Contec CONPROSYS Series Setup Manual

Configurable type
Hide thumbs Also See for CONPROSYS Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Setup Manual
CONPROSYS series
Configurable Type
CONTENTS
Introduction .................................................................. 4
Safety Precautions ...................................................... 7
Product Nomenclature and Function................ 10
Hardware Setup......................................................... 15
CONPROSYS WEB Setting ..................................... 20
Set the Computer Network ................................... 24
Installation ................................................................... 39
Connecting with CODESYS ................................... 47
Appendix ...................................................................... 53

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONPROSYS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Contec CONPROSYS Series

Summary of Contents for Contec CONPROSYS Series

  • Page 1 Setup Manual CONPROSYS series Configurable Type CONTENTS Introduction ..............4 Safety Precautions ............7 Product Nomenclature and Function....10 Hardware Setup............15 CONPROSYS WEB Setting ........20 Set the Computer Network ........24 Installation ..............39 Connecting with CODESYS ........47...

  • Page 2: Table Of Contents

    Table of Contents Introduction ............... 4 1. Related Manuals ..............................5 2. Online Help ................................6 Safety Precautions ............. 7 1. Safety Information..............................8 2. Handling Precautions ............................9 Product Nomenclature and Function ......10 1. Nomenclature of Product Components ..................... 11 2.
  • Page 3 Table of Contents 2. Mounting on a DIN Rail..........................43 3. Setting the Configurable Type Module ....................45 Connecting with CODESYS ..........47 1. Using CODESYS ..............................48 1. How to obtain the CODESYS development environment ............. 48 2. Installation of CODESYS Package......................50 3.

  • Page 4: Introduction

    Introduction This setup manual provides information on the basic settings and installations of the product. This chapter lists the related manuals and the purposes. — 4 —...

  • Page 5: Related Manuals

    (Printed matter) package. and describes the precautions. Setup Manual Download from Read this when setting up the This describes the required items for the Contec product. setup and configuration procedure. website (PDF) Reference Manual Download from Read this when operating the...

  • Page 6: Online Help

    — — Introduction Setup Manual Configurable Type 2. Online Help We offer the detailed information on “CONPROSYS VTC” for assembling processing tasks such as calculation and control as well as on “CONPROSYS HMI” for operating and editing the monitoring screen through the Online Help. Consult the Online Help as necessary.

  • Page 7: Safety Precautions

    Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. — 7 —...

  • Page 8: Safety Information

    — — Safety Precautions Setup Manual Configurable Type 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. DANGER indicates an imminently hazardous situation which, if not DANGER avoided, will result in death or serious injury.

  • Page 9: Handling Precautions

    — — Safety Precautions Setup Manual Configurable Type 2. Handling Precautions Refer to [Handling Precautions] in the “Reference Manual (Hardware)” of the each model for handling details. — 9 —...

  • Page 10: Product Nomenclature And Function

    Product Nomenclature and Function This chapter describes product component names and their functions, pin assignment of each connector. — 10 —...

  • Page 11: Nomenclature Of Product Components

    — — Product Nomenclature and Function Setup Manual Configurable Type 1. Nomenclature of Product Components Component names of the product are shown in the figure below. This example is the configurable type M2M controller CPS-MCS341G-DS1-130. (Inside) 24V DC 3G ANT MCOM DIO0 DIO1...
  • Page 12 — — Product Nomenclature and Function Setup Manual Configurable Type Name Function USB Port This is a TYPE-A USB port. RS-232C Serial Port This is a RS-232C serial ports (male). DIP Switch 2 This is used to run SDK This example is the configurable type I/O module CPS-DIO-0808L. Name Function Stack Bus...

  • Page 13: Description Of Product Components

    — — Product Nomenclature and Function Setup Manual Configurable Type 2. Description of Product Components Main connectors used in the product are described. *Refer to the “Reference Manual (Hard ware)” of each model for unlisted connectors. 1. Power Connector Use the 3-pin connector, included in the package, to connect to external power. Pin Assignment Pin No.

  • Page 14: Digital Input/Digital Output Connector

    — — Product Nomenclature and Function Setup Manual Configurable Type 3. Digital Input/Digital Output Connector This product has 4 channels of digital input and 4 channels of digital output. You can switch them as digital input or digital output. Use the 6-pin connector, included in the package to connect to external power. Pin Assignment Pin No.

  • Page 15: Hardware Setup

    Hardware Setup This chapter describes how to set hardware including supplied items and switches. — 15 —...

