OPERATION AND MAINTENANCE MANUAL
SKD-LRBNK50
SKD-LRBNK100
SKD-LRBNK100F
SKD-LRBNK220
Attention!
LRBNK is belonging to high torque series. For safety consideration,
please collaborate it with Auxiliary Arm (KP-AUXA Series).
DC-TYPE Automatic Non Carbon-Brush Series
KILEWS INDUSTRIAL CO., LTD.
SKD-LRBNK75
SKD-LRBNK150
SKD-LRBNK150F
http://www.kilews.com
Y2F209A-1-001
Advertisement
Table of Contents
Related Manuals for Kilews SKD-LRBNK50
Summary of Contents for Kilews SKD-LRBNK50
- Page 1 OPERATION AND MAINTENANCE MANUAL SKD-LRBNK50 SKD-LRBNK75 SKD-LRBNK100 SKD-LRBNK150 SKD-LRBNK100F SKD-LRBNK150F SKD-LRBNK220 Attention! LRBNK is belonging to high torque series. For safety consideration, please collaborate it with Auxiliary Arm (KP-AUXA Series). DC-TYPE Automatic Non Carbon-Brush Series KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com Y2F209A-1-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation. If damaged, have the power tool repaired before use. Many accidents are cause by poorly maintained power tools. Inspect extension cords periodically and replace, if damaged.
- Page 5 7) Kindly note that SKD-LRBNK50/75/100/150/100F/150F/220 will be enclosed with thetorque fixing ring. The torque fixing ring can protect the operator and avoid getting hurt by the threads on the screwdriver. And it can fix the torque and prevent the torque to be adjusted.
-
Page 6: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE ! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. - Page 7 Operations Cautions 1)Before changing bits from RBNK Series screwdriver, make sure the Forward / Reverse switch stays at “OFF”position. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals. 3) Use screwdriver carefully, do not drop or abuse.
-
Page 8: Description Of Operation
CAUTION ● Do not drop or abuse the tool. ● Whenever a tool is not being used, position the Power Switch to the “OFF” position and unplug the power cord. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. -
Page 9: Do Not Attempt To Repair This Electric Screwdriver
2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. -
Page 10: Specifications
1、ＢＩＴ Type： No. 00 ．．． Bit use in dia 1.3~1.8mm screw No. 0．．．． Bit use in dia 1.8~2.0mm screw No. 1．．． ．Bit use in dia 2.0~2.6mm screw No. 2．． ．．Bit use in dia 3.0~4.0mm screw 2、SKD-LRBNK50/75/100/150 B with BIT 2 Pcs SKD-LRBNK100F/150F/220 B... -
Page 11: Torque Adjustment Operation
If turn to “LO”on the power supplier, the screwdriver can’t offer high watt output, the torque on the screwdriver should be adjust under middle range to use. Please refer to Kilews website http://www.kilews.com for the detail component list.
