- Page 1 F&eIT Series RS-232C-Ethernet Media Converter RP-COM(FIT)H RS-232C-Ethernet Media Converter PoE Conform RP-COM(FIT)H-AF User’s Manual CONTEC CO.,LTD.
- Page 2 Check Your Package Thank you for purchasing the CONTEC product. The product consists of the items listed below. Check, with the following list, that your package is complete. If you discover damaged or missing items, contact your retailer. Product Configuration List - Module [RP-COM(FIT)H or RP-COM(FIT)H-AF] ...1...
-
Page 3: Copyright
No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document. The information in this document is subject to change without notice. -
Page 4: Table Of Contents
Nomenclature of Module Components ....................9 LED indicator ............................9 MODE Switch ............................10 ID Switch............................... 11 Input-Output Interface........................... 12 Explanation in Mode of Operation Virtual COM Mode ..........................13 Through Mode ............................14 Modem Mode ............................16 RP-COM(FIT)H, RP-COM(FIT)H-AF... - Page 5 Control Using SNMPc...........................32 Building-in to SNMPc ...........................33 MIB Database Updates..........................33 Troubleshooting When Communication Fails......................35 When SNMP Connections Fail ......................35 When the RP-COM(FIT)H, RP-COM(FIT)H-AF Will Not Start ..........35 Appendix System Reference ..........................37 Product Specifications........................37 External Dimensions ........................39 Memory register.............................40 Differences between the RP-COM(FIT)GY, RP-COM(FIT)H and RP-COM(FIT)H-AF ....43...
-
Page 6: Before Using The Product
Up to 7 channels available for RS-232C (when three COM-2(FIT)GY’s are added) Add-on device modules [COM-2(FIT)GY] (for RS-232C 2ch) and [COM-1PD(FIT)GY] *2 (for RS-422A/RS-485 1ch) can be freely combined to allow up to three units to be added for extension RP-COM(FIT)H, RP-COM(FIT)H-AF... -
Page 7: Support Software
Help section on the attached CD-ROM. Setup utility : Automatically detects RP-COM(FIT)H and RP-COM(FIT)H-AF on the network upon startup. Can set the device for the operating mode (Virtual COM Mode, Penetration Mode, Modem Mode), Device ID, IP address, subnet mask, etc. -
Page 8: Cable/Connector (Option)
RS-232C 2ch Communication Module COM-2(FIT)GY Isolated RS-422A/485 1ch Communication Module COM-1PD(FIT)GY < Accessory for the RP-COM(FIT)H > AC adapter (input : 90 - 264VAC, output : 12V 1A) POA201-10-2 < Accessory for the RP-COM(FIT)H-AF > AC adapter (input : 90 - 264VAC, output : 5VDC 2.0A) POA200-20-2 AC-DC Power Supply Unit (input : 85 - 132VAC, output : 5VDC 3.0A) :... -
Page 9: Customer Support
You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited Three-Years Warranty CONTEC products are warranted by CONTEC CO., LTD. -
Page 10: Safety Precautions
Handling Precautions CAUTION Do not modify the module. CONTEC will bear no responsibility for any problems, etc., resulting from modifying this module. Do not use or store the equipment in a hot or cold place, or in a place that is subject to severe temperature changes.(Operating temperature range: 0 - 50°C) -
Page 11: Caution On Maintenance
Even when using the product continuously, be sure to read the manual and understand the contents. Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting from modifying this product. Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein. -
Page 12: Environment
(3) Store the package at room temperature at a place free from direct sunlight, moisture, shock, vibration, magnetism, and static electricity. Disposal When disposing of the product, follow the disposal procedures stipulated under the relevant laws and municipal ordinances. RP-COM(FIT)H, RP-COM(FIT)H-AF... - Page 13 1. Before Using the Product RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 14: Module Nomenclature And Settings
Startup, or startup error POWER Operating Flashing Sending or receiving COM data - Others Name State Indicator Flashing 2 times Initialization error POWER Flashing 3 times Firmware writing error POWER All flashing at Firmware writing in progress same time RP-COM(FIT)H, RP-COM(FIT)H-AF... -
Page 15: Mode Switch
2. Module Nomenclature and Settings MODE Switch This sets or initializes the operating mode for the RP-COM(FIT)H, RP-COM(FIT)H-AF. The factory default setting is that the MODE switch setting is used and all switches are set to OFF. You can use the MODE switch to change the operating mode from the factory default setting to your desired mode. -
Page 16: Id Switch
2. Module Nomenclature and Settings ID Switch This sets the device ID for the RP-COM(FIT)H, RP-COM(FIT)H-AF. The setting range is 0 - E (0 - 14), but the ID can be set in the range 0 - 254 by software. -
Page 17: Input-Output Interface