  • Page 16: Insert Sim Card

    When communicating through 3G network with SIM card, follow the steps described below to insert SIM card. SIM card is required individually. Visit the CONTEC website to find the compatible card with the product. https://www.contec.com/ Website Unfasten the screw of the cover.
  • Page 17 — — Hardware Setup Setup Manual Configurable Type Fasten the card cover with a screw. *Reverse the procedure described in the "Insert SIM Card " to remove the card. *Tightening torque of the card cover is 3.5 kgF. Cm. — 17 —...

  • Page 18: Set Antenna

    — — Hardware Setup Setup Manual Configurable Type 2. Set Antenna Set the supplied antenna to the antenna connector. Turn the antenna in the direction of the arrow shown to fasten. — 18 —...

  • Page 19: Dip Switch

    — — Hardware Setup Setup Manual Configurable Type 3. DIP switch DIP Switch 1 It is used for user setup. The factory default of all switches are set to “OFF”. Bit No. Description System Reservation: Always OFF 2: OFF, 3: OFF This indicates it is set in the default setting.

  • Page 20: Conprosys Web Setting

    CONPROSYS WEB Setting This chapter describes the "CONPROSYS WEB Setting" in which the functions of the product are set. — 20 —...

  • Page 21: Conprosys Web Setting Outline

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 1. CONPROSYS WEB Setting Outline The functions of the product can be set easily with the "CONPROSYS WEB Setting" through a browser. This section describes the outline of CONPROSYS WEB Setting. 1.

  • Page 22: Menu Function List

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 2. Menu Function List Menu Functions are listed below. Menu item name Function Setting Network Wired LAN Set up the network such as “IP address”. Wireless LAN Set up the wireless LAN setting such as “IP address”. Set up 3G communication.
  • Page 23 — — CONPROSYS WEB Setting Setup Manual Configurable Type Menu item name Function Reboot Reboot the product. Shut down Shut down the product. *Refer to the "Reference Manual (Software)" for the details of each item. — 23 —...

  • Page 24: Set The Computer Network

    Set the Computer Network This chapter describes how to connect the product with a PC, set the network, and check the communication. — 24 —...

  • Page 25: Items To Set Up

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 1. Items to Set Up The product requires the items listed below to set up. Have the followings ready. Controller Power unit (Individually sold: Computer (CONPROSYS product) (CPS-PWD-90AW24-01 recommended) Lead AC power cable LAN cable Power cable (AWG28-16...

  • Page 26: Connectors For Setup

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 2. Connectors for Setup The positions of connectors to connect cables are listed below. Power 24VDC PWR ST1 ST2 ERR MCOM Digital I/O DIO0 DIO1 DIO2 DIO3 — 26 —...

  • Page 27: Connect With A Pc

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 3. Connect with a PC To set the product, you need to first set up the network between the PC and the product in order to establish communication. First, connect the product with the PC. Follow the instructions below to connect the computer, the controller, and the power unit.
  • Page 28 — — CONPROSYS WEB Setting Setup Manual Configurable Type Connect the power unit with AC plug, then turn on the computer. *After connecting the power unit with AC plug, it takes a few minutes for the controller to complete the start-up. (approx. 1-2 min) —...

  • Page 29: Set The Computer Network

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 4. Set the Computer Network Follow the “Computer Network Setting Procedure” described below and set the network to make the IP addresses as shown. The product must set a unique IP address for the bold part (200 or 101) that is not used by other devices on your network.
  • Page 30 — — CONPROSYS WEB Setting Setup Manual Configurable Type Click the [Change adapter options] in [Network status]. Double-click the appeared [Ethernet] Click the [Property] in [Ethernet Status] dialog box. — 30 —...
  • Page 31 — — CONPROSYS WEB Setting Setup Manual Configurable Type Double-click the [Internet protocol version 4(TCP/IPv4)] in [Ethernet Properties] dialog box. In the [Internet protocol version 4 (TCP/IPv4) property], set IP address and Subnet mask as shown below. Click the [OK] → the [OK] → the [Close] to close the dialog box and complete the network setting.

  • Page 32: Check Communication

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 5. Check Communication Start Web browser on your computer. Enter IP address (10.1.1.101) of the controller in the address bar, then press the [Enter] key. The dialog box asking for the User name and Password appears, enter them and click the [OK]. Refer to “Compatible Web Browser (page 21)”...

