SERVICE MANUAL
General
Operating channel
10 channels
Dial signal
Tone, 10 PPS (pulse) selectable
Supplied accessories
AC power adaptor (AC-T47) (1)
Telephone line cord (1)
Rechargeable battery pack (BP-T16) (1) (SPP-98)
Rechargeable battery pack (BP-T16) (2) (SPP-99)
Wall bracket/stand (1)
Screws (2)
Handset
Power source
Rechargeable battery pack BP-T16
Battery life
Standby : Approx. 8 days
Talk
: Approx. 6 hours
Battery charging time
Approx. 12 hours
Dimensions
Approx. 54 × 195 × 49 mm (w/h/d),
antenna excluded
× 7
× 1
(approx. 2
inches)
1/4
3/4
15/16
Antenna: Approx. 285 mm
(approx. 11
inches)
1/4
Mass
Approx. 240 g (approx. 8 oz), battery
included
MICROFILM
SPP-98/99
Handset
Photo: SPP-98
SPECIFICATIONS
Base unit
Power source
Battery charging time
Dimensions
Mass
Design and specifications are subject to change without
notice.
– 1 –
Singapore Model
Base unit
DC 9V from AC power adaptor
Rechargeable battery pack BP-T16
(SPP-99 only)
Approx. 20 hours (SPP-99 only)
Approx. 120 × 64 × 223 mm (w/h/d),
antenna excluded
× 2
× 8
(approx. 4
inches)
3/4
5/8
7/8
Antenna: Approx. 680 mm
(approx. 26
inches)
7/8
Approx. 350 g (approx. 12 oz), wall
bracket and battery excluded
CORDLESS TELEPHONE
Advertisement
Table of Contents
Related Manuals for Sony SPP-98
Summary of Contents for Sony SPP-98
- Page 1 AC power adaptor (AC-T47) (1) Approx. 20 hours (SPP-99 only) Telephone line cord (1) Dimensions Approx. 120 × 64 × 223 mm (w/h/d), Rechargeable battery pack (BP-T16) (1) (SPP-98) Rechargeable battery pack (BP-T16) (2) (SPP-99) antenna excluded × 2 × 8 Wall bracket/stand (1) (approx.
-
Page 2: Table Of Contents
COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. -
Page 3: General
SECTION 1 GENERAL This section is extracted from instruction manual. – 3 –... - Page 4 – 4 –...
- Page 5 – 5 –...
- Page 6 – 6 –...
- Page 7 – 7 –...
- Page 8 – 8 –...
-
Page 9: Disassembly
SECTION 2 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 2-1. CABINET (LOWER) 1 BTP 3x10 2 BTP 3x10 6 cabinet (lower) – 9 –... -
Page 10: Base Main Board
2-2. BASE MAIN BOARD 2 BTP 2.6x8 1 BTP 2.6x8 3 BASE MAIN board 4 telescopic antenna – 10 –... -
Page 11: Cabinet (Rear)
2-3. CABINET (REAR) 6 cabinet (rear) 1 battery lid 2 BTP 2.6x10 5 claw 4 claws 3 claws 2-4. HAND MAIN BOARD 5 Unsolder. discharge gap (CP101) 3 BTP 2x8 4 Unsolder the 3 wires. 2 BTP 2x8 8 HAND MAIN board 9 BVTP 2x8 !¡... -
Page 12: Test Mode
SECTION 3 TEST MODE MACHINE TEST MODE BASE UNIT SECTION Set the Test Mode: 1. With the TEST I/O (TP808) terminal in “L” (low) input state, MANUAL TEST MODE cause Reset of Power ON. Equipment enters machine test mode. Set the Test Mode: 2. - Page 13 Channel Setting: During startup in machine test mode, make the following channel settings by loading the terminal input data. Pin No. TX frequency RX frequency TEST CLK/ COL4 COL3 COL2 COL1 (MHz) (MHz) Channel POWER LED (TP809) (TP807) (TP806) (TP805) (TP804) 43.720 48.760...
-
Page 14: Handset Section
HANDSET SECTION MACHINE TEST MODE Set the Test Mode: 1. When power on reset is applied while a “L” (low) is input the MANUAL TEST MODE TEST I/O (TP316) terminal (IC401 #§ pin), the RING (Level Set the Test Mode: H, 1 sec) sounds. - Page 15 Key Processing (Setting the Manual Test Mode) : DATA Light MUTE RSSI TEST POINT FUNCTION OUT- LCD HICUT SENS Light INITIAL – NORM TEST MODE TALK TP204 TP209 TX & RX – – – TP201 TP209 TEST MODE OFF – –...
- Page 16 Channel Setting: During startup in machine test mode, make the following channel settings by loading the terminal input data. Pin No. TX frequency RX frequency PC0-I/O PD3-I PD2-I PD1-I PD0-I (MHz) (MHz) Channel (TP205) (TP204) (TP203) (TP202) (TP201) 48.760 43.720 48.840 43.740 48.860...
