- Page 1 Instructions and installation manual MODELS: BSGH95-ANZ / BSGH75-ANZ BSGH64-ANZ / BSGH32-ANZ BSGH30-ANZ PLEASE READ THIS MANUAL BEFORE INSTALLING THE COOKTOP. COD. 04067IR 26.02.2013...
- Page 2 DESCRIPTION OF COOKTOP 12 11 Natural U-LPG 1 Ultra rapid gas burner/WOK 14.5 MJ/h 12.6 MJ/h 2 Rapid gas burner 12.0 MJ/h 10.4 MJ/h 3 Semirapid reduced gas burner 5.4 MJ/h 4.9 MJ/h 4 Semirapid gas burner 7.1 MJ/h 6.3 MJ/h 5 Auxiliary gas burner 4.1 MJ/h 3.6 MJ/h...
- Page 3 1) BURNERS Power ratings Pan Ø A diagram is screen-printed above each knob on the Burners in cm Natural U-LPG front panel. This diagram indicates to which burner the knob in question corresponds. After having Ultra rapid/WOK 14.5 MJ/h 12.6 MJ/h 24 ÷...
- Page 4 WARNINGS AND ADVICE FOR THE USER: - Do not attempt to change the technical characteristics of the product because it can be dangerous. - If you decide longer use this appliance any more (or replace an old model), before disposing of it, make it inoperative in conformity with current law on the protection of health and the prevention of environmental pollution by making its dangerous parts harmless, especially for children who might play on an abandoned appliance.
- Page 5 CLEANING 1f - 2f (30 Cm) Vetroceramic IMPORTANT: Always disconnect the appliance from the gas If you wish to maintain the shine of the ceramic and electricity mains before carrying out any surface, treat the glass with a silicon-based film cleaning operation.
-
Page 6: Installation
INSTALLATION TECHNICAL INFORMATION 3) INSTALLING THE COOKTOP FOR THE INSTALLER Check that the appliance is in a good condition after This appliance shall be installed only by authorised having removed the outer packaging and internal personnel accordance with wrappings from around the various loose parts. In manufacturer’s installation instructions, local gas case of doubt, do not use the appliance and contact fitting regulations, municipal codes, electrical wiring... - Page 7 INSTALLATION 4) FIXING THE COOKTOP - When the appliance is installed so that the base can be touched, we recommend fitting a The cooktop has a special seal which prevents protecting shield. This shield must be at least liquid from getting into the cabinet. Strictly comply 70 mm below the base of the bench top (fig.
- Page 8 INSTALLATION 5) GAS CONNECTION Liquified Petroleum Gas. In a Universal LP Gas installation the gas The gas connection is located in the rear and on regulation is made at the gas cylinder and the underside of the appliance 100 mm from the regulation at the appliance is not required.
-
Page 9: Electrical Connection
INSTALLATION 6) ELECTRICAL CONNECTION Before performing any service on the electrical part of the appliance, it must absolutely be IMPORTANT: the appliance must be installed disconnected from the electrical network. following the manufacturer's instructions. The manufacturer will not be liable for injury to persons or animals or property damage caused If the installation requires modifications to by an incorrect installation. - Page 10 ADJUSTMENTS 7) TAPS Always disconnect the appliance from the electricity main before making any adjustments. Our taps are suitable for all gas, they are male All seals must be replaced by the technician at conical type. the end of any adjustments or regulations. “Reduced rate”...
- Page 11 4 Burners 4 Burners BSGH75-ANZ BSGH75-ANZ 5 Burners 5 Burners BSGH95-ANZ BSGH95-ANZ 5 Burners 5 Burners 1. Remove each burner cap and burner skirt. 1. Remove each burner cap and burner skirt. 2. Remove the Universal LP Gas main injector with 2.
-
Page 12: Replacing The Injectors
CONVERSIONS 10) REPLACING THE INJECTORS and affix the label corresponding to the new gas regulation on the appliance instead of the already The burners can be adapted to different types of existing one. This label is supplied in the packet gas by installing injectors suited to the type of gas containing the spare injectors. - Page 13 SERVICING CABLE TYPES AND SECTIONS TYPE OF TYPE OF SINGLE - PHASE COOKTOP CABLE POWER SUPPLY Gas cooktop H05 RR - F Section 3 x 0.75 mm ATTENTION!!! If the power supply cable is replaced, the installer should leave the ground wire longer than the phase conductors (fig.
-
Page 14: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS Before leaving the factory, this appliance will have been tested and regulated by expert and specialised personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention. - Page 16 Service Telephone 1800 444 357 Website www.thinkappliances.com Applico Ltd. Private Bag 92900 Onehunga, Auckland, New Zealand 1061 Website www.applico.nz United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Sales Telephone (0118) 933 6900 Website: www.baumatic.co.uk...
