Electric Hot Water/Steam Pressure Washer
Instructions for Set-up, Operation, Maintenance & Storage
This pressure washer produces cold or hot water high-pressure spray as well as steam spray. Cleaning chemicals
may be incorporated into the spray if desired. The pressure pump is powered by an electric motor and water is
heated by an open flame burner fueled by diesel/kerosene or fuel-oil. Read and understand this Owner's Manual
completely before using and keep this manual for review. Failure to properly set up, operate, and maintain could
result in serious injury or death to operator or bystanders.
WARNING: SPECIAL HAZARDS
• Skin/Eye Injury: High-pressure spray can cause serious skin or eye injury, including injection injury if fluid pierces the skin.
Injection injury can result in blood poisoning and/or severe tissue damage.
• Burns: Hot spray can scald and burn skin. Hot surfaces of wand and burner, as well as hot exhaust from the burner can
cause burns.
• Slips/Falls: Spray discharge can cause puddles and slippery surfaces. Spray-gun kickback can cause operator loss of
balance and falls.
• Flying Debris: High-pressure spray can cause surface damage and flying debris.
• Fire/Explosion: Burner sparking can ignite fuel or other flammable liquids or vapors in the vicinity. Hot exhaust from burner
can ignite combustible materials.
• Chemical Exposure: Cleaning chemical vapors or contact with skin may be hazardous.
• Electric shock: Spray contact with electrical sources can cause electric shock.
• Electrocution: Improper connection of the equipment or grounding conductor can result in a risk of electrocution.
• CO Poisoning: Exhaust from burner contains carbon monoxide, a poisonous gas that can cause carbon monoxide poisoning
and possible death if inhaled.
Inspect Upon Delivery: STOP! Closely inspect to make sure no components are missing or damaged. See the
"Assembly and Initial Set-Up" section for instructions on whom to contact to report missing or damaged parts.
Check Pump Oil: Pump is shipped with oil. Check pump oil level before starting.
Water Flow Requirements: Make sure your supply water flow rate is 20% higher than the pressure washer's flow
rate (3 gal/min preferred), and that your water is clean and particle free.
Chemical Spraying: Use only NorthStar brand or equivalent washer chemicals designed for pressure washer use.
Maintenance Schedule: Pump, burner fuel filter, burner coil and electrodes require periodic checking and servicing
to keep pressure washer functioning efficiently. See "Maintenance Schedule Summary" for frequency of servicing.
MEI 10-9-12
®
Owner's Manual
Equipment Protection Quick Facts
1
M157305?
ITEM NUMBER: 157305, 157306,
157307, 157308
SERIAL NUMBER: _____________
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for North Star 157305
Summary of Contents for North Star 157305
-
Page 1: Equipment Protection Quick Facts
M157305? ITEM NUMBER: 157305, 157306, 157307, 157308 ® SERIAL NUMBER: _____________ Owner’s Manual Electric Hot Water/Steam Pressure Washer Instructions for Set-up, Operation, Maintenance & Storage This pressure washer produces cold or hot water high-pressure spray as well as steam spray. Cleaning chemicals may be incorporated into the spray if desired. -
Page 2: Table Of Contents
Table of Contents Equipment Protection Quick Facts ............................1 TABLE OF CONTENTS ..............................2 ABOUT YOUR PRESSURE WASHER .......................... 4 SPECIFICATIONS ................................. 5 COMPONENT IDENTIFICATION ..........................6 SPECIAL EQUIPMENT SAFETY FEATURES ......................7 High Pressure Relief Valve .............................. - Page 3 Step 3. Spraying ..................................16 Starting ....................................16 Spraying Procedure ................................16 Using Chemicals for Cleaning (if desired) ........................... 16 Hot Spray Procedure ................................18 Step 4. Stopping ..................................18 STORAGE ..................................18 ...