Not used Used in PoE Not used Used in PoE Power Input Connector Table 2.5. Power Input Connector Pin Assignments Signal name Pin No. RP-COM(FIT)H RP-COM(FIT)H-AF 10 - 30VDC input 5VDC input FG (frame ground) FG (frame ground) RP-COM(FIT)H, RP-COM(FIT)H-AF... -
Page 18: Explanation In Mode Of Operation
[Device ID = 2] [Device ID = 1] (Example1) RP-COM(FIT)H can be used like "COM3 of the PC via Ethernet. * It is same when RP-COM(FIT)H-AF is replaced to RP-COM(FIT)H. (Example2) COM-2(FIT)GY can be used like "COM3", "COM4" and "COM5"... -
Page 19: Through Mode
RS-232C 2ch communication module : COM-2(FIT)GY Isolated RS-422A/RS-485 1ch communication module : COM-1PD(FIT)GY CAUTION If using broadcasting, ensure that all RP-COM(FIT)H (or RP-COM(FIT)H-AF) units have different device IDs. Device ID 255 is reserved for broadcast use. To avoid any adverse effects on other LAN devices, set the IP address, subnet mask, and other network parameters to appropriate values. - Page 20 RS-232C (device C, device ID = 1) ← Connection to Ethernet (wired LAN) → RS-232C (device E, device ID = 1) RS-232C (device D, device ID = 2) ← Connection to Ethernet (wired LAN) → RS-232C (device F, device ID = 2) * It is same when RP-COM(FIT)H-AF is replaced to RP-COM(FIT)H and when COM-1PD(FIT)GY is replaced to COM2(FIT)GY, too.
-
Page 21: Modem Mode
Device ID 255 is reserved for broadcasting. To avoid any adverse effects on other LAN devices, set the IP address, subnet mask, and other network parameters to appropriate values. When COM-1PD(FIT)GY is stacked with RP-COM(FIT)H or RP-COM(FIT)H-AF, half duplex communication is disabled. RP-COM(FIT)H, RP-COM(FIT)H-AF... - Page 22 RS-232C (device D, device ID = 4) ← Connection to Ethernet (wired LAN) → RS-232C (device E, device ID = 5) RS-232C (device D, device ID = 4) ← Connection to Ethernet (wired LAN) → RS-232C (device F, device ID = 6) * It is same when RP-COM(FIT)H-AF is replaced to RP-COM(FIT)H and when COM-1PD(FIT)GY is replaced to COM2(FIT)GY, too.
- Page 23 3. Explanation in Mode of Operation RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 24: Installation And Connection
Installation Method Mounting on a Device Module RP-COM(FIT)H (or RP-COM(FIT)H-AF) can connect the RS-232C port add-on device module COM-2(FIT)GY and the RS-422A/RS-485 port add-on COM-1PD(FIT)GY up to three totals. When COM-2(FIT)GY *1 is added up to three, RS-232C can be used up to 7ch including the RP-COM(FIT)H, RP-COM(FIT)H-AF. - Page 25 (the groove moves toward you). Locking device Unlocking Push the groove of the locking device with a tool that has a slender tip in the direction of the arrow until the device is locked. Locking device RP-COM(FIT)H, RP-COM(FIT)H-AF...
- Page 26 Inserting the stack hook by aligning it with the hook insertion inlet for the other device automatically locks the device module. Removing the device module Unlock the locking device at the top and the bottom. Remove the connected module from the hook. RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 27: Mounting On A Din Rail
Figure 4.1. Mounting on a DIN Rail < 2 / 3 > (3) The fixing hook is automatically locked, and the module can be mounted in one-touch. Fixing hook Side view Figure 4.1. Mounting on a DIN Rail < 3 / 3 > RP-COM(FIT)H, RP-COM(FIT)H-AF... - Page 28 Figure 4.2. Removing the Module from the DIN Rail < 2 / 3 > (3) By lifting the unit, you can easily remove it from the DIN rail. Side view Figure 4.2. Removing the Module from the DIN Rail < 3 / 3 > RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 29: Table Top Installation
To install on a table top, choose a sturdy, level surface with a well-ventilated space (approx. 5cm.) in all directions. CAUTION Do not obstruct the ventilation slits. This can cause the temperature inside the product to rise and can damage the components inside. RP-COM(FIT)H, RP-COM(FIT)H-AF... -
Page 30: Connection
Figure 4.3. Cable Connection CAUTION The RP-COM(FIT)H, RP-COM(FIT)H-AF operates as a DTE (Data Terminal Equipment) device. Use a straight-through cable if connecting to a DCE (Data Circuit-terminating Equipment) device and an optional cross cable if connecting to a DTE (Data Terminal Equipment) device. -
Page 31: Connection Of A Power Supply
Connection of a Power Supply CAUTION Because the power supply unit generates heat, a minimum spacing of 2 cm should be provided between the RP-COM(FIT)H, RP-COM(FIT)H-AF and any adjoining units, and care should be taken so that the ventilation holes are not covered. RP-COM(FIT)H <... - Page 32 To supply power from the power supply input connector, connect a supported cable from the detachable connector at the front. (Supported cable : AWG28 - 16) You can also connect an optional AC adapter (POA200-20-2) or power supply unit (POW-DD10GY, POW-AD13GY). Figure 4.7. Connection of a Power Supply (Using an optional AC adapter) RP-COM(FIT)H, RP-COM(FIT)H-AF...
