreme high or low temperatures.
  • Page 33 Storage RV Antifreeze Funnel Hose Figure 12 Water Inlet Long Term freeze protection: (if storing more than 30 days) The RV antifreeze will save the components from freeze damage and keep them lubricated. 1. Fill bucket with 5 gallons of RV antifreeze. a.
  • Page 34 Storage 2. Lubricate cylinder and piston: a. Disconnect spark plug wire and remove spark plug b. Add one teaspoon oil through spark plug hole c. Place rag over spark plug hole and turn starter (or pull the recoil) a few times to lubricate the combustion chamber. d.

  • Page 35: Burner Adjustment

    Burner Adjustment Oil Burner Adjustment (only needed if white exhaust smoke appears) The oil burner is preset and performance tested at the factory (elevation 1100 feet). Different altitudes may require a one-time initial burner adjustment. CAUTION: If white smoke appears from the burner exhaust vent during start-up or operation, discontinue use and readjust air bands.

  • Page 36: Maintenance And Repair

    Maintenance and Repair Inspect and maintain your pressure washer as specified below in order to keep it in safe and optimal working order. Follow all safety rules and recommended maintenance instructions. WARNING ALWAYS shut off water supply, bleed water pressure, turn off engine and disconnect the spark plug before cleaning, adjusting, or servicing the pressure washer.
  • Page 37 Maintenance and Repair repair parts. Replacement parts that do not meet specifications may result in a safety hazard or poor operation of the pressure washer and will void the warranty. Keep pressure Keep pressure washer clean. washer clean If dust or debris accumulates on the pressure washer, clean the pressure washer with a damp cloth or soft bristle brush.
  • Page 38 Maintenance and Repair Good Water dripping or spraying, or localized moisture Exposed wire mesh due to wear Figure 15 Clean inlet filter Clean the inlet filter before each use. WARNING: When cleaning filters, check whether dangerous chemicals have been used with the filter and take any precautions that may be recommended by the manufacturer of these chemicals.
  • Page 39 Maintenance and Repair Recharge and Inspect, recharge, and maintain battery according to your battery maintain battery manufacturer's instructions. Do not store with battery charger always connected. Batteries that are over- charged can boil themselves dry and produce excessive amounts of hydrogen, an explosive gas.
  • Page 40 Maintenance and Repair Maintain burner's Drain water from burner's filter bowl as needed, and replace filter after fuel filter/water every 500 hours of use or as needed. separator 1) After each use of the burner, visually check the filter bowl. If any water has accumulated, drain it via the water drain at the bottom of the bowl.
  • Page 41 Maintenance and Repair 7) Dispose of the cleaning solution where it is not harmful to animals or the environment. 8) Flush with fresh water and clean the inlet strainer when finished. Figure 18 Cleaning Flow Inspect and clean the flow switch as needed Switch Mineral build-up and/or debris within the flow switch can occur and may affect burner operation if not periodically cleaned.
  • Page 42 Maintenance and Repair 2) Remove the “Cap” fitting from the flow switch. Cap Fitting 3) Slide out the “Shuttle Assembly”. If the magnet in the shuttle assembly is damaged or missing, replace the entire flow switch assembly. To order a replacement flow switch assembly, call Northstar Product Support at 1-800-270-0810.
  • Page 43 Maintenance and Repair 4) Observe the “Shuttle Assembly” and internal portion of “Body” for obstructions, hard water deposits and any other foreign debris. Remove the foreign debris with light scraping or compressed air. If no additional cleaning is required continue to Step 7. If additional cleaning is required continue to step 5.
  • Page 44 Maintenance and Repair 8) Insert the “Shuttle Assembly” with the rounded end first, into the body. Align with grooves. Body (female Guides) Shuttle (Male Tabs) Rounded End First 9) Inspect the O-ring on the “Cap”, if it is damaged, replace the entire flow switch assembly.
  • Page 45 Maintenance and Repair Inspect heating coil Inspect and desoot coil annually. and desoot as Most coils never require desooting. However, poor grades of fuel oil or needed inadequate combustion air will cause heavy soot build-up on the outside surface of the heating coil tubing. These deposits will insulate the coil, which then restricts air flow through the heat exchanger and further aggravates the soot build-up.
  • Page 46 Maintenance and Repair Inspect electrodes Inspect electrodes yearly and make adjustments as needed. 1) Remove the 4 nuts that attach the burner to the heating chamber. You do not have to disconnect the fuel lines or the electric cords. 2) Pull the burner out from underneath the heat exchanger. 3) Clean off carbon deposits, which may have accumulated on the tips of the electrodes.
  • Page 47 Maintenance and Repair NOTE TO COMMERCIAL USERS: All mechanical equipment, no matter how well designed, will need maintenance and repairs. A Northstar pressure washer is no exception. At times, a Northstar pressure washer may become inoperable because repairs are required. Northstar Product Support will assist in these repairs as needed, but if an inoperable pressure washer creates a major expense to your business, then we strongly recommend the following:...