-
Page 4: About Your Pressure Washer
About Your Pressure Washer Thank you for purchasing a NorthStar hot water Site Selection. Pressure washers used while the open pressure washer! It is designed for long life, flame burner heats the water are for OUTDOOR USE dependability, and top performance. ONLY unless specific exhausting guidelines are met. -
Page 5: Specifications
Specifications MODEL Model # 157305 157306 157307 157308 FLOW OUTPUT Pressure Rating 1700 psi 2700 psi 2000 psi 2750 psi Flow Rate 1.5 gpm 2.5 gpm 1.5 gpm 2.5 gpm Maximum Temperature 250° F POWER REQUIREMENTS Dedicated NEMA 5-20R 6-30R... -
Page 6: Component Identification
Component Identification Machine Component Identification 157305, 157306, 157307, 157308 Exhaust Vent: Provides an exit for burner exhaust Fuel Tank: The Burner has a 8.25 gal. fuel tank- gases. kerosene, #1 or #2 diesel, or fuel oil may be used. Ref #... -
Page 7: Special Equipment Safety Features
13. Pump: A mechanical device that moves and 19. Fuel Filter/Water Separator: Filter in fuel line that pressurizes fluid. [Pump oil must be changed after removes water and screens out dirt and debris from first 40 hours of use, and then changed every three fuel. -
Page 8: Safety
Safety Hazard Signal Word Definitions This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER (red) indicates a hazardous situation, which if DANGER not avoided, will result in death or serious injury. -
Page 9: Safety Labeling
Safety Labeling WARNING RISK OF ELECTROCUTION 1. Connect only to properly grounded outlet. Do not remove ground pin. 2. Inspect cord before using - Do not use if cord is damaged. 3. Keep all connections dry and off the ground. 4. -
Page 10: Assembly And Initial Set-Up
Assembly and Initial Set-Up Step 1. Inspect & Unpack Step 2. Assembly Inspect pressure washer immediately after delivery for Insert nozzles in spaces provided on the control panel. missing parts or damage. Find and separate To install wheels, refer to Figure 6: components identified in Figure 4 and Figure 5. -
Page 11: Extension Cord And Usage
Have an electrical amperage rating not less than • DANGER: Electrocution hazard the rating of the product. Improper connection of the equipment or grounding conductor can result in a risk of electrocution. Check Usage Precautions: with a qualified electrician or service personnel if you Do not yank on any cord to disconnect. -
Page 12: Before Each Use
Before Each Use Follow the steps below prior to each use. Clean garden hose water inlet filter. (See • Maintenance instructions.) Step 1: Inspect Equipment WARNING: High pressure fluid injection Electrical hazard • Inspect cord before using. Do not use if cord is High-pressure fluid discharge from leaks (even pin- damaged. -
Page 13: Step 2. Check And Fill Burner Fuel Tank
Step 2. Check and Fill Burner Fuel Tank Step 3. Select Suitable Worksite Guidelines If you are planning to use heated water, check level of WARNING: Location hazard burner fuel tank. If fuel is needed, use #1 or #2 diesel, You must choose a suitable site for operating your B5 or lower biodiesel, kerosene or fuel oil. -
Page 14: For Indoor Hot Water/Burner Use
For Indoor Hot Water/Burner Use For more details, refer to NFPA 31: Standard for • Exhaust: the Installation of Oil-Burning Equipment. Hot fumes from burner must be exhausted Chapter 5 provides guidelines on how to ensure • through a hood or piped to the outside. adequate air is provided for safe combustion. -
Page 15: Selecting And Connecting Spray Nozzle
Turn pressure washer off and depressurize line before Coupler connecting a new nozzle. Engage safety latch on spray gun. Connect appropriate nozzle according to “Quick Connect Procedure.” Step 2. Pre-Spraying Procedure Water outlet or Collar nozzle-type Safety Rules connection Prevent slips/loss of balance. High-pressure spray Figure 9a could cause you to lose balance from kickback forces, and wet surfaces can be slippery. -
Page 16: Personal Protective Gear
Personal Protective Gear • Nozzle should be 12” to 24” from the work, closer for tough areas. WARNING: High pressure spray hazard • Disengage safety latch and start spraying at the top High-pressure spray can injure eyes/skin. Hot water can using long, even, side-to-side, overlapping passes. - Page 17 Warm or cold water can be used. If warm water CAUTION: Chemical mixture • is specified on chemical label, start burner The special NorthStar braided chemical hose when placed within a liquid and attached at the pump’s according to the instructions in the following chemical injection port will inject 1 part chemical to 15 section, “Hot Spray Procedure.”...