-
Page 17: Electrical Adjustments
SECTION 4 ELECTRICAL ADJUSTMENTS BASE UNIT SECTION RX SECTION ADJUSTMENT RX DISCRI Adjustment Note: Note: • Apply 9V dc from regurated DC power supply. • Perform the adjustment at T3CH (28CH : 49.910 MHz) as a rule. • Perform the adjustment at T3CH (28CH : 49.910 MHz) as a rule. Setting : •... - Page 18 Adjustment Location : – base main board (component side) – RV501 FL501 L503 L602 RV601 – base main board (conductor side) – TP601 TP506 TP602 TP507 TP603 TP508 TP502 TP503 50 Ω TP505 TP702 TP701 – 18 –...
-
Page 19: Handset Section
HANDSET SECTION RX DISCRI Adjustment Adjustment Location : Note: • Perform the adjustment at T1CH (26CH : 43.780 MHz) as a rule. Note: – hand main board (side A) – Setting : • Apply 3.6 V dc from regurated DC power supply. FM RF •... -
Page 20: Diagrams
SPP-98/99 SECTION 5 DIAGRAMS 5-1. BLOCK DIAGRAM — BASE SECTION — ANT1 TELESCOPIC ANTENNA FL501 RX DISCRI MIX, IF AMP, DET EXPANDER MJ701 IC501 ( 2/3 ) IC501 ( 1/3 ) LINE D704 RECE CF501 T701 SPEECH MIX IN RF AMP 10.68MHz... -
Page 21: Block Diagram -Handset Section
SPP-98/99 5-2. BLOCK DIAGRAM — HANDSET SECTION — ANT2 TELESCOPIC ANTENNA EXPANDER RX DISCRI MIX, IF AMP, DET IC1 ( 2/3 ) IC1 ( 1/3 ) RECE MIX IN 10.7MHz BPF1 EXPANDER 460kHz MUTE SPEAKER D-COMP VOLUME RSSI CONTROL LOCAL... -
Page 22: Printed Wiring Board -Base Section
SPP-98/99 5-3. PRINTED WIRING BOARD — BASE SECTION — • Semiconductor Location Ref. No. Location D501 D502 D601 D701 D702 D703 D704 D706 D801 D802 D804 D805 D806 D807 D808 D810 (D841) (D842) D901 C-10 D902 (D903) (D904) (D908) D909... -
Page 23: Schematic Diagram -Base Section
SPP-98/99 5-4. SCHEMATIC DIAGRAM — BASE SECTION — • Refer to page 37 for IC Block Diagrams. Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. -
Page 24: Printed Wiring Board -Hand Main Section
SPP-98/99 5-5. PRINTED WIRING BOARD — HAND MAIN SECTION — • Semiconductor Location Ref. No. Location D101 (Page 34) Q101 Q102 Q103 (Page 34) Note: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. -
Page 25: Schematic Diagram -Hand Main Section
SPP-98/99 5-6. SCHEMATIC DIAGRAM — HAND MAIN SECTION — • Refer to page 37 for IC Block Diagrams. (Page 36) Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. -
Page 26: Printed Wiring Board -Hand Key Section
SPP-98/99 5-7. PRINTED WIRING BOARD — HAND KEY SECTION — (Page 30) (Page 30) • Semiconductor Location Ref. No. Location D201 D202 (D301) (D302) (D303) (D304) <D305> <D306> <D307> <D308> D401 D402 D403 D404 D405 D406 IC201 IC202 IC301 IC401... -
Page 27: Schematic Diagram -Hand Key Section
SPP-98/99 5-8. SCHEMATIC DIAGRAM — HAND KEY SECTION — • Refer to page 37 for IC Block Diagrams. (Page 32) Note: • All capacitors are in µF unless otherwise noted. pF: µµF • Voltage is dc with respect to ground under no-signal 50 WV or less are not indicated except for electrolytics condition. -
Page 28: Ic Pin Descriptions
• IC Block Diagrams 5-9. IC PIN DESCRIPTIONS • IC801 LC6621108A (SYSTEM CONTROL) (BASE UNIT) Pin No. Pin Name Pin Description IC501 TB31224F (BASE MAIN BOARD) RSSI CTRL RSSI sens select output (L: Low sens) IC1 TB31224F (HAND MAIN BOARD) EEPROM DATA EEPROM data input/output (Not used in this set.) EEROM CLK... - Page 29 • IC401 LC662716A (SYSTEM CONTROL) (HANDSET) Pin No. Pin Name Pin Description BEEP ATT Beep volume High/Low control output (L: High) TX-DATA RF transmission data output BEEP Beep output — Ground OSC1 — Crystal oscillation input (4.048MHz) OSC2 — Crystal oscillation output (4.048MHz) —...