  • Page 48: Troubleshooting

    Troubleshooting Engine Will Not Start Causes Solutions Low Oil Shutdown Fill engine with the adequate amount of oil. Cold Engine Choke engine to start. No Fuel Add gas to fuel tank, make sure fuel shutoff valve is open. Dead Battery Recharge/Replace battery.

  • Page 49: Parts Explosion

    Parts Explosion M157310 – Rev AR...
  • Page 50 Parts Explosion M157310 – Rev AR Ref# Part # Description Ref# Part # Description 793846 Outer Frame 778219 ISO-Mount Plate G 789546 Decal, Instructions 778228 ISO Support Bar 791574 Fuel Tank (Yellow) 777232 Rear Brake 784769 Sealed Fuel Cap 30747 Handle/Brake Grip 791575 Gas Tank (Red)
  • Page 51 Pump Explosion – Rev AR...

  • Page 52: Wiring Diagrams

    Wiring Diagram/Schematic – Rev AR...

  • Page 53: Summary Of Important Safety Information

    Do not allow anyone to operate the pressure washer who has not read the Owner's Manual and been instructed on its safe use. Owner's Manuals are available from North Star at 1-800-270-0810. • Adult control only. Only trained adults should set up and operate the pressure washer. Do not let children operate. Pressure washers can generate forces greater than children can control and require judgment beyond what can be expected of children.
  • Page 54 Summary of Important Safety Information accumulate, even in areas that appear to be well ventilated, resulting in dangerous and fatal concentrations within minutes. To prevent dangerous CO build-up: • ONLY use pressure washer outdoors and at least 20 feet from the home, away from windows, vents and air intakes, to allow proper ventilation.
  • Page 55 Summary of Important Safety Information • Position safely. Place sprayer on firm, level ground to prevent accidental falls and equipment tip-over. • Not in presence of combustibles. Do not use the pressure washer in the presence of flammable vapors, dust, gases, or other potentially combustible materials.
  • Page 56 Summary of Important Safety Information chemicals have been used with the filter and take any precautions that may have been recommended by the supplier of these chemicals. Always dispose of hazardous fluids per local, state, and national guidelines. • Do not exceed pressure and or temperature limits. Do NOT operate this pump with components (such as hose, connections, and spray gun) rated for lower pressure and or temperature limits than the machine's maximum rated pressure and temperature, or component could rupture and cause serious personal injury from escaping high pressure fluids.

  • Page 57: Limited Warranty

    Limited Warranty Dear Valued Customer: The NorthStar Product you just purchased is built with the finest material and craftsmanship. Use this product properly and enjoy the benefits from its high performance. By purchasing a NorthStar product, you show a desire for quality and durability. Like all mechanical equipment this unit requires a due amount of care.

  • Page 58: California Proposition 65 Information

    WARNING : This product can expose you to chemicals including gasoline engine exhaust, which is known to the State of California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
