QUICK SET UP GUIDE

Follow these instructions to get up and running in very little time.
1. Install 2 AA batteries
diagrams on the equipment to ensure batteries are positioned correctly.
a.) Handheld transmitter: Unscrew bottom portion of the transmitter to expose
battery holder. Push the fi rst battery up through the housing with negative side
up. Place the second battery below the fi rst with negative side up. The batteries are
spring loaded and will settle into place. Screw the cover back into place.
b.) Bodypack transmitter: With bodypack face down, push the spring release to
the right to open. Place left battery negative side up, and the right battery negative
side down. Snap the battery cover to close.
2. Attach antennas
screwing it into the connector (2a). After attached, bend antennas into position (2b).
6
1a
in the handheld transmitter and bodypack. Refer to the
2a
to the back of the receiver. Keep each antenna straight while
1b
2b
