OPERATOR'S MANUAL
OPERATOR'S MANUAL
A Division of Snow Joe
A Division of Snow Joe
, LLC
, LLC
®
®
THANKS
OF A REMANUFACTURED PRODUCT.
To make sure you get the most out of
your product, be sure to register online at
to enjoy full product support.
ELECTRIC CHAIN SAW
R
R
14-INCH | 9-AMP
Model SWJ699E-RM
FOR
snowjoe.com
PASTE UPC LABEL HERE
YOUR
Form No. SJ-SWJ699E-RM-880E-V1
PURCHASE
Advertisement
Table of Contents
Related Manuals for sunjoe SWJ699E-RM
Summary of Contents for sunjoe SWJ699E-RM
- Page 1 A Division of Snow Joe A Division of Snow Joe , LLC , LLC ® ® Form No. SJ-SWJ699E-RM-880E-V1 THANKS YOUR PURCHASE OF A REMANUFACTURED PRODUCT. To make sure you get the most out of your product, be sure to register online at snowjoe.com...
-
Page 2: Electric Chain Saw
A Division of Snow Joe A Division of Snow Joe , LLC , LLC ® ® Form No. SJ-SWJ699E-RM-880E-V1 IMPORTANT! General Safety Safety Instructions WARNING! When using electric yard tools, basic safety precautions should always be followed to reduce the risk of... - Page 3 Chain Saw Use + Care 15. Disconnect tool – Disconnect the chain saw from the power supply when not in use, before servicing, when transporting, or when changing the chain or other Save all warnings and instructions for future reference. The accessories.
-
Page 4: Electrical Safety
Electrical Safety The appliance plug will fit into a polarized extension cord only one way. If the appliance plug does not fit fully into the extension cord, reverse the plug. If the plug 1. Ground fault circuit interrupter (GFCI) protection should still does not fit, obtain a correct polarized extension be provided on the circuit(s) or outlet(s) to be used for cord. -
Page 5: Chain Saw Safety Warnings
This electric chain saw is double-insulated, eliminating the • Keep handles dry, clean and free from oil and grease. Greasy, oily handles are slippery and can cause loss of need for a separate grounding system. Use only identical control. replacement parts. Read the instructions before servicing double-insulated appliances. - Page 6 • Ensure safe carrying of the chain saw. Whenever the machine is to be handled or transported, you must: – switch off the motor and wait for the chain to come to a complete stop; – mount the guide bar cover; –...
-
Page 7: Safety Symbols
Safety Symbols The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions READ THE OPERATOR'S MANUAL(S) – Read, understand Keep bystanders and children a safe and follow all instructions in the distance away. -
Page 8: Know Your Electric Chain Saw
Know Your Electric Chain Saw Read the owner’s manual and safety rules carefully before operating your electric chain saw. Compare the illustration below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. -
Page 9: Carton Contents
Unpacking Installing the Guide Bar + Chain Tools and supplies required: Carton Contents • Dual-tipped hex key wrench/blade screwdriver (supplied) • Electric chain saw • Heavy-duty work gloves • 14 in. (35.6 cm) Oregon chain (pre-mounted on bar) NOTE: When replacing the guide bar and chain, use only identical replacement parts. - Page 10 3. Starting at the tip, mount the chain drive links into the bar groove, leaving a loop at the back of the bar. The chain will Fig. 5 loosely fit until it is placed on the sprocket (Fig. 3). NOTE: Make certain of the direction of the chain. If Chain tensioner the chain is mounted backwards, the saw will vibrate screw...
-
Page 11: Preparing To Work
7. Remove all slack from the chain by turning the chain 3. Remove the cutting bar and chain from the mounting tensioner screw clockwise until the chain seats snugly surface (Fig. 8). against the bar with the drive links flush inside the bar groove (Fig. -
Page 12: Operation
Adjusting the Chain Tension Chain Lubricant WARNING! CAUTION! Before performing any checks, Failure to lubricate the chain will cause damage to the chain and bar. Use a good quality bar and chain adjustments, repairs, or maintenance on the machine, make oil designed specifically for use with chain saws. -
Page 13: Operating Tips
2. Make a loop in the power cord and push it up through the 2. Keep in mind that the operator or user is responsible for hole in the handle and around the cord restraint hook accidents or hazards occurring to other people or their (Fig. - Page 14 Proper Cutting Stance WARNING! Prolonged exposure to vibrations can cause injuries and neurovascular disorders (also called “Raynaud's 1. Weight should be balanced with both feet on solid syndrome” or “white hand”), especially to people suffering ground. from circulation disorders. The symptoms can effect the 2.
-
Page 15: Cutting Techniques
7. Let the chain do the work; exert only light downward IV) Before starting to fell, consider the natural lean of the tree, pressure. If you force the cut, damage to the bar, chain, or the location of larger branches, and the wind direction to unit can result. - Page 16 • Limbing a tree II) When the log is supported on one end (Fig. 19B), cut 1/3 the diameter from the underside (underbuck). Then make Limbing is the process in which branches are removed from a the finishing cut by overbucking to meet the first cut. fallen tree.
-
Page 17: Finishing Work
IV) It is easier to saw a log using the spiked bumper • If there is excessive dirt or resin build-up, disassemble the (Fig. 19D). chain and place it in a container with a suitable cleanser. Then rinse it with clean water and treat it with a suitable –... -
Page 18: Chain Tension
Chain Tension An authorized service center will sharpen the chain using the right tools to ensure minimum removal of material and even Check the chain tension before using the saw when the chain sharpness on all the cutting edges. is cold. The correct tension of a cold chain is when there is no If you sharpen the chain yourself, use special round-section slack on the underside of the guide bar;... -
Page 19: Guide Bar Maintenance
Model #: S W J 9 9 E You can purchase replacement parts for your Sun Joe ® Serial #: SWJ699E-RM electric chain saw online at snowjoe.com or, to order by phone, contact Snow Joe + Sun Joe customer ® ®... -
Page 20: Troubleshooting
Troubleshooting Fault Possible Cause Remedy • Cord not connected to • Make sure that the cord is connected to a the power source power source • Trigger switch not • Check safety lock button is fully depressed prior operational to engaging the trigger switch The motor does not start •... -
Page 21: Optional Accessories
Optional Accessories WARNING! ALWAYS use only authorized Snow Joe + Sun Joe replacement parts and accessories. NEVER use ® ® replacement parts or accessories that are not intended for use with this saw. Contact Snow Joe + Sun Joe if you are unsure ®... - Page 22 NOTES...
- Page 23 SNOW JOE + SUN JOE REFURBISHED GOODS WARRANTY ® ® GENERAL CONDITIONS: Snow Joe + Sun Joe may from time to time change the design ® ® of its products. Nothing contained in this warranty shall be Snow Joe + Sun Joe operating under Snow Joe , LLC warrants ®...
- Page 24 snowjoe.com...
