H60 TRANSMITTER - BATTERY COMPARTMENT
2
1
Houses AA batteries (see Quick Set Up
Guide for installation instructions, pg 6).
H60 TRANSMITTER - TOP
1
Dip switch with choice of 3 output gain
Dip switch with choice of 3 output gain
settings for capsule (0 dB, -6 dB, -12 dB).
14
1
2
Dip switch to choose between
30 Milliwatt (HI) and 10 Milliwatt (LO)
power RF power output.
1