- Page 33 4. Installation and Connection RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 34: Setup
The setup utility allows the user to detect, read and write device settings on the network, upgrade the firmware version and display its status. For information about how to use the setup utility, refer to the Help file stored on the CD-ROM. Figure 5.1. Setup Utility RP-COM(FIT)H, RP-COM(FIT)H-AF... - Page 35 5. Setup RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 36: Snmp Agent Functions
6. SNMP Agent Functions This chapter describes the SNMP functions of this product, and explains how they can be built in using the SNMP Manager SNMPc by CONTEC. SNMPc Overview SNMPc is network control software for SNMP that runs on Windows and controls all network devices that have SNMP agent functions. -
Page 37: Control Using Snmpc
Also, you can install the Utility Disk provided with this product on SNMPc, to display information about this product in graphic form as shown below. CAUTION In order to control this product, its IP address and community name must be entered accurately in the Settings. Figure 6.1. Settings RP-COM(FIT)H, RP-COM(FIT)H-AF... -
Page 38: Building-In To Snmpc
(1) Insert the attached CD in the CD drive. Here, the D drive is used as the CD drive. (2) Execute the “RPCOM_H.EXE” file in [D:\RPCOM\MIB\RP-COM(FIT)H\] or [D:\RPCOM\MIB\RP-COM(FIT)H-AF\]. (3) Embed the data according to the procedure displayed on the screen. - Page 39 6. SNMP Agent Functions RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 40: Troubleshooting
Check the SNMP settings that are being used. When the RP-COM(FIT)H, RP-COM(FIT)H-AF Will Not Start Check the power LED Be sure the power LED is on. If not, check that the AC adapter, power supply connector, and mains power plug are connected correctly. - Page 41 7. Troubleshooting RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 42: Appendix
(In case of supply from the power connector) When supplying 12.0VDC 0.2A When supplying 5.0VDC 0.4A (Max.) (Max.) (Only RP-COM(FIT)H-AF : In case (Only RP-COM(FIT)H) of supply from the power connector) Current consumption When supplying 24.0VDC 0.1A When supplying 48VDC 0.068A (Max.) - Page 43 15G, half-sine shock for 11ms in X, Y, and Z directions (JIS C0041-compliant, IEC68-2-27-compliant) Grounding Class D grounding (previous class 3 grounding) *1 : When using POA201-10-2 for RP-COM(FIT)H, when using POA200-20-2 for RP-COM(FIT)H-AF Table 8.3. Software Specifications Item Specification...
-
Page 44: External Dimensions
8. Appendix External Dimensions (1.2) (1.2) POWER MODE 10 - 30 Vi - LINK RP-COM-H 25.2 64.7 [mm] This is figure of RP-COM(FIT)H. It is the same size as with RP-COM(FIT)H-AF. Figure 8.1. External Dimensions RP-COM(FIT)H, RP-COM(FIT)H-AF... -
Page 45: Memory Register
*REG084 Opposing Same device 0: Connect to device with same device ID. station 1: Connect to device with specified device ID. setting Enable through mode only Note : In the "Access" column, "R" indicates read. RP-COM(FIT)H, RP-COM(FIT)H-AF... - Page 46 Maximum 0000h and above value of UDP port 3 REG104 Minimum 0000h and above value of UDP port 4 REG106 Maximum 0000h and above value of UDP port 4 Note : In the "Access" column, "R" indicates read. RP-COM(FIT)H, RP-COM(FIT)H-AF...
- Page 47 Note : In the "Access" column, "R" indicates read and "W" indicates write. This table defines the correspondence between device ID and IP address. It is required for communication with devices on the other side of an IP router. It is not required for communication within the same network group. RP-COM(FIT)H, RP-COM(FIT)H-AF...
-
Page 48: Differences Between The Rp-Com(Fit)Gy, Rp-Com(Fit)H And Rp-Com(Fit)H-Af
Differences between the RP-COM(FIT)GY, RP-COM(FIT)H and RP-COM(FIT)H-AF The RP-COM(FIT)H and RP-COM(FIT)H-AF partially enhanced version of the conventional products of RP-COM(FIT)GY and it is upper compatible with RP-COM(FIT)GY. Basically, you can use these new products as same way as the RP-COM(FIT)GY. - Page 49 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [10192012] [12162005] Management No. A-51-131 [10192012_rev4] Parts No. LYFN574...
