Summary of Contents for Contec CONPROSYS Series
Page 1
This product is an option product of the following. - Supported Product (Selling separately) CONPROSYS Series : CPS-MCS341 series Package Contents The product you have purchased consists of the following items. Be sure that you have them all. If you find any item either missing or damaged, please contact the sales representative you purchased the product from.
Page 2
CPS-PWD-30AW24-01 Specifications Requirement Description Power supply space Rated input voltage 100 to 240VAC, 50 to 60Hz Permissible input voltage * 85 to 264VAC, 50 to 60Hz Input current 0.55A typ (115VAC), 0.35A typ (230VAC) Rated output voltage 24VDC Rated output current 1.3A (Max.) Input-Output 3000VAC 1minute 50MΩ...
Page 3
CPS-PWD-30AW24-01 Interface Model CPS-PWD-30AW24-01 Pin No. Signal 100- +24VDC name 240VAC Connector Model MC 1,5/3-ST-3,5(PHOENIX CONTACT) Pin No. Signal +24V name Mounting Figure Green Black Terminal tightening torque : 10KgF cm Disposal When disposing of the product, follow the disposal procedures stipulated under the relevant laws and municipal ordinances.
Page 4
CONTEC sales representative or sales office. - Use the product with the specified models by the CONTEC. Not doing so may cause malfunction. - Use the product in the specified operating condition (temperature and humidity) - This product is a device embedded products, it is not a final product.