-
Page 30: Exploded Views
3-007-173-01 LABEL (TERMINAL CAUTION) (/S) 3-025-403-01 TERMINAL (BASE), CHARGE 7-685-134-19 SCREW +BTP 2.6X8 TYPE2 N-S A-3672-591-A BASE MAIN BOARD, COMPLETE (SPP-99) 7-685-547-14 SCREW +BTP 3X10 TYPE2 N-S A-3672-600-A BASE MAIN BOARD, COMPLETE (SPP-98) ANT1 1-501-982-11 ANTENNA, TELESCOPIC (BASE UNIT) 3-025-392-01 CABINET (LOWER) (SPP-99) D706... -
Page 31: Handset Section
1-790-013-11 WIRE (FLAT TYPE) (15 CORE) 3-027-147-01 SHEET (RECEIVER), ADHESIVE * 58 A-3622-243-A HAND KEY BOARD, COMPLETE (SPP-99) 3-027-565-01 SHEET (LCD), ELECTROSTATIC * 58 A-3622-249-A HAND KEY BOARD, COMPLETE (SPP-98) 3-031-843-01 SPONGE (MICROPHONE) 3-030-405-01 SPACER (MICROPHONE) ANT2 1-754-006-11 ANTENNA, TELESCOPIC (HANDSET) 3-025-402-01 HOLDER (LCD) -
Page 32: Electrical Parts List
Description Remark Ref. No. Part No. Description Remark A-3672-591-A BASE MAIN BOARD, COMPLETE (SPP-99) C538 1-163-021-11 CERAMIC CHIP 0.01uF A-3672-600-A BASE MAIN BOARD, COMPLETE (SPP-98) C539 1-126-964-11 ELECT 10uF C540 1-163-021-11 CERAMIC CHIP 0.01uF ************************** C541 1-163-809-11 CERAMIC CHIP 0.047uF... - Page 33 BASE MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C907 1-163-009-11 CERAMIC CHIP 0.001uF < IC > (SPP-99) C908 1-126-935-11 ELECT 470uF 6.3V IC501 8-759-462-29 IC TB31224F (SPP-99) IC801 8-759-565-54 IC LC6621108A-4K71 C909 1-126-935-11 ELECT 470uF 6.3V IC901...
- Page 34 BASE MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark Q703 8-729-032-66 TRANSISTOR 2SC5069-TD R613 1-216-057-00 METAL CHIP 2.2K 1/10W Q801 8-729-027-60 TRANSISTOR DTC144TKA-T146 (SPP-99) R614 1-216-081-00 METAL CHIP 1/10W Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (SPP-99) R701 1-215-861-00 METAL OXIDE Q803 8-729-901-06 TRANSISTOR DTA144EK (SPP-99)
- Page 35 D307 8-719-059-94 LED SML-010MT-T86 (SPP-99) D308 8-719-059-94 LED SML-010MT-T86 (SPP-99) ************************************************************* A-3622-243-A HAND KEY BOARD, COMPLETE (SPP-99) D401 8-719-914-43 DIODE DAN202K A-3622-249-A HAND KEY BOARD, COMPLETE (SPP-98) D402 8-719-058-24 DIODE RB501V-40TE-17 D403 8-719-914-43 DIODE DAN202K ************************* D404 8-719-938-75 DIODE SB05-05CP...
- Page 36 HAND KEY Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < LIQUID CRYSTAL DISPLAY > R314 1-216-073-00 METAL CHIP 1/10W R315 1-216-037-00 METAL CHIP 1/10W LCD1 1-803-146-11 DISPLAY PANEL, LIQUID CRYSTAL R316 1-216-033-00 METAL CHIP 1/10W R317 1-216-033-00 METAL CHIP 1/10W...
- Page 37 HAND MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-3672-595-A HAND MAIN BOARD, COMPLETE C112 1-163-239-11 CERAMIC CHIP 33PF C113 1-163-243-11 CERAMIC CHIP 47PF *************************** C114 1-162-587-11 CERAMIC CHIP 0.039uF < BAND PASS FILTER > C115 1-107-725-11 CERAMIC CHIP 0.1uF...
- Page 38 1/10W 1-216-077-00 METAL CHIP 1/10W 1-771-405-11 SWITCH, RUBBER KEY (SPP-99) 1-216-070-00 METAL CHIP 7.5K 1/10W 1-771-405-31 SWITCH, RUBBER KEY (SPP-98) 1-216-037-00 METAL CHIP 1/10W 1-790-013-11 WIRE (FLAT TYPE) (15 CORE) 1-216-073-00 METAL CHIP 1/10W ANT1 1-501-982-11 ANTENNA, TELESCOPIC (BASE UNIT)