  • Page 33: Check Operation

    — — CONPROSYS WEB Setting Setup Manual Configurable Type 6. Check Operation Once communication has confirmed, proceed to the next steps described below to check whether the controller is operating properly. Connect the pin number 2 (DIO0) and 3 (DIO1) of the digital I/O connector with the lead-wire to create the connector for operation check.
  • Page 34 — — CONPROSYS WEB Setting Setup Manual Configurable Type From CONPROSYS WEB Setting, click the [Monitoring edit] to show the “CONPROSYS VTC”. For the details of CONPROSYS VTC, refer to the “Easy Data Process and Control” or the “Reference Manual (Software)”. Click the module images or the [Configure] button in the list to set the details.
  • Page 35 — — CONPROSYS WEB Setting Setup Manual Configurable Type Module list  Change those DIO0, DIO1 to value DIO0⇒DI, DIO1⇒D 1O respectively. (Default settings are all DI) Click the [Set] after setting After changing the settings, go to [Exit] on CONPROSYS WEB Setting, and click the [Save and Reboot] to save the changes and reboot the controller.
  • Page 36 — — CONPROSYS WEB Setting Setup Manual Configurable Type Click the [Monitoring edit] on CONPROSYS WEB Setting, and change to the “Run” in the Mode that is located on the upper-right side. From here, create a monitoring view screen with “CONPROSYS HMI”. Refer to the “[Monitoring edit]”...
  • Page 37 — — CONPROSYS WEB Setting Setup Manual Configurable Type From Components list on the left side, select “Switch” and “Lamp” controls and drag & drop them onto the “Layer area”. Drag & Drop Set the switch. (1) Click the “Switch” control on the layer area to activate. (2) Click [! OnPressd] in the [Property tab] on the right side, (3) and click “Link Box”...
  • Page 38 — — CONPROSYS WEB Setting Setup Manual Configurable Type Set the lamp. (1) Click the “Lamp” control on the layer area to activate. (2) Click [value] in the [Property tab] on the right side, (3) and click “Link Box” icon in the Link Box. (4) Select [CPU_DI00] in Device Tree and click (5) the [OK].

  • Page 39: Installation

    Installation This chapter describes installation conditions and how to mount the product on a DIN rail. — 39 —...

  • Page 40: Install The Product

    — — Installation Setup Manual Configurable Type 1. Install the Product 1. Installation Conditions  Installation Orientation Install the product in the orientations shown below (0 °). Other orientations may cause problems such as malfunctions due to inadequate heat dissipation. DIN rail Mounting —...
  • Page 41 — — Installation Setup Manual Configurable Type  Ambient Temperature The ambient temperature is decided from the multiple measurement points which are a 50mm- distance from the product. During the operation, adjust the air current to make certain that the temperatures measured in the points stay within the specified temperature.
  • Page 42 — — Installation Setup Manual Configurable Type CAUTION Note that although the ambient temperature is within the specified range, an operational  malfunction may occur if there is other device generating high heat; the radiation will influence the product to increase its temperature. Do not install this product into the fully-sealed space except the case in which the internal ...

  • Page 43: Mounting On A Din Rail

    — — Installation Setup Manual Configurable Type 2. Mounting on a DIN Rail This product should be set on DIN rail for operation.  How to Mount Pull down the hook to unlock. If the hook is stuck, use a slotted screwdriver to unlock. Fixed hook (1).
  • Page 44 — — Installation Setup Manual Configurable Type Push the hook up to lock the product on the DIN rail. *When removing the controller, reverse the procedure described in "How to Mount (page 43)". — 44 —...

  • Page 45: Setting The Configurable Type Module

    — — Installation Setup Manual Configurable Type 3. Setting the Configurable Type Module CAUTION Always confirm the PWR-LED is turned off before setting or removing the modules   How to Set First, slide the attached end cover to remove it from the product that is mounted on the DIN Rail.
  • Page 46 — — Installation Setup Manual Configurable Type Engage the side rail of the setting module to the side rail of the controller (or another module) that is already mounted. When the rails fit, slide the setting module all the way toward the DIN rail. Module side rail 山路を登りながら...

  • Page 47: Connecting With Codesys

    Connecting with CODESYS This chapter describes how to use the product with CODESYS. Reading the following instruction when using the “PAC series” controller. — 47 —...

  • Page 48: Using Codesys

    — — Connecting with CODESYS Setup Manual Configurable Type 1. Using CODESYS With PAC series, you can utilize the “CODESYS”, a device-independent system that is compliant with the IEC 61131-3 standard, for PLC or HMI development. To use the CODESYS, installation of the CODESYS development environment and “CODESYS Package” for CONPROSYS are required.
  • Page 49 — — Connecting with CODESYS Setup Manual Configurable Type After log-in, click the “Download” to start downloading. Execute the downloaded file and install CODESYS development environment into the host computer. — 49 —...

