OPERATION AND MAINTENANCE MANUAL
Attention!
RBK120/RBK180/RBK250/RBK350/RBK500 is belonging to high
torque series. For safety consideration, please collaborate it
with Auxiliary Arm (KP-AUXA /KP-AUXA-500 Series).
DC-TYPE Automatic Non Carbon-Brush Series
KILEWS INDUSTRIAL CO., LTD.
SKD-RBK60L
SKD-RBK90L
SKD-RBK120L
SKD-RBK120LF
SKD-RBK180L
SKD-RBK180LF
SKD-RBK250L
SKD-RBK350L
SKD-RBK500L
http://www.kilews.com
SKD-RBK60P
SKD-RBK90P
SKD-RBK120P
SKD-RBK120PF
SKD-RBK180P
SKD-RBK180PF
SKD-RBK250P
SKD-RBK350P
SKD-RBK500P
Y2F183A-E-001
Advertisement
Table of Contents
Related Manuals for Kilews SKD-RBK60L
Summary of Contents for Kilews SKD-RBK60L
- Page 1 SKD-RBK180P SKD-RBK180LF SKD-RBK180PF SKD-RBK250L SKD-RBK250P SKD-RBK350L SKD-RBK350P SKD-RBK500L SKD-RBK500P Attention! RBK120/RBK180/RBK250/RBK350/RBK500 is belonging to high torque series. For safety consideration, please collaborate it with Auxiliary Arm (KP-AUXA /KP-AUXA-500 Series). DC-TYPE Automatic Non Carbon-Brush Series KILEWS INDUSTRIAL CO., LTD. http://www.kilews.com Y2F183A-E-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 c) Disconnect the plug from the power source before making any adjustments, changing accessories, or storing the power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
-
Page 5: Do Not Operate This Tool Without Protective Earth Connected
7) Kindly note that SKD-RBK60/90/120/180/120F/180F/250 will be enclosed with the torque fixing ring. The torque fixing ring can protect the operator and avoid getting hurt by the threads on the screwdriver. And it can fix the torque and prevent the torque to be adjusted. In order to prevent getting hurt, kindly check if the torque fixing ring is fixed when using the screwdriver and adjusting the torque. - Page 6 Operations Cautions 1)Before changing bits from RBK Series screwdriver, make sure the Forward / Reverse switch stays at “OFF”position. Before changing bits from TBN Series screwdriver, make sure the Forward / Reverse switch stays at the middle position. The screwdriver must be unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver.
-
Page 7: Description Of Operation
CAUTION ● Do not drop or abuse the tool. ● Whenever a tool is not being used, position the Power Switch to the “OFF” position and unplug the power cord. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. -
Page 8: Do Not Attempt To Repair This Electric Screw Driver
2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. -
Page 9: Specifications
Specifications RBK60L RBK90L RBK120L RBK180L MODEL (SKD-) RBK60P RBK90P RBK120P RBK180P Input voltage(DC) DC 40V Power Consumption Torque (N.m) 4~12 6~18 Repeatable Torque ±5% Accuracy (%) Torque Adjustment Stepless Unloaded Rotation Speed 1000 (R.p.m) )±10% Machine ≤8 ≤10 4.0~5.0 5.0~6.0 screw(mm) Screw Size... - Page 10 SKD-RBK60 90 120 120F 180 180F 250 B/W with BIT(socket) 2 Pcs (1 Pcs) SKD-RBK350 B/W with BIT(socket) 3 Pcs (1 Pcs) SKD-RBK500 W with (socket) (1 Pcs) 2、Suspension rack and Torque fixing ring acceptable for use with the tool are available from KILEWS catalogue.
-
Page 11: Torque Adjustment Operation
7. If turn to “LO”on the power supplier, the screwdriver can’t offer high watt output, the torque on the screwdriver should be adjust under middle range to use. 8. Please refer to Kilews website http://www.kilews.com for the detail component list.
