Summary of Contents for Frico PL3200C
- Page 1 PL3200C Recommended installation height 3,2 m...
- Page 2 PL3200C DN20 (3/4") outside thread 1046 / 1556 / 2046 1046 / 1556 / 2046 1046 / 1556 / 2046 min 500 min 500 min 500 DN20 (3/4") min 500 min 500 DN20 (3/4") DN20 (3/4") L = 2 m...
- Page 3 PL3200C Gland Gland ø17,5 ø17,5 Knock-out ø32,5 Knock-out ø25,5 Gland ø20,5 Knock-out ø17,5 Fig. 2 Fig. 3: Open the unit.
- Page 4 PL3200C Minimum distance Fig. 4 30 mm 60 mm Fig. 5...
- Page 5 PL3200C Mounting with wall brackets Ø8 (3x) Ø7 Ø16 PL3210C 2 pcs PL3215C 2 pcs 3 pcs PL3220C Fig. 6: Mounting with wall brackets...
- Page 6 PL3210C, PL3215C, 1 m PA34TR15 PA34TR20 PL3220C, 1 m PA2P15 PL3210C, PL3215C, 1 m PA2P20 PL3220C, 1 m PA3PF15 PL3210C, PL3215C PA3PF20 PL3220C PAMLK PL3200C PL3200C W FHDN20 PA34TR PA2P PA3PF PAMLK FHDN20 PL2DR PL2DR VOT15 DN15 VLSP VOT20 DN20...
- Page 7 PL3200C PL3210CA / PL3215CA / PL3220CA 0 -10V N H1H2 N F1 F2 F3 Black Blue Black Brown Blue Black Blue Black Brown Blue...
- Page 8 PL3200C PL3210CE8 / PL3215CE12 / PL3220CE16 0 -10V N H1H2 N F1 F2 F3 Yellow White Orange Black Blue Black Brown Blue Yellow White Orange Black Blue Black Brown Blue...
- Page 9 PL3200C PL3210CW / PL3215CW / PL3220CW 0 -10V N H1H2 N F1 F2 F3 Black Blue Black Brown Blue Black Blue Black Brown Blue...
- Page 10 PL3200C PAMLK 0 -10V N H1H2 N F1 F2 F3 N F1 F2 F3 Black Brown Blue Black Brown Blue...
- Page 11 PL3200C Ambient, no heat - PL3200C A Type Output Airflow* Sound Voltage Amperage Length Weight level* motor motor [kW] [dB(A)] [mm] [kg] 1100/1750 46/57 230V~ 1046 PL3210CA PL3215CA 1700/2750 46/59 230V~ 1556 PL3220CA 2300/3500 50/60 230V~ 2046 Electrical heat - PL3200C E ∆t...
- Page 12 PL3200C Output charts water PL3200C Supply water temperature:80 °C Water temperature: 80/60 °C Room temperature: +18 °C Room temperature: +18 °C Outlet air temperature: +35 °C* Type Airflow Output Return Water Pressure Output * Outlet Water Pressure position water temp.
-
Page 13: Operation
Mounting with wall brackets (fig. 6) Application 1. Mount the brackets on the wall, see fig.6A PL3200C is a compact air curtain with a and dimension drawing fig.1. If the wall is recommended installation height of 3,2 uneven the brackets must be compensated metres. - Page 14 Note that the unit shall be preceded by a the distribution board it is to be indicated regulating valve, see Frico valve kit. that ”the air curtains can be supplied from The water coil is connected on top of the unit more than one connection”.
-
Page 15: Maintenance
PL3200C Service, repairs and maintenance Overheating For all service, repair and maintenance first The air curtain unit with electric heater is carry out the following: equipped with an overheat protector. If it is deployed due to overheating, reset as follows: 1. - Page 16 PL3200C Replacing the water coil (W) Residual current circuit breaker (E) 1. Shut off the water supply to the unit. When the installation is protected by means of a residual current circuit breaker, which 2. Disconnect the connections to the water trips when the appliance is connected, coil.
- Page 17 PL3200C Controls The air curtain has an integrated control system and can be remotely controlled. 230V~ Actuator SD230 Black (remove the quick Brown connector) Blue PL2DR (accessory) External on/off Eg time switch. External potential free closure = off Factory setting dip-switches - Unit with water...
-
Page 18: Functional Test
PL3200C Fan step 1/2/3 ~20 °C Heat step Electric: Half/full power Water: On/off (1 LED) On/off Control panel - Unit with electrical heating or water heating Fan step 1/2/3 On/off Control panel - Unit without heating Remote control - on/off, fan steps and heating steps... - Page 19 Technical Support - tel. +46 313368600 Art.no.117959, 2013-10-24 CH/HH...
