Download  Print this page


Other Information
No Picture, No Video
The TV won't turn on.
The TV turns off automatically.
There is picture/Video.
RF(Cable/Antenna) Connection
The TV is not receiving all channels.
The picture is distorted: macro block error
small block, dots, pixelization
PC Connection
A "Mode Not Supported" message
"PC" is always shown on the source list,
even if a PC is not connected.
The video is OK but there is no audio.
The picture won't display in full screen.
The remote control does not work.
Plasma TV is making humming noise.
Image Retention (Burn In) Issue.
Solutions and Explanations
Make sure the AC power cord is securely plugged in to the wall outlet and the TV.
Make sure the wall outlet is working.
Try pressing the
on, refer to "Remote control does not work" below.
Ensure the Sleep Timer is set to Off in the Setup menu (p. 18).
If your PC is connected to the TV, check your PC power settings.
Make sure the AC power cord is plugged in securely to the wall outlet and the TV.
When watching TV from an antenna or cable connection, the TV will turn off after 10 - 15 minutes if
there is no signal.
Check cable connections (remove and reconnect all cables connected to the of TV and external
Set your external devices' (Cable/Set top Box, DVD, Blu-ray etc) video outputs to match the
connections to the TV input. For example, if an external device's output is HDMI, it should be
connected to an HDMI input on the TV.
Make sure your connected devices are powered on.
Be sure to select the TV's correct source by pressing the SOURCE button on the TV remote.
Make sure the Antenna cable is connected securely.
Please try Plug & Play (Initial setup) to add available channels to the channel list. Go to
Setup - Plug & Play (Initial setup) and wait for all available channels to be stored (p. 7).
Verify the Antenna is positioned correctly.
Compression of video contents may cause picture distortion, especially with fast moving pictures
such as sports and action movies.
A low signal can cause picture distortion. This is not a TV issue.
Set your PC's output resolution and frequency so they match the resolutions supported by the TV (p.
This is normal; "PC" is always shown on the source list, regardless of whether a PC is connected.
If you are using a HDMI connection, check the audio output setting on your PC.
HD channels will have black bars on either side of the screen when displaying upscaled SD (4:3)
Black bars on the top and bottom will appear during movies that have aspect ratios different from
your TV.
Adjust the picture size options on your external device or TV to full screen.
Replace the remote control batteries with the poles (+/–) in the right direction.
Clean the sensor's transmission window on the remote.
Try pointing the remote directly at the TV from 5~6 feet away.
Plasma TVs typically make a soft humming sound. This is normal. It's caused by the electrical charges
that are used to create the images on the screen.
If the humming sound is loud, you may have set the brightness on the TV too high. Try setting the
brightness lower.
You can also have loud humming if the back of your Plasma TV is too close to a wall or other hard
surface. Also try rerouting your connection cables.
Improper installation of wall mount can create excessive noise.
To minimize the possibility of screen burn, this unit is equipped with screen burn reduction technology.
Pixel Shift technology enables you to set picture movement up/ down (Vertical Line) and side to side
(Horizontal Dot).
button on the TV to make sure the problem is not the remote. If the TV turns