  • Page 50: Installation Of Codesys Package

    2. Installation of CODESYS Package Install the CODESYS Package from the CONTEC website. Go to the CONTEC website. From the menu Downloads, select [Drivers & Software]. Enter the product name or specify the category (PAC system) and click the [Search].

  • Page 51: Connecting To Pre-Installed System (Plc Controller)

    Specify the (3) Name and the (4) Location of the project, then click the (5) [OK]. In the Standard Project dialog, select the controller to be used in the (6) [Device].Device can be shown as [CODESYS Control CONTEC CPS-PCXXXXXXXXXX]. From the (7) “PLC_PRG”, choose Structured Text (ST).
  • Page 52 Setup Manual Configurable Type Now, see whether connecting the controller from CODESYS can be achieved. On the Devices window, double click the (8) “Device (CODESYS Control CONTEC CPS- PCXXXXXXXXXX)” icon to open “Device Configuration window”. Select the (9) [Communication Settings] in the Device tab.

  • Page 53: Appendix

    Appendix This chapter describes how to use the task function “CONPROSYS VTC” monitoring function “CONPROSYS HMI” that are implemented in the product. — 53 —...

  • Page 54: Useful Functions

    — — Revision History Setup Manual Configurable Type 1. Useful functions The M2M controller features the "CONPROSYS VTC"(Visual Task Control), with which you can create processing tasks without language programming by combining icons like drawing the flowchart to calculate or control data, and the "CONPROSYS HMI"(Human Machine Interface), which monitors the input signals and displays the conditions of the signals with control icons.

  • Page 55: Create Processing Tasks

    — — Appendix Setup Manual Configurable Type Name Function Menu bar The menu bar is used to execute commands with menu buttons. Control selection area The task controls can be selected to place on the task setting area. Task setting area This area is where the task controls are placed and set.

  • Page 56: Basic Procedure For Creating Processing Tasks

    — — Appendix Setup Manual Configurable Type 4. Basic Procedure for Creating Processing Tasks  Place Task Controls 1. Select a necessary task control from Control selection area. 2. Drag and drop it onto the task setting area.  Set Property The property of placed controls are displayed on the property area.
  • Page 57 — — Appendix Setup Manual Configurable Type  Copy and Delete Controls Right-click the placed control to show the editing menu. In this menu, such as coping or deleting controls can be performed.  Move Controls The placed control can be moved by drag and drop. Create the tasks by following the procedure described above to place controls on the task setting area.
  • Page 58 — — Appendix Setup Manual Configurable Type  Save a Task Processing From Menu command, select the “File” – “Save task” to open a dialog to save the created task processing with the specified number.  Open a Saved Task From Menu command, select the “File”...

  • Page 59: Monitoring Edit

    — — Appendix Setup Manual Configurable Type 2. Monitoring Edit 1. Monitoring function (CONPROSYS HMI) You can create a monitoring screen through a web browser without a specialized knowledge of language programming. Remote-monitoring of the operations, errors, or standstill in the facilities are achieved. Easy creating a monitoring screen.

  • Page 60: Create A Monitoring Screen

    — — Appendix Setup Manual Configurable Type 3. Create a Monitoring Screen From the CONPROSYS WEB Setting, click the [Monitoring edit]. CONPROSYS HMI starts up and you can create the monitoring screen. 4. Basic Procedure for Creating a Monitoring Screen ...
  • Page 61 — — Appendix Setup Manual Configurable Type  Configure the Properties of Controls (1)Click the placed control. (2)The property of the control is shown in the “Property” on the right side of the screen. The properties area allows you to change the values, set the data to link with I/O devices or other controls.
  • Page 62 — — Appendix Setup Manual Configurable Type  Copy and Delete Controls Right-click the activated control to show the editing menu. In this menu, such as coping or deleting controls can be performed.  Configure the Layer Select “Layer” tab at the upper right on the screen to open the layer properties. In the “Settings”...
  • Page 63 — — Appendix Setup Manual Configurable Type  JavaScript You can enter code using JavaScript as necessary. If a particular control logic is needed to run the system, code the behaviors of the system using JavaScript in “JavaScript” area. Refer to “Online Help” for usable JavaScript functions for each control. ...
  • Page 64 — — Appendix Setup Manual Configurable Type Revision History MONTH YEAR Summary of Changes July 2018 The First Edition — 64 —...
  • Page 65 CONTEC CO., LTD. 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. Setup Manual Configurable Type [07202018] July 2018 Edition...