-
Page 18: Hot Spray Procedure
Hot Spray Procedure DANGER: Carbon monoxide poisoning hazard CAUTION: Metal burn hazard Exhaust fumes from the burner contain carbon Use of burner will make spray gun hot. Avoid touching monoxide (CO), a poisonous gas you cannot see, wand. Serious burns from hot metal could occur if smell, or taste. -
Page 19: Winter Storage Preparation
c. Run engine for at least 5 to 10 minutes 2. Using a wrench, disconnect the plumbing that after adding stabilizer to allow it to enter connects to the pump outlet. the fuel system. 3. Obtain the materials you will need: d. -
Page 20: Maintenance & Repair
Maintenance & Repair WARNING: Maintenance hazards ALWAYS shut off water supply, bleed water pressure, turn off motor and unplug electrical cord before cleaning, adjusting, or servicing the pressure washer. After servicing, make sure all guards and cover shields are replaced before using. Follow all safety rules and recommended maintenance instructions. -
Page 21: Clean Inlet Filter For Garden Hose
a. For Comet pumps: Use Universal Tractor Transmission Oil or Mobil 1 Synthetic 15W-50 oil. b. For Cat pumps: Use SAE30 non-detergent oil or Cat Pump Oil Item #22158. Good Replace oil fill cap. • Drain Burner’s Fuel Filter/Water Separator Drain water from burner’s filter bowl as needed. -
Page 22: Inspect And Clean Flow Switch
Swivel fitting Removable outlet fitting Brass body Figure 18 – Flow Switch Remove shuttle. • Clean inside of brass flow switch body and shuttle • Figure 17 with water and a soft brush. Attach high-pressure hose(s) to machine’s high- Insert shuttle into brass flow switch in orientation •... -
Page 23: Inspect Heating Coil And Desoot As Needed
Inspect Heating Coil and Desoot as Needed Inspect and desoot coil annually. Although most coils never require desooting, poor grades of fuel oil or inadequate combustion air will cause heavy soot build- up on the outside surface of the heating coil tubing. These deposits will insulate the coil, which then restricts airflow through the heat exchanger and further aggravates the soot build-up. -
Page 24: Perform Engine Maintenance
Perform Engine Maintenance See engine owner’s manual for instructions on how to Electrodes properly maintain the engine. NOTE TO COMMERCIAL USERS: All mechanical equipment, no matter how well designed, will need maintenance and repairs. NorthStar Product Support will assist in these repairs as needed, but if an inoperable pressure washer creates a major expense to your business, then we strongly recommend the following:... -
Page 25: Oil Burner Adjustment (Only Needed If White Exhaust Smoke Appears)
Oil Burner Adjustment (only needed if white exhaust smoke appears) The oil burner is preset and performance tested at 5. Loosen locking screw and rotate air band closed factory elevation of 1100 feet. Different altitudes may until black smoke appears from burner exhaust require a one-time initial burner adjustment. -
Page 26: Troubleshooting
Troubleshooting Pressure Washer Will Not Run – No Power Causes Solutions Machine not plugged in Plug machine in GFCI tripped Make sure machine is dry Press RESET on the GFCI Machine turned OFF Turn pump switch ON Line circuit breaker tripped Check for tripped circuit breaker in building Circuit Breaker Trips During Operation Causes... -
Page 27: Parts Explosion - Rev New
Parts Explosion – Rev New MEI 10-9-12... - Page 28 Motor Power Cord 14/3 157305 778195 3000PSI RXS Hose, 3/8” 18” 157306 157306, 307, 778193 3000PSI RXS Hose, 3/8” 26” 157305, 307, 308 778191 Motor Power Cord 12/3 777347 Tee, 6MP-6FP-6FP 778141 GFCI Cord, 120V/20A, 36” 157305, 157307 784621 157306, 307, 308 778142 GFCI Cord, 240V/30A, 36”...
-
Page 29: Pump Explosions
Pump Explosions Item Part # Description Model 786056 Comet BXD 1617 157305 779403 Comet BXD 2527G-E 157306 778154 Cat 2DX 157307 38518 Cat 3DX 157308 35918 Thermal Protector, 1/4” 157307, 157308 777340 1/4” MPT x 1/4” Hose Barb 157308 778236... - Page 30 Comet BXD 1617 MEI 10-9-12...
- Page 31 MEI 10-9-12...
- Page 32 MEI 10-9-12...
- Page 33 Cat 2DX MEI 10-9-12...
-
Page 34: Wiring Diagrams
Wiring Diagrams MEI 10-9-12... - Page 35 MEI 10-9-12...
- Page 36 MEI 10-9-12...
-
Page 37: Limited Warranty
Limited Warranty Dear Valued Customer: The NorthStar Product you just purchased is built with the finest material and craftsmanship. Use this product properly and enjoy the benefits from its high performance. By purchasing a NorthStar product, you show a desire for quality and durability. - Page 38 ® Manufactured by Northern Tool + Equipment Co., Ltd Burnsville, MN 55306 NorthernTool.com MEI 10-9-12...
Need help?
Do you have a question about the 157305 and is the answer not in the manual?
Questions and answers
HEATER WILL NOT TURN ON-PULLED OFF FLOW SWITCH-HOW DO YOU REMOVE SHUTTLE
To remove the shuttle on a North Star heater with part number 157305, follow these steps:
1. Disconnect the swivel fitting from the elbow to the inlet of the coil.
2. Remove the “Cap” fitting from the flow switch.
3. Observe the “Shuttle Assembly” and internal body for obstructions, hard water deposits, or other debris.
4. Remove foreign debris using light scraping or compressed air.
5. If additional cleaning is needed, remove the “Body” from the plastic “Enclosure” and soak it in CLR or similar solution to remove buildup.
6. After cleaning, reinsert the “Shuttle Assembly” with the rounded end first into the body, aligning with grooves.
This answer is automatically generated
