Specifications - E705
Product Specifications
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI
DVI-D 24pin
DisplayPort DisplayPort Connector Digital RGB
VGA*
15pin Mini D-sub
2
HDMI/
HDMI Connector
HDMI2
Y/Pb/Pr*
15pin Mini D-sub
2
AUDIO
AUDIO
STEREO Mini Jack
Input
HDMI Connector
DisplayPort Connector Digital Audio
AUDIO
STEREO Mini Jack
Output
Speaker Output
Control
Service port
Power Supply
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible mounting interface
Power Management
Plug & Play
Power supply for Slot 2 type OPTION
Accessories
NOTE: Technical specifications are subject to change without notice.
70"/1765.6 mm diagonal
Resolution:
1920 x 1080
Color:
Over 16 million colors (depending on video card used)
Horizontal:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
Vertical:
50.0 - 85.0 Hz
25.2 MHz - 162.0 MHz
1538.9 x 865.6 mm
Digital RGB
DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
DisplayPort Complies with Standard V1.1a, applicable to HDCP V1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync
Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV
HDMI
Digital RGB
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Component
Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Analog Audio
Stereo L/R 0.5 Vrms
Digital Audio
PCM 32, 44.1, 48 KHz (16/20/24bit)
PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio
Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10 W + 10 W (Stereo)
RS-232C In:
9 Pin D-sub
LAN:
RJ-45 10/100 BASE-T
USB service port for maintenance
3.6 - 1.6 A @ 100-240V AC, 50/60Hz
Temperature*
:
0 - 40°C / 32 - 104°F
3
Humidity:
20 - 80% (without condensation)
Altitude:
0 - 3000 m (Brightness may decrease with altitude)
Temperature:
-20 - 60°C / -4 - 140°F
Humidity:
10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
1587.0 (W) x 919.6 (H) x 86.9 (D) mm / 62.5 (W) x 36.2 (H) x 3.4 (D) inches
46.7 kg (103.0 lbs)
400 mm x 400 mm (M8, 4 Holes)
VESA DPM
VESA DDC2B, DDC/CI, DisplayPort
16V/3.6 A
Setup manual, Power Cord, Video Signal cable, Remote Control, AAA Battery x 2, Clamp x 1,
Screw x 1, CD-ROM
*3: When you use option board accessories, please contact your supplier for detailed information.
English-45
, 1920X1080 (60Hz), 1080p, 1080i
1
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1
, WUXGA60*
1
, 1920X1080 (60Hz)
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
*1: Compressed image.
*2: Common terminal.
