Washing Machine
User's Manual
WTE 12745 X0D
EN
Document Number=
2820527141_EN/ 22-01-19.(14:32)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTE12745 X0D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beko WTE12745 X0D

Summary of Contents for Beko WTE12745 X0D

  • Page 1 Washing Machine User’s Manual WTE 12745 X0D Document Number= 2820527141_EN/ 22-01-19.(14:32)
  • Page 2 This product was manufactured using the latest technology in environmentally friendly conditions.

  • Page 3: General Safety Instructions

    General safety instructions This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 Life and property safety Never place the product on a carpet-covered floor. Otherwise, lack of airflow beneath the machine will cause electrical parts to overheat.

  • Page 4: Electrical Safety

    Electrical products are dangerous for the children. Keep children away from the product when it is in use. Do not allow them to play with the product. Use child lock to prevent children from intervening with the product. Do not forget to close the loading door when leaving the room where the product is located.

  • Page 5: Important Instructions For Environment

    Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling.

  • Page 6: Technical Specifications

    Technical specifications Supplier name or trademark Beko Model name WTE 12745 X0D Rated capacity (kg) Maximum spin speed (rpm) 1400 Height (cm) Width (cm) Depth (cm) Net weight (±4 kg.) Single Water inlet / Double Water inlet • / - • Available Electrical input (V/Hz)

  • Page 7: Appropriate Installation Location

    4.1 Installation • Apply to the nearest authorised service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures. • Make sure that the installation and electrical connections of the product are performed by authorised service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorised persons.

  • Page 8: Connecting Water Supply

    4.1.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher. CAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will get damaged or the product will switch to protection mode and will not operate. CAUTION: Do not use old or used water inlet hoses on the new product.

  • Page 9: Adjusting The Feet

    4.1.6 Adjusting the feet CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems.

  • Page 10: Preparing Laundry For Washing

    4.2 Preparation 4.2.1 Sorting the laundry * Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always observe the instructions given on the garment care labels. 4.2.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwiring, belt buckles or metal buttons will damage the product.

  • Page 11: Using Detergent And Softener

    4.2.6 Using detergent and softener When using detergent, softener, starch, fabric dye, bleach and descaling agents to be added through the detergent container 2, read the manufacturer's instructions written on the package and follow the dosages specified. Use a measuring cup, if any. For programmes where liquid detergent dosing is selected, do not add any powder detergent.
  • Page 12 • When adding liquid detergent or softener, do not exceed the tip of the «Max» label. • Close the lid. • Close the detergent drawer by pushing it slowly. • After closing the detergent drawer, the flashing dosing symbol ( will start to light up steadily. • Indicates that the components are filled and the drawer is closed. • For coloured and white laundry, it is recommended to fill commonly used liquid detergent in the compartment. • Despite the fact that the detergent compartments are filled, if 'detergent symbol ' continues to flash, the detergent drawer is not fully closed. Ensure that the drawer is seated in place by pushing it. WARNING: While the detergent drawer is full with detergent and/or softener: a- Do not pull the machine,...
  • Page 13 Liquid detergent and softener dosing symbols will be active or inactive depending on the programme selected on the display. • If the liquid detergent symbol is on, this means that liquid detergent dosing is active. • If the softener symbol is on, this means that softener dosing is active. • If the liquid detergent symbol is off, this means that you can wash your laundry with powder detergent. • If the softener symbol is off, this means no softener will be used in the rinsing step. The first position on the display: means liquid detergent is active, softener is on. If liquid detergent and softener symbols are active on the display, the liquid detergent will become on and the softener will become off after you press the Auto Dosing key for the first time.

  • Page 14: Tips For Efficient Washing

    4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature temperature range temperature range range based on soiling level: range based on soiling level: based on soiling level: based on soiling level: 40-90°C) cold -40°C) cold -40°C)

  • Page 15: Operating The Product

    4.3 Operating the product 4.3.1 Control panel WTE 12745 X0D Cottons Cottons Eco AntiCrease+ On / Hygiene+ Synthetics Temp. Daily Express Xpress Super Short Dark Care Wash Jeans Outdoor Woollens Sports Hand Wash Duvet Start/ Pet Hair Night Time Down Wear Fast+ AutoDose Pause...

  • Page 16: Programme And Consumption Table

    4.3.3 Programme and consumption table Auxiliary functions Selectable Programme temperature range °C 60** 1400 • Cold-60 61,5 0,55 Cottons 1400 • Cold-60 57,3 0,97 57,3 0,97 1400 • Cold-60 1400 • Cold-60 61,5 0,55 Cottons Eco 1400 • Cold-60 57,3 0,97 1400 •...

