- Page 1 SMH3 SMH3 Motorcycle Bluetooth Headset & Intercom SENA www.senabluetooth.com User’s Guide...
- Page 2 Sena™ is a trademark of Sena Technologies, Inc. or its subsidiaries in the USA and other countries. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sena is under...
-
Page 3: Table Of Contents
SMH3 CONTENTS 1. INTRODUCTION 2. PACKAGE CONTENTS 3. INSTALLING THE SMH3 ON YOUR HELMET 4. POWERING ON/OFF AND CHARGING 4.1 Powering On 4.2 Powering Off 4.3 Charging 4.4 Low Battery Warning 5. CHECKING THE BATTERY LEVEL 5.1 LED Indicator 5.2 Voice Prompt Indicator 6. - Page 4 SMH3 10. FIRMWARE UPGRADE...
-
Page 5: Introduction
SMH3 1. INTRODUCTION Thank you for choosing the Sena SMH3, Motorcycle Bluetooth Headset and Intercom. With the SMH3, you can call handsfree on your Bluetooth mobile phone, listen to stereo music or voice instructions of GPS navigation by Bluetooth wirelessly, and have intercom conversations in full duplex with a passenger or other riders. -
Page 6: Package Contents
SMH3 2. PACKAGE CONTENTS SMH3 Headset Unit Microphone Sponges USB Power & Data Cable Velcro Pads for Speakers... -
Page 7: Installing The Smh3 On Your Helmet
SMH3 3. INSTALLING THE SMH3 ON YOUR HELMET 1. [picture 3-1] 2. [picture 3-2] 3. [picture 3-3] Remove the left and right side Place the speaker-microphone unit The boom microphone should be cheekpads from the helmet. along with the velcro pad to the left positioned to face properly towards inside surface of the external shell, your mouth. -
Page 8: Powering On/Off And Charging
4.4 Low Battery Warning When the battery is low, the blinking blue LED in stand-by mode turns to red and you will hear mid-tone triple beeps and a voice prompt saying “Low battery”. -------------------------------- *please contact Sena regarding locally approved agencies Sena accepts. -
Page 9: Checking The Battery Level
SMH3 5. CHECKING THE BATTERY LEVEL You can check the battery level in two different ways when the headset is powering on. 5.1 LED Indicator When the headset is powering on, the red LED flashes rapidly indicating the battery level. 4 flashes = High, 70~100% 3 flashes = Medium, 30~70% 2 flashes = Low, 0~30%... -
Page 10: Pairing The Smh3 With Bluetooth Devices
1. Turn on the SMH3 and press the (+) Button for 5 seconds until the LED flashes red and blue alternately and you hear multiple beeps. You will hear a voice prompt saying “Phone pairing”. 2. Search for Bluetooth devices on your mobile phone. Select the Sena SMH3 in the list of the devices detected on the mobile phone. -
Page 11: Bluetooth Gps Navigation Pairing
2. Within 2 seconds, press the (+) Button for 1 second, then the LED turns to blue flashing and the beeps turn to high tone double beeps. You will hear a voice prompt saying “Multipoint pairing”. 3. Search for Bluetooth devices on the GPS navigation screen. Select the Sena SMH3 in the list of the devices detected on the GPS. - Page 12 SMH3 3. Wait until the LEDs of both headsets turn to blue and intercom connection is automatically established. The two SMH3 headsets A and B are paired with each other for intercom conversation. If the pairing process is not completed within one minute, the SMH3 will return to stand-by mode.
-
Page 13: Smh3 Configuration Setting
SMH3 8. SMH3 CONFIGURATION SETTING You can set the configuration of the SMH3 by the voice menu instruction as below. 1. To enter into voice configuration menu, press and hold the (+) Button for 10 seconds until the LED shows solid blue and you hear high tone double beeps. -
Page 14: Delete All Bluetooth Pairing Information
SMH3 Voice Prompt “Voice prompt” Factory Default Enable Enable / Disable Tap the (-) Button You can disable voice prompts by configuration setting, but the following voice prompts are always on. - Voice prompts for configuration setting menu - Voice prompts for battery level Indicator - Voice prompts for factory reset 8.3 Delete All Bluetooth Pairing Information Voice Prompt... - Page 15 SMH3 Execute Tap the (-) Button To exit voice configuration menu and get back to stand-by mode, tap the (+) Button until you hear a voice prompt, “Exit configuration”. Tap the (-) Button to confirm. Tap (+) Button Tap (-) Button “Vox phone”...
-
Page 16: Using The Smh3
SMH3 9. USING THE SMH3 9.1 Volume Adjustment You can easily adjust the volume by tapping the (+) Button or the (-) Button. You will hear a beep when the volume reaches maximum or minimum level. The volume is set and maintained independently at different levels for each audio source even when you turn off and on the headset. -
Page 17: Intercom And Mobile Phone Call
SMH3 To terminate an intercom conversation, press the (-) Button for 1 second again. [picture 11-2] 9.4 Intercom and Mobile Phone Call 1. When you have an incoming mobile phone call during an intercom conversation, you will hear a ring tone. You can choose whether to 1) answer the mobile phone call and stop the intercom conversation, or 2) reject the phone call and stay on the intercom conversation. -
Page 18: Function Priority
SMH3 the SMH3 to remotely control music playback. So, You not only can adjust the volume but also use the functions such as play, pause, next track and previous track. ● To adjust the volume, tap the (+) Button or the (-) Button.. [picture 11-3] ●... - Page 19 SMH3 10. FIRMWARE UPGRADE The SMH3 supports firmware upgrade function. Please visit Sena Bluetooth web site at www.SenaBluetooth.com check the latest software downloads.
- Page 20 SMH3 SENA www.senabluetooth.com Users Guide for Firmware v1.0...
- Page 21 This product i s CE marke d according to the pr ovisions of the R&T TE Directive (99/5/EC). This device complies with part 15 of the F CC Rules. Operation is subject to the follo wing two Hereby, SENA declares that this product is in compliance with the essential requirements and conditions: other relevant provisions of Directive 1999/5/EC.
