Installation, Operation, and Maintenance Manual
Cold Water Pressure Washer
To the Owner:
Thank you for purchasing a NorthStar pressure washer. Your machine is designed for long life, dependability,
and the top performance you demand! Take time now to read through this manual so you better understand the
machine's operation, maintenance and safety precautions. Everyone who operates this machine must read and
understand this manual. The time you take now will prolong your machine's life and prepare you for its safe
operation. Enjoy the exceptional performance of your NorthStar pressure washer, the industry leader! The
manufacturer reserves the right to make improvements in design and/or changes in specifications at any time
without incurring any obligation to install them on units previously sold.
Pump Oil
Pump is shipped with oil. Change oil plug and check pump oil level before starting.
Use SAE 30 Non-detergent pump oil (item# 4043) or Cat Pump oil (item# 22158) for oil
changes.
Water
Make sure your water flow is 20% higher than the pressure washer's flow rate.
Make sure your water is clean and particle free. Maximum inlet water temp.
Storage
Do not allow water to freeze in the pump, hose, or spray gun.
Spraying
Use any North Star brand or equivalent pressure washer chemicals.
Chemicals
Adjust soap adjustment knob to regulate cleaning power.
Maintenance
Pump:
Schedule
Read and understand all manuals before operating.
Any Questions, Comments, Problems or Parts Orders
:
Quick Facts
Oil: change after first 50 hours, then every 3 months or 500 hours.
Call NorthStar Product Support 1-800-270-0810
M157304G
HP:______ Volts:______ Amp:______ Ph:_____
RPM:____ PSI:____ GPM:____ Nozzle Size:_____
®
Pump:___________ Hose:______ Lance:_______
Max. Discharge Temperature:_____________
Cleans dirty surfaces with high-pressure water.
ITEM NUMBER: 157304
SERIAL NUMBER:
140°F (60°C)