  • Page 17: Programme Selection

    4.3.4 Programme selection 1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with "Programme and consumption table". Programmes are limited with the highest spin speed appropriate for that particular type of fabric. When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.
  • Page 18 Allergy UK, is the brand of the British Allergy Association. Seal of Approval is created to guide people that require recommendation about a product that the related product restricts / reduces / eliminates the allergens or reduces the allergen content significantly in the ambient where allergy patients exist.
  • Page 19 • Delicates You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20 degrees or by selecting the cold wash option. •...

  • Page 20: Temperature Selection

    4.3.6 Temperature selection Whenever a new programme is selected, the recommended temperature for the programme appears on the temperature indicator. It is possible that the recommended temperature value is not the maximum temperature that can be selected for the current programme. Press the Temperature Adjustment button to change the temperature.

  • Page 21: Auxiliary Function Selection

    If you want to spin your laundry after the Rinse Hold function: - Adjust the Spin Speed. - Press Start / Pause / Cancel button. The programme will resume. Machine drains the water and spins the laundry. If you want to drain the water at the end of the programme without spinning, use No Spin function. No change can be made in programmes where spin speed adjustment is not allowed.

  • Page 22: Auxiliary Functions

    4.3.8.1 Auxiliary functions • Fast+ When this function is selected, the durations of the relevant programmes get shorter by 50%. Thanks to the optimised washing steps, high mechanic activity and optimum water consumption, high washing performance is achieved in spite of the reduced duration. •...
  • Page 23 • AntiCrease+ This function is selected when the 4th auxiliary function is pressed and held for 3 seconds and the programme follow-up light for the relevant step turns on. When the function is selected, the drum rotates for up to 8 hours for preventing the laundry from creasing at the end of the programme.

  • Page 24: Starting The Programme

    With the End Time function, the startup of the programme may be delayed up to 24 hours. After pressing End Time button, the programme's estimated ending time is displayed. If the End Time is set, End Time indicator is illuminated. In order for the End Time function is activated and the programme is completed at the end of the specified time, you must press Start/Pause button after adjusting the time.

  • Page 25: Changing The Selections After Programme Has Started

    Opening the loading door in case of power failure: In case of power failure, you can use the loading door emergency handle under the pump filter cap to open the loading door manually. CAUTION: To avoid any water overflow before opening the loading door, make sure there is no water left inside the machine.
  • Page 26 Switching the machine to pause mode: Press the Start/Pause button to switch the machine to pause mode. Pause symbol will flash on the display. Changing the programme selection after programme has started: The programme change is not allowed when the current programme is running. You can select the new programme after switching the current programme to pause mode.

  • Page 27: Maintenance And Cleaning

    4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer When to clean • If you see hardened, viscous detergent or softener when you open the dosing container lid, • If you are not satisfied with the washing results (the detergent or softener may not be taken into the washing medium since it is hardened), •...

  • Page 28: Cleaning The Loading Door And The Drum

    • Use a flat screwdriver to remove the tabs holding the upper cover of the detergent drawer (there are 6 tabs in total: two on the right side of the drawer, two on the left and two at the back) and wash the inside of the drawer. • After washing it, place the cover back to its location. Make sure that all tabs are fitted. If the tabs do not seat properly, liquids may leak or the detergent drawer may get stuck or difficultly move on the drawer slide.

  • Page 29: Draining Remaining Water And Cleaning The Pump Filter

    Close the taps. Remove the nuts of the water intake hoses to access the filters on the water intake valves. Clean them with an appropriate brush. If the filters are too dirty, remove them from their places with a pliers and clean in this way.

  • Page 30: Troubleshooting

    Troubleshooting Problem Cause Solution Programs do not start after the Start / Pause / Cancel button is not pressed. • *Press Start / Pause / Cancel button. loading door is closed. It may be difficult to close the loading door in case of • Reduce the amount of laundry and make sure excessive loading.
  • Page 31 Problem Cause Solution Washing takes longer than Water pressure is low. • Product waits until taking in adequate amount specified in the user manual.(*) of water to prevent poor washing quality due to the decreased amount of water. Therefore, the washing time extends. Voltage is low.
  • Page 32 Problem Cause Solution Washing performance is poor: Insufficient amount of detergent is used. • Use the recommended amount of detergent Stains persist or the laundry is not appropriate for water hardness and the laundry. whitened. (**) Excessive laundry is loaded in. • Do not load the product in excess.
  • Page 33 Problem Cause Solution Detergent residue in the detergent Detergent was put in wet drawer. • Dry the detergent drawer before putting in drawer. (**) detergent. Detergent has gotten damp. • Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures.
  • Page 36 www.beko.com...
